- Page 1 INSTALLATION AND MAINTENANCE MANUAL FOR SWING DOOR SW2C1 SW2A230C1 D113 All technical and commercial documents are available in the DOWNLOAD area of the website www.facespa.it.
-
Page 2: General Safety Instruction
Make sure the existing structure is up to standard in terms of strength and stability. FACE is not responsible for failure to use Good Working Methods in building the frames to be motorised or for any deformation occurring during use. - Page 3 Viale delle Industrie, 74 - 31030 Dosson di Casier (TV) - ITALY Declares that: SW2C1, SW2A230C1. The Product automations for power operated pedestrian swing door type: Has been built for installation on pedestrian door and constitutes a machine in accordance with Directive 2006/42/EC. The manufacturer of the power operated pedestrian door must declare its conformity in accordance with Directive 2006/42/EC (Annex II-A) prior to starting-up the machine.
-
Page 4: Technical Data
2. TECHNICAL DATA Features SW2C1 SW2A230C1 Product dimensions: Height x Depth x Length 82 x 117 x 443 mm 82 x 117 x 443 mm Maximum load: 200 kg x 0,8 m 200 kg x 0,8 m Opening and closing time: 2 –... -
Page 5: Standard Installation
Fix the cover to the heads at the lower holes (or at the lateral holes), using the screws 2,9 x9,5. Rif. Code Description SW2C1 Automation for swing doors (24 Vdc power supply) SW2A230C1 Automation for swing doors (230 Vac power supply) SW2BSC1... -
Page 6: Electrical Connections
To handle electronic parts, wear earthed antistatic conductive bracelets. FACE declines all responsibility in the event of components which are not compatible with the safe and correct operation of the product. - Page 7 6. ELECTRONIC CONTROL ADJUSTEMENT The electronic control has 4 buttons and 4 alphanumeric displays to set all the necessary adjustments. After turning on the electronic control, the display shows the word "MENU". The operation of the four keys are indicated in the table.
- Page 8 Display Description BTMD Setting operation of battery power device, in absence of electricity. Choose between the following values: BATTERY NO (*) = battery not connected MODE EMER = emergency open CONT = continuation of normal operation of the door, with last cycle of opening Note: the number of operations with battery, depends on the efficiency of the battery, the weight of the doors and the present friction.
- Page 9 6.3 MEM (MEMORY MANAGEMENT MENU) Using the buttons ↑ and ↓ select MEM, press ENTER to select and adjust the following parameters. (*) Factory settings. Display Description FSET Restore all settings to factory defaults. Choose between the following values: FACTORY NO (*) = no restore.
-
Page 10: Troubleshooting
DISPLAY WARNING CHECK W001 Encoder error Check encoder connection W002 Motor short circuit Check the connection of the motor W003 Motor control error Electronic control failure W010 Direction reversed Check the presence of obstacles W011 Running too long Check the connection of the belt W012 Running too short Check the presence of obstacles... - Page 11 8. START-UP PROCEDURE OF THE AUTOMATIC SWING DOOR - Preliminary checks. At the end of the installation, move the doors manually and make sure that operation is smooth and without friction. Check the solidity of the structure and the proper attachment of all the screws. Check the correctness of all electrical connections. Make sure you have installed the mechanical stop of the open door.
-
Page 12: Disposal Of Products
DECLARATION OF INCORPORATION (FOR UK MARKET ONLY) The Supply of Machinery (Safety) Regulations 2008, Annex II-B FACE S.r.l. - Viale delle Industrie, 74 - 31030 Dosson di Casier (TV) - ITALY SW2C1, SW2A230C1 Declares that the Product automations for power operated swing door type: Has been built for installation on pedestrian door and constitutes a machine in accordance with The Supply of Machinery (Safety) Regulations 2008.
