Kelly Controls, Inc
Kelly DC/DC Converter
KL-48DCDC-400-5 KL-48DCDC-500-5
KL-72DCDC-400-5 KL-72DCDC-500-5
User's Manual
Model:
KL-96DCDC-500-5
KL-144DCDC-500-5
KL-72DCDC-650-5
KL-96DCDC-650-5
KL-144DCDC-650-5
KL-96DCDC-800-5
KL-144DCDC-800-5
Rev.1.21
Jan. 2023
0
Advertisement
Related Manuals for Kelly KL-96DCDC-800-5
Summary of Contents for Kelly KL-96DCDC-800-5
- Page 1 Kelly Controls, Inc Kelly DC/DC Converter User’s Manual Model: KL-48DCDC-400-5 KL-48DCDC-500-5 KL-72DCDC-650-5 KL-96DCDC-800-5 KL-72DCDC-400-5 KL-72DCDC-500-5 KL-96DCDC-650-5 KL-144DCDC-800-5 KL-96DCDC-500-5 KL-144DCDC-650-5 KL-144DCDC-500-5 Rev.1.21 Jan. 2023...
-
Page 2: Specifications
If you have any questions, please contact the support center of Kelly Controls, Inc. Kelly DC-DC Converter covers wide range of DC input voltages of 40V to 200V, and outputs DC 13.5V. It is quite efficient and reliable with a compact size. - Page 3 Kelly Controls, Inc • Operating Temperature Range: -20℃ to 90℃ (case temperature) • Full - load efficiency: ≥90% • Ripple coefficient: ≤1% Output Output voltage voltage Input Operating Output Output Model (at nominal (at min Voltage Voltage Current Power input...
-
Page 4: Installation
Kelly Controls, Inc 4. Installation KL-xxDCDC-400-5 Dimensions: 130mm (L)*94mm (W)*53mm (H) The case outline and mounting holes’ dimensions are shown below. Figure 1 :(Top view) Models: KL-xxDCDC-400-5 Figure2: (Side view) Models: KL-xxDCDC-400-5... - Page 5 Kelly Controls, Inc Figure 3 :(Front view) Models: KL-xxDCDC-400-5...
- Page 6 Kelly Controls, Inc KL-xxDCDC-500-5 Dimensions: 125mm (L)*85mm (W)*67.5mm (H) The case outline and mounting holes’ dimensions are shown below. Figure 4 : Models: KL-xxDCDC-500-5...
- Page 7 Kelly Controls, Inc KL-xxDCDC-650-5 Dimensions: 125mm (L)*85mm (W)*67.5mm (H) The case outline and mounting holes’ dimensions are shown below. Figure 5 : Models: KL-xxDCDC-650-5 KL-xxDCDC-800-5 (With cooling fan at the bottom)
- Page 8 Kelly Controls, Inc 5. Connections Input: Red: Input Positive with 15A fuse(2.0mm Yellow: Key Switch(2.0mm Black: Input Negative(2.0mm Output: Red: Output Positive(4.0mm Black: Output Negative(4.0mm 6. Contact Us: Kelly Controls, Inc Home Page: http://www.kellycontroller.com E-mail: sales@kelly-controls.com Phone: (01) 224 637 5092(US)
