HATOR GAMING SPORT LIGHT Quick Start Manual

PACKAGE CONTENTS
BACKREST x1
SEAT x1
5-STAR BASE x1
SIDE COVER KIT x2
GAS LIFT x1
WHEELS x5
SCREW M8x25 mm x16
LARGE WASHER x16
MAGNETIC RINGS x2
SCREWDRIVER x1
GAS LIFT COVER x1
GROVER x16
SOFT PADS x4
ARMREST x2
ADJUSTABLE MAGNETIC
HEADREST x1
ADJUSTABLE LUMBAR
CUSHION x1
CONVENTIONAL TILT
MECHANISM x1
If you have problems during chair assembly,
please contact us for further instructions.
BACKREST ADJUSTMENT 2D ARMREST ADJUSTMENT
Fully pull the lever up and slowly recline the backrest backward Press and hold the button to adjust the needed height.
to the desired position. When the desired backrest angle is Rotate the armrest around the axis to find a comfortable
reached, slowly release the lever. position.
IMPORTANT TERMS OF USE
1. This chair is intended solely for its intended use.
2. Do not step on the chair or use it as a ladder as it may tip over.
3. When using on a hard floor, be sure to place a mat under the chair to avoid damaging the floor
surface.
4. Use the product on a horizontal surface.
5. This chair is designed for one person use.
6. Move the chair carefully.
7. Do not place the chair near heat sources to avoid surface damage and fire.
8. Avoid direct sunlight on the surface of the chair for a long time.
9. It is strictly forbidden to use the chair in places where flammable items are stored or in rooms
with high humidity.
10. Wipe clean with a soft dry cloth and do not use aggressive detergents.
11. It is forbidden to knock out and disassemble the gas lift and other parts
12. Sit with your clothes on. Avoid getting sweat on the upholstery of the chair.
13. We recommend wiping the chair after the first assembly with an alcohol-free wipe for hygienic
purposes.
Do not attempt to adjust this lever until the backrest is installed. It will
help you avoid the improper operation of the mechanism and injury of the hand
Place the assembled base on the floor and insert the
gas lift with the button up. Please put on the gas lift
cover on it.
Fix the conventional tilt mechanism underneath the seat
base using M8x25mm screws. Soft pads have to be placed
between the mechanism and the seat. Please note - the
rotary knob for adjusting the spring rate must be facing
forward.
To get the fully acces to comfy usage magnet side covers,
please remove the transportation screws from the both
sides. For further chair`s transportation please insert the
screws back or take covers off prior.
SWING ADJUSTMENTS
The swing mode can be adjusted according to your weight. If
the chair does not swing, turn the handle under the seat
clockwise or counterclockwise, adjusting the swing stiffness
to suit you. If the swing stiffness is adjusted correctly, you can
swing easily in the chair.
Remove all chair parts from the box without touching the
backrest adjuster (the mechanism is on the seat). Before
assembling, please check all parts by the checking list.
Take the screw set. Make sure that screws have washers
and grovers. Magnetic rings are provided for two screws.
Install the assembled seat on the gas lift. Ensure
the gas lift fits securely into the hole in the
conventional tilt mechanism.
Put the magnetic top cover on both sides.
CHANGING THE DISTANCE BETWEEN ARMREST
You can change the distance between the armrests. Loosen the
M8 screw at the bottom of the armrest and move the armrest to
the desired position, then tighten the screw in the selected
position.
Take the base and insert the five wheels into the
designated holes.
Fix the two armrests to the seat base using
M8x25 mm screws.
Install the backrest of the chair and secure it with
M8x25mm screws. First, put a groover on the screws,
then a large washer. Start by screwing in the screws
from the side of the right hinge, not tightening them and
avoiding any skew. After that, screw in the left side and
tighten the screws on both sides of the backrest. For the
right side, use two screws with magnetic rings.
Fix the lumbar cushion and snap it on the back
with straps. Place the magnetic head cushion on
the backrest of the chair at a comfort level.
*Product and parts design are for reference only
3
2
1
ADJUSTING THE SEAT HEIGHT AND ROLLING MODE
1 To lower the seat height, turn the lever knob up.
The seat will lower under your weight.
To raise the seat height, stand up and turn the lever up.
The seat will rise.
2 To turn on the swing, pull the lever to the right.
The chair will rock when you lean back.
3 To turn off the rocking and lock the seat, move the lever to the
left, in the direction of the mechanism
