R1 ELECTRIC BICYCLE INSTRUCTION MANUAL

�

Table of Contents

Need help?

Do you have a question about the R1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ridel R1

Page 1 R1 ELECTRIC BICYCLE INSTRUCTION MANUAL �...
Page 2: Table Of Contents
Contents Before You Ride ----------------------------------------------------------------------------------------------- 6 Safety Checklist----------------------------------------------------------------------------------------------- 8 Throttles ------------------------------------------------------------------------------------------------------ 10 Battery Care -------------------------------------------------------------------------------------------------- 11 Assembly ----------------------------------------------------------------------------------------------------- 12 Parts ------------------------------------------------------------------------------------------------------------ 13 Pedal & Crank Set -------------------------------------------------------------------------------------------14 Front Wheel - Quick Release ------------------------------------------------------------------------------14 Rear Wheel - Bolt-on Installation ----------------------------------------------------------------------- 15 Rear Wheel - Bolt-on Removal----------------------------------------------------------------------------16 Disc Brakes - Tektro------------------------------------------------------------------------------------------17 Derailleur Systems------------------------------------------------------------------------------------------ 18...
Page 3 FULLY CHARGE BATTERIES BEFORE FIRST USE - Batteries should be fully charged immediately when they are received and immediately after each use for the recommended charge times (see below). • Li-lon (Lithium Ion) batteries 4-6 hours We recommend that you consult a bicycle specialist if you have doubts or concerns as to your experience or ability to properly assemble, repair or maintain your bicycle.
Page 4 �...
Page 5 LCD Screen Display Indication of mileage speed, mileage, gear, headlight and PAS. Fault Warning. Function Setting, etc. �...
Page 6: Before You Ride
�...
Page 7 Your new bicycle was partially assembled in the factory and then partially disassembled for shipping. You may have purchased the bicycle already fully assembled and ready to ride OR in the shipping carton in the partially disassembled form. The following instruction will enable you to prepare your bicycle for years of enjoyable cycling. For more details on inspection, lubrication, maintenance and adjustment of any area please refer to the relevant sections in this manual.
Page 8: Safety Checklist
SAFETY CHECKLIST Before every ride, it is important to carry out the following safety checks: 1. Brakes • Ensure front and rear brakes work properly. • Ensure brake shoe pads are not over worn and are correctly positioned in relation to the rims. •...
Page 9 6. Cranks and Pedals • Ensure pedals are securely tightened to the cranks. • Ensure cranks are securely tightened to the axle and are not bent. 7. Derailleurs • Check that front and rear mechanisms are adjusted and function properly. •...
Page 10: Throttles
Throttles Throttles are equipped on some models of electric bicycles. Throttles operate by rotating the throttle towards the rider much like a motorcycle. They generally are the inner half of the right side handlebar grip and may also contain a battery gauge. The more Control Adjustment you twist the throttle, the faster the motor system will propel the Throttle...
Page 11: Battery Care
• Ridel bikes and scooters are equipped with a ve-minute sleep function. If no activity is detected after ve minutes, the bike/scooter will go into “stasis” mode to conserve battery power. Simply cycle the bike/scooter o then on again to re-activate the battery.
Page 12: Assembly
Assembly Guides Individual assembly guides for each bicycle model can be found packaged with your bicycle. Getting Started Open the carton from the top and remove the bicycle. Remove the straps and protective wrapping from the bicycle. Inspect the bicycle and all accessories and parts for possible shortages. It is recommended that the threads and all moving parts in the parts package be lubricated prior to installation.
Page 13: Parts
LCD Screen Accelerator Double Suspension Fork Removable Batter y Controller Place Saddle Rear Turn Light Front Disc Brake Rear Hydraulic Suspension Crank Pedal �� W Motor Speed Flywheel Chain ��...
Page 14: Pedal & Crank Set
Pedals & Crank Set Look for the letters “R” for right, and “L” for left, stamped on each pedal spindle. Start threading each pedal by hand to avoid stripping the threads. Tighten with a 15 mm narrow open ended wrench. Note that the right hand pedal attaches to the chain wheel side crank arm with a right-handed (clockwise) thread.
Page 15: Rear Wheel - Bolt-On Installation
3. Install the wheel into the dropouts, making sure the quick release lever is on the left side of the bicycle. 4. Holding the quick release lever in the OPEN position with one hand, tighten the tension adjusting nut with your other hand until it is nger tight against the fork dropout.
Page 16: Rear Wheel - Bolt-On Removal
Rear Wheel - Bolt-on Removal ��...
Page 17: Disc Brakes - Tektro
Disc Brakes - Tektro 1. Check the tightness of the six disc mounting bolts holding the brake rotor onto the wheel. If you need to remove these bolts, be sure to use a thread-locking compound when re-installing them. 2. Make sure the bolts securing the caliper adaptor bracket to the fork are tight.
Page 18: Derailleur Systems
Disc brakes require breaking in. Ride and use the brakes gently for about 13 miles before using the brakes in downhill conditions, for sudden stops, or any other serious braking, Please be aware that your brake system will change in performance throughout the wear-in process.
Page 19: Final Check
Final Check ��...
Page 20: Maintenance
Correct routine maintenance of your new bike will ensure smooth running - Longer lasting components - Safer riding - Lower running costs ��...
Page 21 Drive Train The drive train of a bicycle refers to all parts that transmit power to the rear wheel including the pedals, chain, chain wheel, crank set and freewheel. Pedals Pedals are available in a variety of shapes, sizes and materials, and each are designer with a particular purpose in mind.
Page 22: Porblem Solving
��...
Page 23 ��...
Page 24 ��...
Page 25: Warranty Policy
Warranty Policy For Electric scooter after-sales service, contact the distributor at: https://ridelbikes.com/pages/ridel-bikes-support Category Maintenance Contents Starting Time Frame Assembly, Front Wheel, Rear Wheel, Motor, Handlebar Assembly, Steering Tube, Chassis, Disc Brake, Disc Brake Caliper, Machine Body One Year Folding Handle, Front Fork Assembly, Controller Unit, Display Unit...
Page 26 Warranty Claims and Technician Service Procedures 1. Warranty claims must be within the warranty period. 2. Any returns must be made in the original packaging. Shipping products in packaging other than the original may affect its operation. 3. Proof of purchase such as receipt or order number must be provided for warranty claims. 4.
Page 27 Contant Us: Ridel Group LLC 20-21 Wagaraw Road Building #30 Fair Lawn, NJ 07410 Call: 513-813-0708 Email: support@ridelbikes.com www.ridelbikes.com...
