SMP G9 User Manual

SMP G9 Car Alarm User Manual
1. Arming;
Press the button once, the doors will close, the siren will sound once, the indexes
will flash once, and the LED will also start flashing. After 5 seconds, the system will be
armed.
2. Disarming;
Press the button once, the siren will sound twice (except in silent alarm mode),
and the index lights will flash twice. This means that the system has exited arming
mode. The doors can also be opened, the LED is off.
3. Silent arming;
Press the button, it will lock the doors, the indexes will flash once, the LED will light
up. After 3 seconds, the silent alarm mode is activated.
4. Vehicle Search / Panic;
a) Vehicle Search / Panic Button: In disarmed mode, press the
will sound and the indices will flash. Press the
b) Alarm: While driving, press the
siren. This feature allows you to send an emergency call. You can exit the status by
pressing the button again.
5. Automatic central locking;
(a) when the engine is not running, the doors are automatically released from the lock
b) if you step on the brake 15 seconds after starting to drive, the central locking
system will be activated automatically
c) while driving, press the /
press the button, the lock will be released.
6. LED indicator;
When the system is armed, the LED flashes slowly, this flash accelerates when an
alarm occurs.
7. Impact sensor;
The sensitivity of the sensor can be adjusted using a spare meter. Always check the
correct setting after installation!
8. Open door reminder;
If the doors are not closed properly, the system will indicate that the alarm sounds
three times and the central locking system is activated. A new alarm will sound if the
doors still do not close properly.
9. Automatic feedback;
If you do not open the doors 25 seconds after disarming the system, the system will
automatically re-arm due to the possibility of incorrect disarming.
button, the alarm
button again to stop the function.
button, the indexes will start flashing with a
button to lock the central locking system. If you
10. Electric and Pneumatic Lock (Electric Lock is the factory default setting) After
removing the power supply from the central unit, replace the jumper inside the
control panel.
11. Luggage compartment remote opening;
a) in case you have a four-button transmitter: In the disarmed state, press and hold
the button for 3 seconds.
b) if you have a five-button remote control: If the system is not armed, press the
button to open the boot.
12. Code learning;
In case the transmitters do not work properly or are lost, you have the option to
associate another one with the control panel. When the system is disarmed and the
doors are locked, hold down the brake and then open the door. Turn the key three
times (from OFF to ON, finally leave it in the ON position. Press and hold any button on
the new transmitter, you will hear three beeps after 3 seconds. This indicates that you
have successfully paired the device with the control panel. (Attention! perform this
operation within 5 seconds, otherwise the system will automatically return to
disarmed mode.) You must repeat the same operation to teach additional
transmitters.
13. Anti-theft;
While driving, press the button, the indexes will flash. After this, press the button
within 5 seconds and the system will enter anti-theft mode. The indices flash, then 15
seconds later the engine stops and the siren sounds. To exit anti-theft mode, press the
button.
14. Emergency stop;
The emergency stop function is advantageous in case the transmitter is lost or does
not work properly. When the system is armed, place the key on the ACC, turn the key
from OFF to ON five times within 10 seconds. This will disarm the system.
The warranty is conditional on installation by a specialist garage.
Distributor: S.M.Power Kft., 2310 Szigetszentmiklós, Csepeli út 15.,
www.smpower.hu
