Summary of Contents for Optoma OC

  • Page 1 OC Hub User manual...

  • Page 2: Table Of Contents

    Using the Remote Control ......................18 Installing/Replacing the Remote Control Batteries .............. 18 Remote Control Operating Range ..................19 Turning On the OC Hub ......................20 Putting the OC Hub into Sleep Mode .................. 20 Setup Wizard ..........................21 English...
  • Page 3 Home Screen Overview......................24 OSD Menu ..........................25 Shortcut Menu ........................26 Configuring Audio Settings ....................27 Viewing OC Hub Information ....................27 Android Settings Menu ......................28 Personalizing the System ....................29 Configuring Network Settings ....................30 Configuring Device Settings ....................32 Configuring Security Settings ....................

  • Page 4: Safety

    ‡ Do not attempt to service the device yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the device for repair. ‡ Disconnect the power plug from AC outlet if the device is not being used for a long period of time.

  • Page 5: Copyright

    Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2024 Disclaimer The information in this document is subject to change without notice.

  • Page 6: Declaration Of Conformity For Eu Countries

    Declaration of Conformity for EU Countries ‡ EMC Directive 2014/30/EU (Including amendments) ‡ Radio equipment directive 2014/53/EU ‡ The power consumption of the product in networked standby when all wired network ports are connected and all wireless network ports are activated was less than 2.0W. WEEE Disposal instructions Do not throw this electronic device into the trash when discarding.

  • Page 7: 限用物質含有情況標示聲明書 (Declaration Of The Presence Condition Of The Restricted Substances Marking) ─ Taiwan Rohs Compliance

    限用物質含有情況標示聲明書 (Declaration of the Presence Condition of the Restricted Substances Marking) ─ Taiwan RoHS Compliance 設備名稱: OC Hub, 型號 (型式): OCH100 Equipment Name: OC Hub Type designation: OCH100 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 鉛 汞 鎘 六價鉻...

  • Page 8: Introduction

    URL: https://www.optoma.com/support/download *The product images shown are for illustration purposes only and may not be an exact representation of the product. Optoma reserves the right to change product images and specifications at any time without notice. Wall Mounting Kit Remote Control...

  • Page 9: Product Overview

    INTRODUCTION Product Overview Front View Item Item IR receiver LED indicator Rear View Item Item USB 3.0 port HDMI In port USB 2.0 ports (x2) HDMI Out port Reset button LAN port RS232 mini jack DC In jack USB Type-C port Note: ‡...

  • Page 10: Remote Control

    INTRODUCTION Remote Control Button Description Power ( ) Press to put the device into Sleep mode. Press it again to wake the device. Mute ( ) Turn off the sound temporarily. Playback Control No function. Input ( ) Select the input source. Recent Tasks ( ) View currently running applications.
  • Page 11 INTRODUCTION Button Description File Manager ( ) Launch the File Manager app. All Apps ( ) View all pre-installed applications. Menu ( ) Display or hide the OSD menu. Enter Mouse mode. Press it again to switch back to Default Button mode. Mouse Toggle Note: In Mouse mode you can use the Navigation keys (...

  • Page 12: Setup And Installation

    HDMI Out Connect one end of the power cord to the DC In jack on the OC Hub. Connect the other end of the power cord to a power outlet or a power supply. The OC Hub will automatically turn on.

  • Page 13: Connecting Other External Devices

    SETUP AND INSTALLATION Connecting Other External Devices HDMI input connection Connect your video source or a computer to the OC Hub using an HDMI cable. HDMI IN USB Type-C connection Connect your computer to the OC Hub using a USB Type-C cable.
  • Page 14 For USB flash drive connection, simply plug it into one of the available USB ports. USB3.0 USB2.0 RS232 connection Connect your IFP/FP, TV/monitor or projector to the OC Hub using a RS232 mini jack cable. Note: If needed, use a RS232 Male to Female extension cable to extend your existing cable connections. RS232...
  • Page 15 OC Hub. USB 3.0 USB 2.0 ‡ For wired network connections, connect the OC Hub to the network using an Ethernet cable. Note: The LAN port supports PoE function which can delivery a maximum power output of 25W. LAN Settings Note: To configure network settings, refer to “Configuring Network Settings”...

  • Page 16: Wall Mounting

    SETUP AND INSTALLATION Wall Mounting Use only an Optoma-approved wall mount kit. Kit will include the following items: Mounting Plate Screw: M2 x 10mm (x2) Installing the Wall Mount To mount the device on the wall, complete the following steps: Place the device on a stable surface with its bottom facing up.
  • Page 17 SETUP AND INSTALLATION Align the screw holes on the mounting plate with the screw holes on the back of the OC Hub, then secure the mounting plate with two screws. Note: ‡ Screws must be tightly secured; however, to avoid damage to the mounting plate or device, do not overtighten the screws.

  • Page 18: Using The Remote Control

    SETUP AND INSTALLATION Using the Remote Control Installing/Replacing the Remote Control Batteries The remote control requires installing two AAA batteries to control the OC Hub. IMPORTANT! Replace only with the same or equivalent type batteries. Remove the cover of the battery compartment.

  • Page 19: Remote Control Operating Range

    When using the remote control, make sure to point it within ±30° (horizontally) or ±15° (vertically) to the IR receiver on the OC Hub. The distance between the remote control and the IR sensor window should not be longer than 8 meters.

  • Page 20: Turning On The Oc Hub

    SETUP AND INSTALLATION Turning On the OC Hub The OC Hub is automatically turned on when the power cord is connected to the power outlet. The LED indicator light turns green, indicating it is ready to use. Note: Before powering the OC Hub, ensure that the HDMI cable is securely connected to both the OC Hub and external display.

  • Page 21: Setup Wizard

    SETUP AND INSTALLATION Setup Wizard The Setup Wizard will appear on the screen when you turn on your OC Hub for the first time. Select the language for the on-screen display (OSD) menu. Then select Next to continue. If you want to connect your OC Hub to the Internet wirelessly, select one of the available networks and select Connect.
  • Page 22 Configure the date and time related settings. Then select Next to continue. Read Optoma’s legal policies, including Terms and conditions of use, Privacy policy, Cookie policy, and Open Source and Third party software license. Check the I agree to Terms and conditions, Privacy policy, Cookies policy and Open source radio button, and then select Next to continue.
  • Page 23 To install the Display Share app on your mobile device, scan the QR code shown on the screen. Then select Next to continue. To begin setting up OMS, select Start and follow the on-screen prompts, otherwise select Skip. The OC Hub is now ready to use. For more set up information, please refer to page 71. English...

  • Page 24: Basic Operations

    BASIC OPERATIONS Home Screen Overview Home screen is displayed on the connected display every time you start the OC Hub. Sign in to Whiteboard Wireless display verification code from Current date and time Apps shortcuts Display Share Remote Annotation function...

  • Page 25: Osd Menu

    BASIC OPERATIONS OSD Menu To open the OSD menu and configure the settings, you can use the remote control. Main menu Submenu Settings Operation/Action Using the Remote Control Open the OSD menu Press the button Select an item Press the p or q button Enter the submenu Press the u button Adjust the setting...

  • Page 26: Shortcut Menu

    BASIC OPERATIONS Shortcut Menu Shortcut menu is the first OSD menu. Complete the following steps: ‡ Select the input source. Those input sources that are available are marked with the DOT ● symbol. Note: For more information on setting up connections with external devices, refer to the “Connecting Other External Devices”...

  • Page 27: Configuring Audio Settings

    ‡ Select the Volume slider bar and press the t or u button to adjust the volume level. Viewing OC Hub Information In the OSD menu, select to open the Information menu, then complete the following steps: ‡...

  • Page 28: Android Settings Menu

    BASIC OPERATIONS Android Settings Menu To open the Settings menu, select on the Home screen and press the button on the remote control. Note: ‡ You can also access the Settings menu by pressing the button on the remote control. ‡...

  • Page 29: Personalizing The System

    BASIC OPERATIONS Personalizing the System In the Settings menu, select to open the Personalized menu, then complete the following steps: ‡ Select Wallpaper and select a pre-loaded image as a wallpaper or an image from your gallery. If you select a pre-loaded wallpaper from the Pictures folder, the setting will take effect immediately. If you prefer to use a customized wallpaper, follow these steps: a) In the Custom folder, select b) Select your preferred image from the local or external storage and select OK.

  • Page 30: Configuring Network Settings

    For more information, refer to page 15. ‡ Select Wi-Fi to connect the OC Hub to the Wi-Fi network and view current connection status. Make sure the Wi-Fi function is enabled. In the Available network list, select your preferred Wi-Fi network, for example XXXX.
  • Page 31 For a secure connection, set the Wi-Fi encryption (Security field) as WPA2-PSK. Then enter the access password and select OK. ‡ Select Bluetooth to enable Bluetooth and connect to other nearby Bluetooth devices. The OC Hub supports Bluetooth version 5.2 and can connect with compatible Bluetooth devices, such as a keyboard, mouse, and speaker.

  • Page 32: Configuring Device Settings

    BASIC OPERATIONS Configuring Device Settings In the Settings menu, select to open the Device menu, then complete the following steps: ‡ Enable HDMI out encryption setting to enable or disable encrypting HDMI out signal with HDCP. Note: If the connected monitor does not support HDCP, disable HDMI out encryption function. ‡...
  • Page 33 BASIC OPERATIONS ‡ Select Apps to view apps information, clear apps data and cache, and force stop apps. Select an app in the list to force stop it (select Force stop), view its storage and clear its data (select Clear data) and cache (select Clear cache), view app version and set permissions.

  • Page 34: Configuring Security Settings

    BASIC OPERATIONS Configuring Security Settings In the Settings menu, select to open the Security menu, then complete the following steps: ‡ Select Advanced Setting to set or modify the Advanced Setting password and enable or disable settings available in the Advanced Settings menu. Do the following: Note: The DEALER menu advanced settings can be also accessed with the Advanced Setting password set in this menu.
  • Page 35 - Select Unknown source and enable or disable installing third party software from an unknown source. - Select Install app from marketplace and enable or disable whether or not to show the app icon to access the Optoma Marketplace. 3rd party apps installation - Select Uninstall App and enable or disable uninstalling third party software.

  • Page 36: Configuring System Settings

    Select Keyboard to view and manage keyboards. ‡ Select Startup and Shutdown to configure settings related to starting and shutting down the OC Hub. Select any of the following: - Startup Input Source item to select one of the available startup input options: Last shutdown input, Android, HDMI1, or Type-C.
  • Page 37 BASIC OPERATIONS ‡ Select Power to configure power settings. Select any of the following: - Signal Power On to enable or disable starting up the device when an input signal is detected. - Wake on LAN to enable or disable remotely starting up the device over LAN. Note: Wake on LAN can’t work and will be gray out when Power Mode (Standby) is set to Active.
  • Page 38 BASIC OPERATIONS ‡ Select Update to configure upgrading options. Select any of the following: - OTA (Over-The-Air) Software Upgrade to enable or disable upgrading software over Internet. Select Check update when power on to check for update file from the Internet when power on. Select Auto Download to enable downloading update files automatically when power on.
  • Page 39 USB 3.0 port does not support the software upgrade via a USB flash disk. ‡ If you upgrade the OC Hub’s firmware from a USB storage, uncompress the upgrade file first and then copy the uncompressed file to the USB root directory. Make sure the USB flash disk is formatted as FAT32.

  • Page 40: Side Toolbar

    BASIC OPERATIONS Side Toolbar Press the button to hide the > icon on the left side of the screen. Then press the button to open the side toolbar. Side toolbar Use the p or q button to select one of the available option. Then press the button to confirm.

  • Page 41: Viewing Recent Tasks

    BASIC OPERATIONS Viewing Recent Tasks Select to view and manage all opened apps. ‡ To open the app, select the app you want to launch and press the button ‡ To close the app, select in the app window. English...

  • Page 42: Screen Recorder

    BASIC OPERATIONS Screen Recorder Select to open screen recording utility. This utility helps you to record video from the connected display panel screen and connected camera screen (if enabled). Note: ‡ You can drag the recording utility to your preferred location on the screen. ‡...

  • Page 43: Annotation App

    BASIC OPERATIONS Annotation App Select to open the annotation app. In this mode, you can do the following: ‡ Select Pen ( ) to write and draw on the screen. Note: You can change the pen color and thickness by clicking the u icon next to the Pen( ‡...

  • Page 44: Screen Capture Tool

    BASIC OPERATIONS Screen Capture Tool Select to open the screen capture tool. To capture the screen, do the following: Select either Freedom ( ) or Full ( ) to manually select the area or to capture the entire screen respectively. Select Save ( ) to save the screenshot.

  • Page 45: More Tools

    BASIC OPERATIONS More Tools Tap > ⇒ to access more tools such as Spotlight, Timer, Stopwatch, and Freeze. to activate Spotlight. Spotlight can be used to direct the audience’s focus to a specific part of the ‡ Select board. ‡ Select to use the Timer.

  • Page 46: Remote Annotation Function

    BASIC OPERATIONS Remote Annotation function From the homescreen, select to activate the remote annotation function. With this function, you can remotely annotate on documents presented on the display screen with your mobile or desktop devices. This creates a two way interactive working environment. Note: You can also access this function in Display Share app.
  • Page 47 BASIC OPERATIONS ‡ Select to highlight the item on the screen. Note: To change the highlighter color and thickness, click and set the desired settings. ‡ To erase areas of your written texts or drawings on the screen, select Note: To change the eraser thickness, click and set the desired settings.

  • Page 48: Using The Apps

    Optoma support in rectifying any issue which may result from the installation of third-party apps will be chargeable and may be limited. Information is correct at the time of writing and is subject to change.

  • Page 49: Display Share

    Wi-Fi or LAN. IMPORTANT! ‡ The OC Hub and your mobile device/computer must be connected to the same Wi-Fi or LAN network. ‡ While in use, make sure that you have access to the Internet.

  • Page 50: Mobile Device

    When the setup guide screen appears, scan the QR code to download and install the Display Share app onto your mobile device. To connect to the OC Hub, complete the following steps: Note: The connection steps are described based on an iOS device.
  • Page 51 USING THE APPS Tap Start Broadcast (only for iOS device). Enter the Display Share verification code from the launcher screen to establish the connection. English...
  • Page 52 USING THE APPS Tap any of the following: ‡ Mirroring to mirror your mobile device’s screen to the connected display panel. Note: Support up to 4 users at the same time. ‡ Photos to view and share photos. Camera to stream your mobile device’s camera to the the connected display panel. ‡...

  • Page 53: Computer

    USING THE APPS Computer You can mirror the screen of your computer via Chrome browser or Display Share. To use either of these options, open the browser and enter to the URL field the IP address that is displayed on the launcher screen. For example, http://192.168.50.205.
  • Page 54 USING THE APPS Note: ‡ If you want to share audio during screen casting, click on the screen. ‡ The user name that you enter for screen casting will also be used in Moderation mode. ‡ To stop sharing, click Stop sharing or click on the screen.
  • Page 55 USING THE APPS To start screen casting from the desktop app, download the Display Share to your computer. Launch the app and click on the device name. ‡ If the device is not visible in the Room List, enter the device’s IP address manually to the Input IP address field.
  • Page 56 USING THE APPS Click any of the following: ‡ Mirroring to mirror your computer’s screen to the connected display panel. ‡ Remote View to mirror the connected display panel screen to your computer with annotation and image saving feature. ‡ to select up to 4 screens to display on the connected display panel.
  • Page 57 USING THE APPS Select the screens to display. To exit the moderation mode, click Leave. English...

  • Page 58: Display Share Settings

    USING THE APPS Display Share Settings and then select any of the following icons to configure the Display Share launcher screen settings: Select ‡ to activate the remote annotation function. For more information about the function, refer page 46. ‡ to share the screen to other devices.

  • Page 59: Whiteboard

    Before using this app, ensure that a mouse is properly connected to the OC Hub. Note: The remote control is not workable with this app.
  • Page 60 USING THE APPS Item Description Write or draw a freeform line. Select to select the desired line color and thickness. - Select to modify the color palette. You can select five palette colors based on the Pen / Highlighter theme or select them individually. Erase areas of your written texts or drawings.
  • Page 61 USING THE APPS Item Description Draw a geometric shape. Select the desired 2D, 3D shape with several color options, use a ruler to measure distances and draw lines, or use a protractor to measure and draw angles. Geometric shape Select any of the following tools: ‡...
  • Page 62 QR Code to share the file with QR code. Share Note: Before scanning the QR code to download the file, make sure the OC Hub and your mobile device are connected to the same Wi-Fi network. ‡ Email to send the file by email.
  • Page 63 “Template” tab, upload your own from an image file using the “Upload” tab, or go to the “Image Folder” tab to choose from other image files available from the image folder on the internal storage of your OC Hub. Background...
  • Page 64 USING THE APPS Item Description The default session name is “Untitled session”. To rename the session, select and type in a new name at the prompt. Then select Save. Note: ‡ You can also rename the session on the Whiteboard Home tab. Session name Select the session and then select ⇒...
  • Page 65 USING THE APPS Item Description Invite attendees from your Google Classroom class list to join the Whiteboard session. On the Attendees tab , select and then select any of the following options: ‡ Through Google Classroom ‡ By sending an email invitation with the session password ‡...

  • Page 66: File Manager

    USING THE APPS File Manager File Manager Select File Manager to manage files and folders. Note: You can also access the File Manager app by pressing the button on the remote control. Managing Files Select a storage location and browse for a file or folder you want to view then press the button to open a file or folder.
  • Page 67 Share item(s) between the OC Hub and your mobile device over web browser. Share item(s) Note: ‡ By default, all items that you upload to the OC Hub are saved to the Download folder. ‡ For item(s) upload, make sure your mobile device is connected to the same network as the OC Hub.

  • Page 68: Cloud Storage

    USING THE APPS Cloud Storage Select File Manager ⇒ Cloud Storage to create an account or use an existing account to access your cloud storage. To create an account: Select or Add account. Select the drive type. Follow on-screen instructions to create an account or sign in to your existing account. After successful login, you are prompted to set a security PIN.
  • Page 69 USING THE APPS Your account will be listed in the Cloud Storage menu. To manage your cloud storage account(s) in the File Manager, select any of the following: ‡ to add another cloud storage account. ‡ to lock the cloud storage account. ‡...
  • Page 70 USING THE APPS A confirmation message appears on the screen. Select Setup to continue. Enter a PIN code (4-digit number) in the Enter a new PIN field, then re-enter the same 4-digit PIN in the Enter the PIN again field to verify your new PIN. Your new PIN has now been set up.

  • Page 71: Optoma Management Suite (Oms)

    LED displays, and OC Hub enabling easy integration into existing display fleets while offering differing levels of access and control for users, ensuring devices are securely managed.
  • Page 72 On the Optoma Management Suite website, add a new device into the OMS system. Select Device > + > Start and enter the serial number of the OC Hub. Then select Next to continue. Confirm the PIN codes on both the launcher screen and web browser. If the codes match, select Confirm on the OMS launcher screen.
  • Page 73 After pairing is successful, enter the device name and select Done. Use OMS to manage your OC Hub. For more information on OMS, refer to https://onlinemanual.optoma.com/oms-en/bindingdevice. Note: To unpair your OC Hub from the paired account, select Unpair on the launcher screen. English...

  • Page 74: Chromium

    USING THE APPS Chromium Chromium Select Chromium to access web pages. Note: You can also access the Chromium app by pressing the button on the remote control. English...

  • Page 75: Optoma Marketplace

    USING THE APPS Optoma Marketplace Optoma Marketplace Select Optoma Marketplace to visit the built-in app store and to download and install other third-party apps to the device. Note: To install third-party apps, make sure the Install app from marketplace option is enabled in the Settings ⇒...

  • Page 76: Officesuite

    USING THE APPS OfficeSuite OfficeSuite Select OfficeSuite to edit and manage any document format including PDF, Microsoft Word, PowerPoint, and Excel files. Note: You can also open the document directly from File Manager. Refer to page 66. English...

  • Page 77: Additional Information

    ADDITIONAL INFORMATION Specifications Item Description ‡ Dual-core Cortex-A72 up to 1.8GHz ‡ Quad-core Cortex-A53 up to 1.4GHz Storage 32GB Operating System Android 10 DC Input 12V/1.5A I/Os 1x HDMI IN Support up to 4K 30Hz 1x HDMI OUT Support up to 4K 60Hz 1x RS232 (3.5mm mini jack) Adaptor cable for 3.5mm mini jack to RS232(female) 1x RJ45 (with POE function)

  • Page 78: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your OC Hub, please refer to the following information. If a problem persists, please contact your local reseller or service center. No picture or sound on the connected display. ‡ Make sure all signal and power connections are properly connected.

  • Page 79: Optoma Global Offices

    ADDITIONAL INFORMATION Optoma Global Offices For service or support, please contact your local office. Japan Optoma Technology, Inc. 888-289-6786 https://www.optoma.com/jp/ 47697 Westinghouse Drive. 510-996-4794 Fremont, Ca 94539 services@optoma.com Taiwan https://www.optoma.com/tw/ Canada Optoma Technology, Inc. 888-289-6786 China 47697 Westinghouse Drive. 510-996-4794...
