INSTALLATION INSTRUCTION
BEFORE YOU BEGIN
Read and follow all safety
instructions
RISK OF FIRE, EXPLOSION AND ELECTRIC SHOCK
• This product should be installed, inspected, and maintained by a qualified electrician only,
in accordance with the NEC (National Electric Code) and all local codes.
• Turn off electrical power before inspection, installation or removal.
• Use only UL (or other NTRL) approved wire for input/output connections.
• Make sure LEDs and drivers are cool to touch when performing maintenance.
Make sure the supply voltage is the same as the rated voltage of the luminaire.
• Do not install in a hazardous atmosphere, except where the ambient temperature does
not exceed the rated operating temperature of the fixture.
• Keep tightly closed when in operation
Prepare Electrical Wiring
Electrical Requirements
Must check if the local voltage range is correspond with the working voltage of the fixture. Use min. 75ºC
supply.
Grounding Instructions
The grounding and bonding of the overall system shall be done in accordance with NEC Article 600 and
local codes.
Follow all applicable safety procedures and use Personal Protective Equipment such as hardhats, safety
glasses, reflective vest, electrical safety gloves, fall protection equipment and safety toe boots during the
installation, operation, and maintenance of the luminare.
* Any damage caused from improper installation will void warranty and not be accepted for RGA (Return
Goods Authorization). Improper installation includes but not limited to field-drilled hole(s), improper latch
closure and any damage caused during installation.
Contractor is responsible for adequately reinforcing ceilings to support luminaire weight. Alcon Lighting
accepts no responsibility for inadequately reinforced ceilings. The information contained in this drawing
is the sole property of Alcon Lighting.
Any reproduction in part or whole without the written permission of Alcon Lighting is prohibited and
warranty is voided.
AlconLighting.com © 2022
( 877) 733-5236
(
■
WARNING
products@alconlighting.com
■
1/3
Advertisement
Summary of Contents for ALCON 11411-SF
- Page 1 The information contained in this drawing is the sole property of Alcon Lighting. Any reproduction in part or whole without the written permission of Alcon Lighting is prohibited and warranty is voided. AlconLighting.com © 2022 ( 877) 733-5236 products@alconlighting.com...
- Page 2 LINE DRAWING 1/2" NPS Knuckle Mount [ FIG.1] Thread knuckle into the 1/2" NPS hole and secure it with 1/2" locknut. Make electrical connections from the supply Silicon rubber ground (L/N/GND) lead to fixture ground (L/ waterproof gasket N/GND) lead respectively. Make sure to Screw follow all National Electrical Code and all 1/2'' NPS...
- Page 3 The information contained in this drawing is the sole property of Alcon Lighting. Any reproduction in part or whole without the written permission of Alcon Lighting is prohibited and warranty is voided. AlconLighting.com © 2022 ( 877) 733-5236 products@alconlighting.com...
