Summary of Contents for Right On TS-796D
- Page 1 Revision: C TS-796D Dolly Trailer Brackets Approximate Assembly Time Shipping Weight: 26 lbs 1/2 hour Parts List & Assembly Instructions...
-
Page 2: Exploded Parts View
The tools you will need: - box wrenches (16mm, 17mm) - sockets (16mm, 17mm) - measuring tape EXPLODED PARTS VIEW... -
Page 3: Assembly Steps
T railer Part s Hardw are No. Item No. Item Brace Bolt M10 x 25 Orientation Bar Bolt M10 x 65 Handle Bracket Bolt M10 x 70 Roller Base Bolt M10 x 90 Roller Bolt M10 x 1160 Left Wheel Bracket Nut M10 (nylon lock) Right Wheel Bracket Flat Washer M10... - Page 4 STEP 1 (continued): Assemble the front Roller (5) into the front Roller Base (4) using a Bolt M10 (E), M10 Flat Washer (G), and M10 Nut (F) as shown. Grease can be applied to Bolt (E) to reduce rolling friction. Assemble the rear Roller Base (4) and Roller Spacer (8) to the Cross Member using Bolt M10 (B), M10 Flat Washer (G), and M10 Nut (F) as shown.
- Page 5 1. Flip-down dolly gunwale supports if present. Tie bow of boat to dolly as shown below. JOTAG dolly Seitech dolly 2. Move Right-On Trailer to flat open area and hitch to vehicle or chock both tires. Roll dolly to rear of trailer and set dolly tongue on rear roller. 3.
- Page 6 4. Lash handles of dolly to front bracket as shown. Dynamic dolly JOTAG dolly 5. Use a nylon ratchet strap across the wheel brackets to secure the boat/ dolly to the trailer. Secure the strap tightly so the dolly tires slightly compress into the wheel brackets.
