A guide for development tool selection for Programmable System-on-Chip (PSoC) and EZ-Color designs
Cypress Semiconductor has a Development Tool for every need - from entry-level evaluation and
prototyping, to full-speed, real-time emulation and debugging; to programming in a high-volume
manufacturing setting.
Table of Contents
SOFTWARE .......................................................................................................................................... 2
COMPILERS .............................................................................................................................................................. 3
HARDWARE .......................................................................................................................................... 5
DEVELOPMENT AND PROGRAMMING METHODS ........................................................................... 6
-
-
S
IN
SYSTEM
ERIAL PROGRAMMING
-
S
IN
SYSTEM
ERIAL PROGRAMMER
2
-
KITS ..................................................................................................................................................... 10
/
&
/
THIRD PARTY TOOLS ....................................................................................................................... 27
®
& EZ- Color Development Tools Selector Guide
For CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A,
CY8C21x34, CY8C21x23, CY20x34 and CY8CLEDxx
...................................................................................................................................... 2
....................................................................................................................................... 3
................................................................................................................. 7
:
OVERVIEW
(CY3207ISSP)
.................................................................................................. 9
.................................................................................................................. 10
....................................................................................................................... 12
................................................................................................................... 16
................................................................................................................... 18
&
............................................................................................. 20
..................................................................................... 20
................................................................................................ 22
........................................................................................... 23
................................................................................................. 25
Page 1 of 28
............................................................................ 8
.......................................................................... 8
[+] Feedback
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cypress Semiconductor CY8C24x23A
Summary of Contents for Cypress Semiconductor CY8C24x23A
-
Page 1: Table Of Contents
® PSoC & EZ- Color Development Tools Selector Guide For CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A, CY8C21x34, CY8C21x23, CY20x34 and CY8CLEDxx A guide for development tool selection for Programmable System-on-Chip (PSoC) and EZ-Color designs Cypress Semiconductor has a Development Tool for every need – from entry-level evaluation and prototyping, to full-speed, real-time emulation and debugging;... -
Page 2: Tm ....................................................................................................................................... 3
Software Cypress’s PSoC Mixed Signal Array comes with Windows-based software and hardware design tools. Fast, efficient, prototyping and design for embedded systems is now a reality. PSoC software is available at no cost. Download at http://www.cypress.com, and the hardware tools that suit your design needs from evaluation to prototyping and emulation are discussed in the following sections: PSoC Designer At the core of the PSoC development software suite is PSoC Designer. -
Page 3: Ps O C Express Tm
PSoC Express PSoC Express is the first visual embedded system design tool that allows a user to create an entire PSoC project and generate a schematic, BOM, and data sheet without writing a single line of code. Select inputs and outputs Define the output’s behavior Simulate the design to verify Build to generate PSoC HEX file, BOM, schematic, and custom data sheets of your design... -
Page 4: Psoc Programmer
PSoC Programmer PSoC Programmer is a programming application that helps to deliver host-resident application code to the target via a hardware programming tool. Flexible enough to be used on the bench in development, yet suitable for factory programming, PSoC Programmer works as a standalone programming application or it can operate directly from PSoC Designer or PSoC Express PSoC Programmer is the one-stop programming application for Cypress PSoC development tools. -
Page 5: Hardware
Hardware This section introduces the major categories of hardware Cypress offers for development with PSoC. The hardware development for Cypress PSoC falls into five major categories: Demo/Starter Kits, Evaluation Kits, Development Kits, Reference Design Kits, and Programming Kits. Cypress Semiconductor also offers individual Accessories/Kit Components: •... -
Page 6: Development And Programming Methods
Development and Programming Methods Currently there are four ways to program a PSoC: • Prototype programming • Full-featured in-circuit emulation • Production programming • Cypress factory programming for high volume orders** Inexpensive USB Cable Prototype Programming USB Cable Full-Featured Emulation USB Cable Prototype Programming... -
Page 7: In - Circuit Emulation
CY3215-DK kit. The ICE supports large memory model PSoC devices (devices with >256 bytes of RAM) and is backward compatible with previous PSoC devices (CY8C27x43 and CY8C24x23A). What adapters do you need for your project? In addition to the ICE that is included in the Development Kit (CY3215-DK), different Emulation Pods are available to support the range of packages available in the PSoC family. - Page 8 In-System Serial Programming The CY3207ISSP, ICE (CY3215-DK), and MiniProg1 (CY3210-MiniProg1) all allow easy In-System Serial Programming (ISSP). A cable is included in the ISSP Development Kit (CY3207ISSP.) All designers are encouraged to include ISSP capability on their printed circuit boards (PCBs.) ISSP is perfect for prototyping because it allows rapid reprogramming of the PSoC part mounted on the PCB and eliminates the need for multiple package-specific programmers.
-
Page 9: I 2 C-Usb Bridge (Cy3240-I2Usb)
Prototyping Modules (CY3210-2xxxx) PSoC Prototyping Modules are 28-pin PDIP adapters that seamlessly connect any PSoC device package-type to the 28- pin PDIP connector that is default on Cypress PSoC kits. Check the selection tables in the Kit Components and Accessories section of this document for a list of Prototyping Modules offered by Cypress. -
Page 10: Kits
Kits Description PSoC® FirstTouch™ Kit www.cypress.com/FirstTouch • The PSoC FirstTouch Starter Kit is a USB thumb drive kit that provides a quick, easy, and affordable way for embedded customers to evaluate the integration, flexibility, and real mixed-signal programmability of PSoC mixed-signal arrays. •... - Page 11 Description C Port Expander Lite Demo Kit The CY3242-IOXLite Demo Kit quickly demonstrates the following value propositions of Cypress' I solutions: CY3242- IOXLite • Integration • Flexibility • Compatibility One Cypress I2C Port Expander device replaces multiple port expander ICs from other vendors and flexibly integrates IO expansion, PWM functions and user EEPROM.
-
Page 12: Evaluation Kits
Description PSoC Evaluation Kit • This kit features an evaluation board and MiniProg1 programming unit. The evaluation board includes an CY3210- LCD module, Potentiometer, LEDs, and plenty of PSoCEval1 breadboarding space to meet all of your evaluation needs. • The MiniProg1 programming unit will program PSoC devices directly on the evaluation board or on other boards via a 5-pin header Express Evaluation Kit... - Page 13 Description CY3203A-CapSense CSA Evaluation Kit • An excellent CapSense learning resource with software, hardware and example projects to help CY3203A- designers learn how to implement PSoC CapSense in CapSense their own design using the CY8C20x34 family with CSA-type sensing. • A training board is included that is hardwired for buttons and sliders as well as LCD control and I communication.
- Page 14 Description SD Card Module Evaluation Kit The SD Card Module Evaluation Kit assesses the PSoC SD Card user module's ability to quickly and easily write to, CY3210- read from and seamlessly integrate an SD card module into SDCARD an embedded design. Secure Digital (SD) flash memory technologies are quickly becoming the preferred solution for portable, consumer and industrial electronic devices around the world for storing a large amount of information in a...
- Page 15 Description RGB High Brightness LED Kit The CY3261A-RGB board is a preprogrammed HB LED CY3261A- color mix board with seven pre-set colors using the CY8CLED16 EZ-Color HB LED Controller. The color selector software application can be installed on a host PC and is used to control the EZ-Color HB LED controller using the included USB cable.
-
Page 16: Development Kits
Description Basic Development Kit The CY3215-DK development kit includes a CY3215-DK tiny footprint, high-speed in-circuit USB 2.0- based emulator with a large trace buffer. This kit provides most everything you need to develop your designs with PSoC. Universal CapSense Controller – Basic Kit 1 •... - Page 17 Description CY3240- C – USB Bridge Kit (Rev A) I2USB The I2C-USB Bridge Kit allows one to test, tune and debug hardware and software of a PSoC application by bridging the USB port to I device. A wide variety of devices can be connected to the PC using this bridge. Among them are: EEPROMs, real-time clocks, ADC/DAC converters, LCD displays, regulated DC/DC converters, port expanders and many other devices incorporating the I2C interface.
-
Page 18: Programming Kits
Description “MiniProg” Programmer with Evaluation board • MiniEval board is a programming and evaluation board that allows socket programming of DIP devices. • It also includes LEDs and a POT for simple evaluation and demonstration, but does not include a prototyping area. CY3210- •... - Page 19 Description Basic Development Kit CY3215-DK The CY3215-DK development kit includes a tiny footprint, high-speed in-circuit USB 2.0- based emulator with a large trace buffer In-System Serial Programmer Production-unit programmer. It includes protection circuitry and an industrial case that CY3207ISSP is more robust than the MiniProg and the ICE for a production-programming environment.
-
Page 20: Kit Components & Accessories
& & & & Use this table when selecting an emulation kit and package adapter (foot) for use with your CY3215-DK (In-circuit emulation and programming kit.) Each Emulation Kit contains one POD and two FEET. However, the FEET in each Emulation Kit are a default PDIP style. - Page 21 Chip Part Number Package Dev. Kit CY8C21234-24SXI 16 SOIC CY3215-DK CY3250-21X34 CY8C21334-24PVXI 20 SSOP CY3215-DK CY3250-21X34 CY8C21434-24LFXI 32 QFN CY3215-DK CY3250-21X34QFN CY8C21534-24PVXI 28 SSOP CY3215-DK CY3250-21X34 CY8C21634-24LFXI 32 QFN CY3215-DK CY3250-21X34QFN *Foot Kit is required in conjunction with Emulation Kit to emulate this package. **Programming adapter may be required.
-
Page 22: Ordering Information
CY3250-21X34QFN-POD Replacement PSoC CY3250-21X34QFN Pod CY3250-24X23A Emulation support for CY8C24x23A devices. The pod provides the interconnection between the ICE base unit and the target hardware, includes 28PDIP Feet (2). This pod kit supports all non-QFN packages in combination with available CY3250 foot kit. -
Page 23: Foot / Package Adapters
Replacement of ICE Pod Feet The following table lists several examples of package adapters (FEET) with photos. These are In-Circuit Emulator (ICE) pod feet for debugging x- pin PDIP PSoC devices with the CY3215-DK ICE and accessory CY3250-2xxxx ICE PODs (not shown). CY3215-DK and CY3250-2xxxx kits are sold separately. - Page 24 Description CY3250- Replacement ICE Pod Feet (4) for 28SOIC-FK Debugging 28-Pin SOIC PSoC Devices CY3250- Replacement ICE Pod Feet (4) for 28PDIP-FK Debugging 28-Pin PDIP PSoC Device CY3250- Replacement ICE Pod Feet (4) for 32QFN-FK Debugging 32-Pin QFN PSoC Devices CY3250- Replacement ICE Pod Feet (4) for 44TQFP-FK...
-
Page 25: Prototyping Modules
PSoC device family on any 21x34 PSoC developer kit. PSoC developer kits sold separately. CY3210-24x23 provides evaluation of the CY3210- CY8C24x23A PSoC device 24x23 family on any PSoC developer kit. PSoC developer kits sold separately. CY3210-24x94 provides evaluation of the CY8C24x94... - Page 26 Description CY3210-29x66 provides evaluation of the CY8C29x66 CY3210- PSoC device family on any 29x66 PSoC developer kit. PSoC developer kits sold separately. Page 26 of 28 Kit Contents Photo • One (1) CY8C29x66 PSoC Prototyping Module 5.4-011808 [+] Feedback...
-
Page 27: Third Party Tools
Third Party Tools The following list includes 3rd-party programmer tools that have been specifically designed, tested, and qualified to support streamlined programming of PSoC Programmable System-on-Chip devices: BP Microsystems: http://www.bpmicro.com/ Programmer Model 1400 and 1700 Running BP WIN Software Revision V4.64.0 Supporting Cypress PSoC Devices CY8C21X23, CY8C21X34, CY8C22X13, CY8C24X23, CY8C27XXX, CY8C29XXX Qualified March 2007... - Page 28 For information and support on PSoC devices: http://www.cypress.com/psoc. Items may be purchased online at the Cypress Online Store: Or you can purchase Development Tools from one of Cypress’ accredited distributors. © Cypress Semiconductor Corporation, 2006-2008. The information contained herein is subject to change without notice. Cypress Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in a Cypress product.
