Page 1: Table Of Contents
Sep, 2022 WACP-C N100 0.36x Wide Angle Conversion Port Compact PN 85205 User Manual Underwater Optics Introduction Package Contents Important Instructions Part Names Wacp-C to Extension ring Specifications Care/Storage Warranty... -
Page 3: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. WACP-C Clean Cloth... -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS Water-tight test of the housing (without Do not use any kind of abrasive solution to camera inside) along with WACP-C before clean the glass surfaces. usage is recommended. Do not expose the housing in direct Do not point of the lens directly towards sunlight for a prolonged period. -
Page 5: Part Names
PART NAMES Top & Rear View Lens mount index mark... -
Page 6: Wacp-C To Extension Ring
Align the ‘O’ index on the lens port with the ‘I’ index on the adaptor / extension ring, and gently push the adaptor / extension ring towards the WACP-C until it cannot go any further. To Disassemble To un-mount the lens from adaptor / extension ring,... -
Page 7: Specifications
SPECIFICATIONS 85205 WACP-C Accessories # 85225 WACP-C Replacement Hard Cap Outer diameter x Length: DIA 170.0mm×145.5mm Weight in air: 2.24 kg # 21315 N120 to N100 15mm Port Adaptor Buoyancy in water : Negative 0.1 kg # 21320 N120 to N100 20m Port Adaptor... -
Page 8: Care/Storage
CARE/STORAGE Soak the housing system along with the Remove dust and other foreign matter WACP-C in fresh water after salt water from the dome port cover/cap before usage.; wipe the housing with a towel attaching them. before opening. Blow off dust with an air blower or clean When you’ve finished washing your opti-... -
Page 9: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/ or poor maintenance; it is the responsibility of the owner to carefully follow the instructions in our manuals. - Page 10 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
Need help?
Do you have a question about the WACP-C and is the answer not in the manual?
Questions and answers
I have a Nauticam N120 to N100 port converter that will NOT connect to my WACP-C N100. It fit just fine to the housing, but the WACP-C will not connect. I lined up the O with the I. It will not seat.
The Nauticam WACP-C won't connect directly to the N120 to N100 port converter because, in the described setup, it requires additional components: a 35.5mm N120 to N100 adapter and a 25mm adapter ring. The production version uses a 30mm N100 extension ring instead. Without these specific adapters or extension rings, the connection is not possible.
