Karlik DRT-3.1 User Manual

USER'S MANUAL - UNIVERSAL ELECTRONIC WEEK
TEMPERATURE CONTROLLER
Characteristics of the universal electronic week temperature controller
The universal electronic week temperature controller allows you to program up to 9 time intervals per
day and the temperature according to your preferences. The temperature controller allows operation
in the following three modes:
- FLOOR - control of underfloor heating,
- ROOM - control of room temperature,
- LIMITER - room temperature controller with limiter.
Warranty terms
The warranty is provided for a period of 12 months from the date of purchase. The defective controller,
together with the proof of purchase, shall be delivered to the manufacturer or to the dealer. The
warranty does not cover fuse replacement, mechanical damage, defects resulting from self-repair
and improper use of the product.
The warranty period is extended by the duration of the repair.
Notice! Protection class of the shield
The installation must be carried out by a qualified person at de-energized voltage and must comply
with national safety standards. In order to maintain Class II protection, the user must be prevented from
accessing the rear parts of the installation. The mechanism is designed to adjust the temperature only in
dry rooms under standard ambient conditions. The controller meets the requirements of EN 60730. It is
an "independently installed device" operating according to the way 1C works.
Karlik Elektrotechnik Sp. z o.o. | ul. Wrzesińska 29 | 62-330 Nekla | tel. +48 61 437 34 00 | e-mail: karlik@karlik.pl | www.karlik.pl
67,20
number of the current day of the week
indication of the current room temperature
heating/cooling symbol (flashes if the controller
module is not properly connected
or is de-energized)
indication of the current time
operation mode (AUTO)
44,00
1 I 19
