The d-Tilt/BluTuilt features full (360 arcdeg) tri-axial measurement so that placement on structures does not require precise leveling. The d-Tilt/BluTilt can be attached to a beam or mounted directly to any structure. The d-Tilt/BluTilt is also available in borehole model (shown) with a 38mm OD.
Page 3
Generalized 3-D Rotation An accelerometer measures the orientation with respect to the gravity vector which for a cartesian coordinate system (Fig 1) is given by : ) ………(1) g = ( −1 The measured acceleration values are given by a = . ……..(2) where R is a generalized rotation matrix recognizing that the coordinate system is right handed.
Installation The BluTilt uses a 3-axis accelerometer to measure the orientation of the gravity vector g [0,0,- g]. As stated above, this does not mean that the device can measure complete 3-D movements (pitch, roll, yaw) since rotations in the horizontal plane (yaw) cannot be resolved with respect to the vertical gravitational vector.
Page 5
The raw data from the accelerometer is a 20-bit result varying from 256,000 (+1g)to -256,000(-1g). The values for the three axes, x,y and z are reported. tilt_mode 1 - Vector mode: Another way to define a tilt is to specify (i) a single tilt angle () and (ii) a vector (n) representing the axis of rotation (see NXP app note section 4).
Page 6
In many situations the user will want to monitor changes in tilt from an arbitrary reference following installation. To set a reference tilt (a ) the user should install the Blutilt and allow time for the installation to stabilize. Outputing the custom command tilt_ref_set will save the current...
Page 7
The data payload is populated by the two angles corresponding to pitch and roll. For clarity these are remapped as X, Y, Z along the x,y and z axes of the BluTilt. The sign is positive for downward rotation from the positive end of the axis. Field 5 of the output string is the tilt_z_up...
Page 8
tilt_z_up = 0 +z is up tilt_z_up = 1 +y is up...
Page 9
tilt_z_up = 2 +x is up tilt_z_up = 3 +z is down...
Page 10
Figure 6. The 6 tilt_z_up settings. Tilt_mode 3: Three angles.
Page 11
When the BluTilt is aligned with z-up the three angles are zero. How to Setup the BluTilt using the BluPoint App. The setting for the BluTilt are applied using the LogPoint component. The results can be observed using the ViewPoint Component.
Page 12
Step 1: Connect to the BluTilt in LogPoint Open the LogPoint component and connect to the BluTilt of interest. In the case 200166807(YYMM66###).
Page 13
Step 2: Use CUSTOM CMD to determine the tilt_mode. ucom tilt_mode Enter the command (with no value) through custom command.
Page 14
ucom tilt_mode The response to tilt_mode=1 response indicates that the device is in vector mode. Step 3: Change the tilt_mode ucom tilt_mode 2 Using the CUSTOM CMD...
Page 15
2 The message returned, indicates the change has been made. Return to ViewPoint and connect to the BluTilt to see readings.
Page 16
The two angles (Mode 2) are returned. The final csv for each reading is the tilt_mode. Installing a YieldPoint BluTilt – Smooth Concrete Surface The BluTilt will be installed using 4 Tapcon® screws Step 1: Select the appropriate Tapcon screw: Standard or Stainless Steel.
Page 17
Step3 With a wire brush, compressed air or vacuum clean out the hole of all dust created during the drilling process. Step 4: Coat the base of the BluTilt enclosure with either a structural adhesive or silicone.
Page 18
Step 5: Use 4 Tapcon screws either 1.5” or 2” long, to tightly secure the BluTilt. Align the hole in the fixture over the hole in the base material. Insert the concrete screw through a hole in the fixture and into the hole in the base material.
