Summary of Contents for Zone ORACLE OZ-FDL-11-LIFE
- Page 1 USER MANUAL ORACLE SERIES OZ-FDL-11-LIFE | OZ-FDL-11-R-LIFE OZ-FDL-11-P-LIFE Fingerprint Password Mobile App RFID Card Emergency Key DOWNLOAD NOW WORKS WITH: OzoLife iOS OzoLife Android OzoLife WWW.OZONESECUTECH.COM EMAIL ID: INFO@OZONESECUTECH.COM | CUSTOMER CARE: +91-9310012300...
- Page 2 INDEX Product Introduction Functions Installation Operation Add Lock Factory Reset & Dynamic Passcode Add Unlock Modes Add User 12-13 Features 14-15 Add Gateway Passage Mode Secure Lock Mode 18-19 Initialization and Delete Lock FAQs 21-22 Warranty Card...
- Page 3 P R O D U C T I N T R O D U C T I O N This smart lock is a new type of intelligent door lock. Advanced electronic and biometric technology enables the smart lock to have intelligent recognition capabilities, making work and life easier and more convenient for the users.
-
Page 4: Product Introduction
PRODUCT INTRODUCTION UNLOCK MODES FINGERPRINT UPTO 100 USERS PASSCODE RFID CARD MECHANICAL KEYS OZOLIFE APP POWER SUPPLY 4 AA BATTERIES 15 DIGITS TOTAL SCRAMBLE CODE WORK TEMPERATURE -25~700 C FINGERPRINT TYPE SEMICONDUCTOR EMBEDDED FINGERPRINT DOOR THICKNESS 35MM - 65MM OZ-FDL-11 LIFE BLACK BRONZE COLORS AVAILABLE... - Page 5 SAFETY ASSISTANT FUNCTION PASSAGE MODE When you need to open/close the doors frequently. When the voltage is lower than 4.8V, the alarm is activated LOW BATTERY ALARM each time the lock is unlocked. The lock could be unlocked 200 times, after the first alarm. It supports front and back dummy passcodes SCRAMBLE CODE FUNCTION to prevent from peeking.
-
Page 6: Installation
INSTALLATION PARTS INCLUDED Front Rear Connecting Lock Body Connecting Square Double-headed Handle Handle Screws Screws STEPS TO INSTALL Step 3: Turn square bar and adjust the directon of locatng hole according to door opening direction. Accessories selection table 1.If lock is on the let side of the door from outside Door Thickness Square Bar Connecting Rod... - Page 7 Organize flexible flat Insert 4 AA batteries as per the positive and cable and put it into negative poles. Install Part C and fix the the square hole of part screw tightly. A to avoid the cable Note: Make sure to secure the lock button being crushed.
-
Page 8: Operation
OPERATION REGISTER Click on “Sign Up” and read the Privacy Policy after it pops up. Click on “Agree” to enter the registration page. You can use email or mobile number for account registration. The country/region of the app will be the same as the country/region of your phone. - Page 9 ADD LOCK Tap on Add Device on the home page or “+” on the top right corner of the page to go to the Add Device page. Then, you can manually add devices or search for devices to add to the app. Click on the Touch the After searching...
-
Page 10: Factory Reset
FACTORY RESET Turn Rear Handle left or right, and then press secure lock button, and hold for 10 seconds, accompanied by a continuous beep. After the lock is initialized, all fingerprints, passcodes, IC cards are deleted from lock. DYNAMIC PASSCODE SLIDE Slide your finger on the phone screen on the main interface, as shown in Figure A, and the click"Get dynamic code".You can... - Page 11 ADD UNLOCK MODES In main interface, select “Member Manage- ment”, select “User”, and then select to add door card, fingerprint, or passcode. For example, to add fingerprint: Select “finger” function, then click “+” , and then click “start collecting” to start inputting fingerprint.
- Page 12 ADD USER MEMBERS AND MANAGEMENT Family: The user will enter the family group. And this user will be able to control and use all the products in the family group. Others: The user appears only in the member list of the current door lock and can only perform open lock functions.
- Page 13 FEATURES OPENING RECORD You can check the door logins in the door opening log. The records are arranged in reverse order. The unlock ID that has been associated with a username, will display the corresponding username; while the unlock ID that has not been associated with any username, will display the specific unlock ID. About the Opening Log display: When the door lock is connected to the mobile phone bluetooth, the door opening record will be displayed in the app in real time, apart from being cached locally in the...
- Page 14 DOOR CARD MANAGEMENT Connect the door lock with App through Bluetooth, the administrator can enter the door card for themself or other family members; before adding the door card, select the user corresponding to the added door card and click on "Add door card"...
- Page 15 ADD GATEWAY (OPTIONAL) ADD BLUETOOTH GATEWAY 2.4Ghz Red: The Wi- Fi Light Switch/Reset button Blue: The Bluetooth Light Charging Power on the gateway. Turn on the phone bluetooth and connect to 2.4g Wi-Fi (note that if the router supports both 2.4g and 5G modes, the phone must be connected to a 2.4g network;...
- Page 16 ADD DOOR LOCK TO THE BLUETOOTH GATEWAY THERE ARE TWO WAYS TO ADD BLUETOOTH DOOR LOCK DEVICE UNDER BLUETOOTH GATEWAY Method 1: Method 2: Enter the bluetooth Gateway Device App Select the new device to search, select the panel (as shown in picture 1), select add in "door lock"...
-
Page 17: Passage Mode
PASSAGE MODE To set up Passage Mode ,enter a lock interface and enter the setting menu. Then click Automatic Lock Switch (open or close). * When Automatic Lock Switch is grayed out ,passage mode is open. INTRODUCTION INTRODUCTION OPERATION OPERATION F&Q F&Q APPENDIX... - Page 18 SECURE LOCK MODE ACTIVATE SECURE LOCK MODE Long press secure lock button for more than 3 seconds to activate secure lock mode. a. In this mode, the lock can be opened by the App. b. When you do authorization, App function could be banned.
- Page 19 INITIALIZATION AND DELETE LOCK Confirm that the lock to be deleted is online. Select the lock and hold for a while, then click on “Remove Device”, and click “Confirm” to delete and initialize the lock. (Note: If the lock is offline, you need to slide your finger on the phone screen on the main interface to get the lock online.) INTRODUCTION...
- Page 20 Fingerpeint Reader Card Reading Area Touch Keypad USB Charging Port Mechanical Key Hole Secure Lock Mode Button (Passage Mode Button) Battery Battery Cover INTRODUCTION INTRODUCTION OPERATION OPERATION F&Q F&Q APPENDIX APPENDIX...
- Page 21 FAQS How to read operation records? Select “Opening record” option on lock main interface Why can’t I unlock it after opening the passage mode? You need to perform an unlock verification in any method, only then the passage mode will take effect. What is the purpose of Auto Lock option? You can use it to set how long the lock stays open after unlocking.
-
Page 22: Warranty Card
WARRANTY CARD E-Mail ID Invoice No. Total Quantity... - Page 24 Special Instructions: • Please replace the battery as soon as the low voltage alarm signals it. • Read this manual carefully before installation and keep it safe, for future reference. OzoLife Ozone Secutech Pvt. Ltd. Registered Office: H 40, Bali Nagar, New Delhi - 110015, India Operations Office: Plot No.
