M20 Astronaut DODO Smart Bluetooth Speaker
We reserve all patents, trademarks, copyrights and other
intellectual property rights
If the product function parameters are changed without notice,
the product is subject to the actual product
Product parameters:
Product name: Astronaut DODO smart bluetooth speaker
Model: M20
Product material: ABS PC silicone
Audio output power: 6W (RSM).
Frequency response range: 50HZ-20KHZ
Bluetooth version: Jie Li 5.1 + EDR
FREQUENCY: 2.4-2.48GHZ
Receiving distance: 5-15M
Charging voltage: DC 5V
1A
Battery capacity: 1800mAh
Color: milk tea white
pink
girl
SPECIFICATIONS: 170*120*100MM
Product features: AI voice intercom
connection playback Bluetooth
Bluetooth
hands-free call
display
clock
Alarm setting Night light TF
playback FM radio USB sound card
card
Receiving distance: 5M-15M (barrier-free
depending on the
receiving distance,
environment and equipment, the receiving distance is different
)
.)
(Note: The above configuration data will be continuously improved
according to the main control upgrade, and the specific content shall
prevail)
Packaging accessories
Package contains:
Astronaut DODO smart bluetooth speaker user manual 1 copy warranty card certificate 1
servings
1 high-speed TYPE-C-USB power cable
Advertisement
Summary of Contents for Zeblaze DODO Astronaut M20
- Page 1 M20 Astronaut DODO Smart Bluetooth Speaker We reserve all patents, trademarks, copyrights and other intellectual property rights If the product function parameters are changed without notice, the product is subject to the actual product Product parameters: Product name: Astronaut DODO smart bluetooth speaker Model: M20 Product material: ABS PC silicone Audio output power: 6W (RSM).
-
Page 2: Chapter 1: Product Function Key Description
Chapter 1: Product Function Key Description 1. Function key introduction and operation: M key on/off: Long press the M key to turn on, hear the boot prompt tone after the product boots, and default Bluetooth mode, Bluetooth search within 10 minutes do not pair the phone, Bluetooth will enter the low-power mode, you need to click the ,M key to activate the Bluetooth search status. -
Page 3: Chapter 2: Operating Instructions
(This product sets the alarm clock second wake-up function, when the alarm sounds, if you do not manually turn off the alarm will be 5, Again in minutes) +AND AFTER key Long press + key volume plus, long press - key volume down, short press - key- on the song. - Page 4 Follow the official account to view the tutorial1 Bluetooth connection and download APP Open the phone's Bluetooth, find the device with the name: "Astronaut DODO Smart Bluetooth Speaker" and connect Search for "Xiaoyun Assistant" in the mobile app store or scan QR code above to follow the WeChat public account to view the tutorial and...
- Page 5 ● Massive online content ▶ Music Rich QQ music resources, copyright is still in the library; Can meet singers, song on-demand and inquiries; The playlist that matches the application scenario can say: "Hello Xiaoyun", after Xiaoyun replies, you can say "...
- Page 6 Chapter III: Troubleshooting Multiple connections and pairings are unsuccessful Turn off the speaker and turn the phone back on, and make sure the connection name is: Astronaut DODO Smart Bluetooth Speaker There is a stutter in music playback a. Whether the connection distance is out of range or there is an obstacle between the speaker and the mobile phone;...
- Page 7 maintenance, replacement, return (referred to as three guarantees), please read the following: three-guarantee principle of who sells who is responsible, . According to the if the product has a quality problem, contact the dealer with the (warranty card), the dealer provides services to the customer, and our company provides service support to the dealer;...
- Page 8 -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction Chapter 6: Safety Guidelines If consumers use power adapters for power supply, they should use power...
