- Page 1 Mounting instructions for CoBrite Into CBDX4-19-x 19 inch rack mount adaptor E-Mail: info@id-photonics.com www.id-photonics.com ID Photonics GmbH, Neubiberg, Germany V1.0...
- Page 2 ____________________________________________________________________ 1 Remove Side holders and cramps at edge from Tray holder using a Hex Driver (2.5mm) CoBrite Mounting instructions CBDX4-19-x...
- Page 3 ____________________________________________________________________ 2 Remove plastic caps from both sides of laser handle using a small screwdriver 3 Remove plastic caps at lower rear end of laser chassis using a small screw driver CoBrite Mounting instructions CBDX4-19-x...
- Page 4 ____________________________________________________________________ 4 Detach laser chassis handle by removing screw inside handle hole using an appropriate screwdriver CoBrite Mounting instructions CBDX4-19-x...
- Page 5 ____________________________________________________________________ 5 Reuse Handle screw to fix side holders onto laser chassis into center thread CoBrite Mounting instructions CBDX4-19-x...
- Page 6 ____________________________________________________________________ 6 Slide Laser chassis into Tray so that laser chassis faceplate protrudes through faceplate of adaptor tray 7 Fix laser chassis by screwing cramps and side holders to tray CoBrite Mounting instructions CBDX4-19-x...
- Page 7 ____________________________________________________________________ 8 Done! ;-) CoBrite Mounting instructions CBDX4-19-x...
