Getting Started Guide & FAQs of Hollyvox G51
Title
Getting Started Guide & FAQs of
Hollyvox G51
Author
Aaron
Version
V1.0
Reviewer
@彭育威@陈莹 (Chany)
Security Level
Public
内容更新时间
2023-08-14
Getting Started Guide
Base Station Installation
1.
a. The distance between two base stations is at least 1.5 meters when multiple Hollyvox G51 systems are working
together.
b. You are advised to install the base station in an open place higher than 1.7 meters. A confined environment may
affect the wireless signal quality and reduce the transmission range.
Hollyvox G51 官网发布资料
更新内容
文档更新人
初步分类
Document ID
Department
Update Date
Review Date
Release Date
官网更新人
Aaron
AS-230814003
Sales & Engineering Department
2023–08–14
官网更新状态
官网更新时间
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HOLLYVOX G51
Summary of Contents for HOLLYVOX G51
- Page 1 Getting Started Guide Base Station Installation a. The distance between two base stations is at least 1.5 meters when multiple Hollyvox G51 systems are working together. b. You are advised to install the base station in an open place higher than 1.7 meters. A confined environment may...
-
Page 2: Cascade Settings
2. Cascade Settings Cascade with Hollyvox G51 Cascade via the 4-Wire Interface Connection Use a standard network cable to connect two base stations via the 4-wire interface. The length of the network cable is up meters. - Page 3 All devices must work with a static IP ad dress when they are cascaded via the LAN interface. If more than three Hollyvox G51 systems are cascaded, please use LAN and 4-wire cascade connections together. 2. Cascade with Clear-Com 702...
- Page 4 Method 2: Connect Hollyvox G51 to Clear-Com 702 via a 2/4-wire converter. The key settings are the 4-wire ● input & output gain settings on the Hollyvox G51 front panel as well as the input & output gain settings on the 2-/4-wire converter.
- Page 5 Hollyvox G51 front panel, including input & output gain settings, cable length compensation, and others. Method 2: Connect Hollyvox G51 to FreeSpeak II via the 4-wire interface. The key settings are the 4-wire input ● & output gain settings and the line sequence settings on the Hollyvox G51 front panel.
- Page 6 Settings Connect Hollyvox G51 to MCX Rack Station via the 4-wire interface. The key settings are the 4-wire input & ● output gain settings and the line sequence settings on the Hollyvox G51 front panel. 3. How Does Hollyvox G51 Work with an Audio Mixer?
- Page 7 Step 2: Connect Hollyvox G51 to the mixer via a RJ45 to dual XLR cable and check if there is music output on your beltpack. If not, please enter the menu interface on the base station and then select Order Switch under the 4W Settings options to modify the line sequence definition.
- Page 8 Step 1: Turn off the DHCP under the network settings on the Hollyvox G51 front panel and check the base station IP address (default: 192.168.218.10). Step 2: Connect the base station to a laptop via the LAN port with Ethernet cable.
- Page 9 Secondary mic: Omnidirectional, electret How many Hollyvox G51 systems can be cascaded and how to perform cascade connections To connect two Hollyvox G51 systems, use IP cascade or 4-wire cascade; to connect more than two systems, use IP and 4-wire cascade together.
- Page 10 Step 1: Download the Hollyvox app. Step 2: Connect a control device (like iPhone) to the Hollyvox G51 base station in the same LAN. (Connect the devices via Wi-Fi directly or connect them to the same network by a router.) Step 3: Open the Hollyvox app to perform settings.
