QTL Declare QTM-eLED+DALI-DT6 Manual

QTM-eLED+DALI-DT6
LED Power Supply - 100W-300W
1 2
WATTAGE
PRODUCT
QTM-eLED
Sample Part Number: QTM-eLED-200W-2-2-N/A-UNV-24VDC-DALI-DT6-WH
1
PRODUCT
QTM-eLED
2-Wire default is 1 address
3-Wire default is 2 addresses
For customization or pre-
programming contact a local sales
rep.
DALI commissioning to be performed
by a third party at time of installation.
6
PRIMARY VOLTAGE
UNV
COMPATIBLE LEDS
STATIC WHITE
SW24/1.5-4.0
SW24/5.0, SW-HE, SW-HE+
SD-SW24/1.0-4.0
SD-SW24/6.0
SW-IA
SW-XT
PRODUCT INFORMATION
• Limited output voltage and current, plus isolation for safe operation
• Controllable by DALI 2 protocol
• DALI dimming down to 0.2%
• Fully potted driver(s) for moisture resistance
• Suitable for dry and damp locations
• Suitable for surface or recessed mounting use
• Primary voltage - universal (120-277V)
• Wide operating temperature range: -4˚F to 122˚F
• Fits up to (3):100W 24 VDC driver(s) and DALI decoder module(s)
• Driver has Class A sound rating
© 2024 QTL. All rights reserved | 155 Hill St. Milford, CT 06460 | 203-367-8777 | sales@QTL.lighting | QTL.lighting
• LED power supply for DALI 2 applications
• Utilizes a 100W constant voltage LED Driver from Thomas Research and DALI 2 DT-6 Decoders
• Available in 100-300 watt capacity
• The power supplies and decoders are all prewired together along with terminal blocks for power and control wires
• Housing can be recessed or surface mounted
3 4
OUTPUT WIRING 1 OUTPUT WIRING 2
2
WATTAGE
100W
200W
300W
7
SECONDARY VOLTAGE
24VDC
OTHER
DW-HE Tunable Applications
DW-HE Warm Dim Applications
WD
SC
RGB
RGBW, RGBW-HE
5
OUTPUT WIRING 3 PRIMARY VOLTAGE
UNV
3
OUTPUT WIRING 1
2 2-Wire Light Engines
3 3-Wire Light Engines
2 2-Wire Light Engines
3 3-Wire Light Engines
2 2-Wire Light Engines
3 3-Wire Light Engines
2-Wire Light Engines: SW, SW-HE,
SW-HE+, SD-SW, SC, WD
3-Wire Light Engines: DW, DW-HE
8
CONTROL
DALI-DT6
SHEETS
Q-SHEETS SW
Q-SHEETS DW Tunable Applications
Q-SHEETS DW Warm Dim Applications
Q-SHEETS RGB
Q-SHEETS RGBW
• 5 year warranty
• Class 2 output
• CSA #239924
• Low Voltage Lighting Systems
• CSA class 3425-15 and class 3425-95
• CSA standard C22.2 No. 250.0-08 - Luminaires
• ANSI/ UL standard 2108 - Low voltage lighting systems
• CSA standard C22.2 No 250.13-14 - Light emitting diode (LED equipment for
lighting applications
• ANSI/ UL standard 8750 - Light emitting diode (LED) equipment for use in lighting
products
6 7
SECONDARY VOLTAGE
24VDC
4
OUTPUT WIRING 2
N/A
2 2-Wire Light Engines
3 3-Wire Light Engines
2 2-Wire Light Engines
3 3-Wire Light Engines
2-Wire Light Engines: SW, SW-HE,
SW-HE+, SD-SW, SC, WD
3-Wire Light Engines: DW, DW-HE
9
WH
BK
MICRO 5
MICRO 5 DW Tunable Applications
MICRO 5 DW Warm Dim Applications
Specification subject to change. Rev-02-16-24
COMPLIANT
8 9
CONTROL COLOR
DALI-DT6
5
OUTPUT WIRING 3
N/A
N/A
2 2-Wire Light Engines
3 3-Wire Light Engines
2-Wire Light Engines: SW, SW-HE,
SW-HE+, SD-SW, SC, WD
3-Wire Light Engines: DW, DW-HE
COLOR
White (Standard)
Black Powder Coat Finish
MICRO 5 SW
MICRO 5 RGB
