- Page 1 OPERATING MANUAL - BA05.24 Hydrolog HLF4 Data logger with data remote transmission for water level recording...
-
Page 2: Table Of Contents
Revision ................................... 18 Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 3: About This Document
[04-5] Exemplary notice to a type variant (>> chapter Product description - Product code) 1.3. Other documents Besides this document the following material can be found on the Internet at www.acs-controlsystem.com: • EU Declaration of Conformity (current version) • Manufacturer declarations •... -
Page 4: Safety Instructions
The associated EU-Declaration of Conformity can be ordered or downloaded from the homepage. Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 5: Product Description
The connected sensors, analogue with current signal 0/4…20mA or digital RS485 Modbus RTU or impulse / switch input are supplied by the device with energy and the recorded measurement values are stored internally loss-protected. The data transmission of the measuring values to the ACS-Web-Portal or to an FTP server is made automatically per mobile communication. -
Page 6: Product Label
LTE-M, NB-IoT, EGPRS / Bluetooth® 5.2 Electronic – Input 2x Ai 0/4…20mA / 2x Ci RS485 / 1x Di Tariff Separate billing / without XS1B ACS DataComplete XS, Basic XS1S ACS DataComplete XS, Standard XS1P ACS DataComplete XS, Premium ACS DataComplete S, Basic... -
Page 7: Packaging, Transport, Storage
Not exposed to corrosive media Protected against solar radiation • • Avoiding mechanical shock and vibration • Storage and transport temperature -20…+85°C • Relative humidity 20…85% ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 8: Accessories
Strain relief sensor (total sensor weight > 1kg) 611000549 Adapter plate for 3" / 4" ACS level caps, outer diameter 107.5mm 611000550 Adapter plate for 4 1/2“ / 5“ ACS level caps, outer diameter 136mm 611000551 Adapter plate for 6“ ACS level caps, outer diameter 158mm 611000578 Pole/wall mount for solar module SM10W01, tiltable -5...+30°, tube diameter 30...63mm... -
Page 9: Installation
NOTE Suspension sensors from ACS with electrical connection option H - cable assembly Hydrolog and length L1, in combination with the data logger, result in the installation length L1 based on the hanging edge of the level tube cap or adapter plate. -
Page 10: Electrical Connection
Input / output Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 11: Auxiliary Power Supply
Battery replacement required when battery is low. the DC supply fails. The rechargeable battery is recharged via the DC supply. Battery (D/DD) Li-ION Li/SOCl2 4,2V 3,6V 7..32V 7..32V ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 12: Transmitter Power Supply - Uo1/Uo2/Uo3/Uo4
Di1 – Switch / Counter Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 13: Operation
ACS-SmartConnect. By using your own SIM card, you lose the ability to transfer the data to the ACS WEB portal and thus also all the functionalities of the WEB portal. The collected measured values are then transferred to an FTP server to be provided by the user. -
Page 14: Error Diagnosis And Troubleshooting
Insert the plug of the battery connecting cable into the socket (6). Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 15: Repair
Disposal As required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), products of ACS are marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Such products may not be disposed of as unsorted municipal waste and can be returned to ACS for disposal. -
Page 16: Technical Data
Connector SMA / 50Ohm Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... -
Page 17: Data Logger
Operation device class B / Industrial range (EN/IEC 61326) Altitude above sea level 2000m above sea level MTTF 258 years Weight 0,9kg 10.6. Materials Processwetted PA, aluminum/PES lacquered, PUR, brass, nickel, silicone, NBR ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0... -
Page 18: Revision
Option [04-5] - LTE-M1, LTE-NB2, EGPRS Y O U R P A R T N E R F O R M E A S U R E M E N T & A U T O M A T I O N www.acs-controlsystem.com... - Page 19 ACS-CONTROL-SYSTEM GmbH | Lauterbachstr. 57 | 84307 Eggenfelden | Germany info@acs-controlsystem.de | +49 (0) 8721/9668-0...
- Page 20 FEEL FREE TO CONTACT US ACS-CONTROL-SYSTEM GmbH Lauterbachstr. 57 84307 Eggenfelden - Germany info@acs-controlsystem.de www.acs-controlsystem.com +49 (0) 8721-9668-0 Y O U R PA R T N E R F O R M E A S U R E M E N T & A U T O M AT I O N...
