Thank you for purchasing the Performance Hutch Organizer (Black).
1
Cam Lock
8 Pcs
A
Back Panel
1
Line up Cam Lock,
turn clockwise.
IMPORTANT !!
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
Check that you have all parts and hardware.
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten any screws or bolts until the unit is completely assembled.
Keep all hardware parts out of reach of children.
Please follow these instructions for easy assembly.
2
3
Klix Cam
8 Pcs
B
C
Left Gable
Right Gable
KLIX CAM INSTRUCTIONS
2
Insert the Klix with the arrow
pointing towards the hole in the
4
Housing Cap
Allen Key
8 Pcs
1 Pc
D
E
Top Panel
Bottom Panel
3
Insert the Cam Lock into Klix
Cam. Turn Klix Cam to lock.
edge.
PL 122GG-A1
HUTCH ORGANIZER (BLACK)
5
Shelf Support Pin
20 Pcs
F
Adj. Shelf x 5pcs
PAGE 1 OF 2
