Summary of Contents for CRAVOT CyberRack E1
- Page 2 Parts for bike rack Parts for ramp...
- Page 3 Parts List for bike rack Parts List for ramp Part# Description Part# Description Beam Assembly Ramp M10*25 Outer Hexagon Bolt Kit Quick-release pin Front Wheel Holder M10 Long Outer Hexagon Bolt Required Tools（Not included） M10 Lock Nut Bottom Fixing Bracket Name Imperial Metric...
- Page 4 STEP1 STEP2 Put the holes of the Front Wheel Holder (3) and the Beam Place the components assembled in steps 1 above into the Assembly (1) aligned, install 4pcs M10*25 Outer Hexagon Bolt Bottom Fixing Bracket (6), align the holes, install 2pcs M10 Long Kit (2) and tighten them.
- Page 5 STEP3 STEP4 50Nm Insert the Support Rod (7) into the Bottom Fixing Bracket (6), Insert the adjustable Connecting Block (9) into the Support Rod align the holes, place the Semicircle Plate (15) on both sides of (7), and properly tighten the knob so that it does not slide down. Support Rod (7), install the M10 Low Square Neck Bolt (8) and the M10 Lock Nut (5), and tighten them until the support rod does not move.
- Page 6 with the φ3.8 pin (13), making sure to place the pin through the STEP5 holes on the bolt. The diameter of lock beam should be less than 7mm. The lock is not included. Align the holes of the folding tube with the holes on the vehicle's 2"...
- Page 7 Bike Installation Instructions Before placing the bike, stand up the support rod in the middle, snap the front tire of the ebike into the front wheel holder, place the rear tire in the beam, and then use the ratchet wheel straps to fix the front wheel, rear wheel, and seat/middle tube of the bike as shown in the figure below.
- Page 8 Bike Installation Instructions（tire width<2.5”） If your tire width is less than 2.5”, please use velcros to fasten the front and rear tires. Only 2pcs of Velcro(14) are required to fix the tires, the rest are for spare. Note: The velcro fixes the front tire as illustrated Note: The velcro fixes the rear tire as illustrated...
- Page 9 How to Adjust the Wheel Cradle 1. Pull the cam gear 2. Turn in counterclockwise 3. Slide it 4. Until it against the tire 5. Fix by turning clockwise 6. Press it down...
- Page 10 How to Use the Ramp 1. Fix the buckle to the 2. Insert the ramp 3. Insert the 4. Fix the quick-release rack quick-release pin 5. Confirm the direction 6. Insert the ramp to the 7. Push the bike up of ramp bike rack along the ramp...
- Page 11 YOU ARE ALMOST THERE!
-
Page 12: Technical Specifications
Not intended for use with mopeds, motorcycles or 3 wheels bikes ⚫ Applicable for tires width within 5”, extra velcros (included) need to be applied for tires within 2.5” Model Name CRAVOT CyberRack E1 Description 2'' Hitch 1-Bike Rack with Ramp Material Aluminum & Steel Maximum Weight Capacity... - Page 13 ⚠ WARNINGS ⚠ ⚫ Do not overload beyond the bike rack’s weight capacity of 100lbs. ⚫ Do not carry more than 1 bike on the carrier. ⚫ The bike rack is not intended for transporting humans or animals. If you are planning to load only one bike, it is recommended to place it in the position closest to the vehicle. ⚫...
- Page 14 CRAVOT Warranty Policy Thank you for choosing CRAVOT. We are committed to providing you with quality products and exceptional service. This Limited Warranty Policy outlines the terms and conditions of our warranty support, including considerations for varying state laws in the United States and important disclaimers.
-
Page 15: Get Support
⚫ Disclaimer of Liability It is crucial to follow the instructions provided in the product manual for proper use. CRAVOT is not responsible for any damages or losses resulting from improper operation or handling of the product. This disclaimer of liability includes but is not limited to personal injury, damage to property, or any other losses incurred due to non-compliance with the provided instructions. - Page 16 CRAVOT HITCH BIKE RACK! ● The CRAVOT Bike racks are meticulously designed to ensure stability and safety when hitching your bikes. Prior to assembly, carefully read through this Owner’s Manual, as it provides essential information for both assembly and adjustment. CRAVOT is committed to delivering a bike rack that is properly assembled and accurately adjusted upon leaving our factory.
