Page 2 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Product Specification Item Wi-Fi6 and Bluetooth 5.x SOM Customer BIXOLON Model WBT-MSB Version Date 2023. 12. 08  2022 MOVON. All Right Reserved...
Page 3 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Revision History Revision Date Changes Written by Rev1.0 12/26/2022 First Release (EVT) Yanim SON Rev2.0 12/08/2023 2nd Release (DVT) Yanim SON  2022 MOVON. All Right Reserved...
Page 4: Table Of Contents
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Contents Product description ........................5 Overview ............................5 Key Feature ..........................5 Standard Compliance ........................6 Application ............................. 6 Product Specifications ........................6 SW Block Diagram ........................6 Specification Overview ......................... 7 Pin Assignment ........................... 12 Pin allocations ..........................
Page 5: Product Description
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB 1. Product description The module is that the System on Module (SOM) designed according as the BIXOLON board to board specification for use with Wi-Fi6/Bluetooth 5.3 networks that provides IEEE 802.11a/b/g/n/ac/ax and Bluetooth SIG 5.x mobile connectivity. This module is applicable to dedicated to BIXOLON POS, KIOSK and other potable device.
Page 6: Standard Compliance
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB  Supports OFDMA up to 1024QAM and Target Wake Time (TWT) Instantaneous 0-DFS  Bluetooth  Bluetooth 5.3 SIG standard/specifications compliant Supports up to EDR 3Mbps  Supports Low Energy 2Mbps and Long Range ...
Page 7: Specification Overview
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB B. Specification Overview Item Description Hardware Wi-Fi6 and Bluetooth5.3 SoC Independent ARM-based Wi-Fi and Bluetooth CPUs Integrated Buck regulator for core power supply Separate power block for independent of Wi-Fi/Bluetooth OFDMA 1024QAM and Fully MU-MIMO...
Page 8 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB F59L1GB1A-25BIG Memory Cell Array: (128M + 4M) x 8bit Data Register: (2K + 64) x 8bit Program/Erase Lockout During Power Transitions ECC Requirement: - 1bit/528Byte Boot from NAND support Automatic Memory Download BGA 63-ball 9mmx11mmxx1.0mm MFI343S00177 Apple MFI CP3.0 signal communication codec chip...
Page 9 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Linux, Android Wi-Fi 802.11 a/b/g/n/ac/ax Protocol Bluetooth Bluetooth 5.3 Classic/BLE Wi-Fi 2.4Ghz / 5Ghz BR and EDR 1Mbps, 2Mbps and 3Mbps Networking Bluetooth LE 1Mbps/2Mbps, Long Range Power class 1.5 Wi-Fi AES, TKIP...
Page 10 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB - Wi-Fi RF performance Wi-Fi 2.4GHz Item Functional Item Detailed Specification Remark Standard IEEE802.11 b/g/n/ax Frequency range 2.401~2.483GHz Band Class Channels 1~13ch Channel 802.11b/g 20MHz 802.11n/ax 20MHz/40MHz Modulation DSSS/CCK Rate 11/5.5/2/1Mbps Auto fallback 802.11b...
Page 11 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB 802.11ac/ax 20MHz/40MHz/80MHz Modulation OFDM Rate 54/48/36/24/18/12/9/6Mbps Auto fallback 802.11a Max. Sensitivity -68dBm Conducted, 54M Conducted, 54M Output power 14dBm @EVM<-27dB Modulation OFDM Rate MCS0 ~ MCS7 Max. Sensitivity -65dBm Conducted, HT20 MCS7 802.11n...
Page 12: Pin Assignment
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB 3Mbps/8DPSK Max Rx. Sensitivity 0.001% @ -70dBm Conducted RF Spread Frequency Hopping Spread Spectrum (FHSS) 1600hops/sec, 1MHz channel space Profile Classic Max 3Mb/s @ EDR3 throughput Max 2Mb/s C. Pin Assignment Pin allocations <Bottom side>...
Page 13: Pin Description
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Pin description Voltage level When is signal Pin # Port name Description and I/O needed DGND Digital Ground Always VCC_3.3V Always Power supply for Host chip VCC_1.8V Host UART For Host chip UART Transmission interface VCC_3.3V...
Page 14: Electrical Specification
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB D. Electrical Specification Power sequence Power up sequence The external 1.8V_DUT and 3.3V_DUT shall not rise (10 - 90%) faster than 40 microseconds for minimize in-rush current and not slower than 100 milliseconds. PDN must be held low for at least 100 milliseconds after external 1.8V_DUT and 3.3V_DUT has reached specification level before pulled high.
Page 15: Dc Characteristics
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Parameter Unit Delay from PDN low (at least 0.2V) to time of VDD_CORE_DUT ramp- down Delay from PDN low (at least 0.2V) to time of VDD_CORE_DUT high (at least 90%) DC characteristics - Power Tree The module utilizes VDD_3.3V, 3.3V_DUT and 1.8V_DUT power sources.
Page 16 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB - Electrical characteristics Parameter Minimum Typical Maximum Unit External Power supply Voltage range 3.135 3.30 3.465 DC 3.3V_9098 * Current consumption Voltage range 1.71 1.80 1.89 DC 1.8V * Current consumption Voltage range 3.30...
Page 17: Power Dashboard According To Wi-Fi/Bluetooth Use Cases
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Power dashboard according to Wi-Fi/Bluetooth use cases Mode Conditions 3.3V_DUT (Avg) 1.8V_DUT (Avg) Unit Power down Power down 0.03 0.26 Deep sleep Bluetooth only Wi-Fi only Wi-Fi + Bluetooth Wi-Fi Uplink (1X1 Tx) 2.4GHz 802.11b,...
Page 18 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB 80MHz Bluetooth LE LE advertise Interval=1.28s 1.72 Interval=1.28s LE scan 1.93 Window=11.25ms LE link Interval=1.28s 1.98 LE Peak transmit @ 4dBm, 1Mbps 0.56 LE Peak receive 1Mbps 0.56 Bluetooth BR/EDR Idle 20.11 0.56 Page scan 2.01...
Page 20: Recommended B2B Plug Selection Guide
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Recommended B2B plug selection guide Please refer to dimension in red box of figure below that is recommended plug dimension. <B2B socket of module>  2022 MOVON. All Right Reserved...
Page 22: Regulatory And Compliance
Wi-Fi6 and Blutooth5.x System on Module WBT-MSB 3. Regulatory and compliance FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 23 Wi-Fi6 and Blutooth5.x System on Module WBT-MSB Ce dispositif est conforme à la norme CNR-247 d’Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
Page 24 - OEM integrators must ensure that its product is electrically identical to the device, FCC ID: TDU-WBT-MSB reference designs . Any modifications to module reference designs may invalidate regulatory approvals in relation to the product, or may necessitate notifications to the relevant regulatory authorities.
