Outland Living FM1BS-215 Owner's Manual

Princeton 1 burner gas stove
Hide thumbs

Advertisement

Table of Contents

PRINCETON
1 BURNER GAS STOVE
Model number FM1BS-215
(1x) 30,000 BTU/h cast aluminum burner with OUTLAND DuoFlame™ control technology.
Design Patent Pending. ™ is a trademark of FMI Brands Inc.
® is a registered trademark of FMI Brands Inc.
The OUTLAND flame is a registered trademark of FMI Brands Inc.
MANUFACTURED BY FMI BRANDS INC 101-3570 194 Street, Surrey, BC Canada V3Z 1A5
USA, Canada Toll Free: 1-888-514-1663 | Email: info@outlandliving.com
Hours of Operation: 8:30AM - 4:00PM (Pacific Time)
Owner's
Manual
LP Cylinder
not included
D.215.000.V1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM1BS-215 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outland Living FM1BS-215

  • Page 1 1 BURNER GAS STOVE LP Cylinder not included Model number FM1BS-215 (1x) 30,000 BTU/h cast aluminum burner with OUTLAND DuoFlame™ control technology. Design Patent Pending. ™ is a trademark of FMI Brands Inc. ® is a registered trademark of FMI Brands Inc.
  • Page 2 State of California to cause cancer, birth defects or other reproductive harm. For more information go to Cancer and Reproductive Harm - www.P65Warnings.ca.gov. En-1 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...

  • Page 3: Carbon Monoxide Hazard

    CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car, or home. WARNING: WARNING: Do not store or use gasoline or other For outdoor use only.
  • Page 4 Ensure all 4x leg extensions are fully seated. The thumb screw washer should be on top of the U slot. The thumb screws should be fully tightened before turning the stove over. En-3 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...
  • Page 5 SECTION 1: ASSEMBLY (continued) STEP 4 : ENSURE THE STOVE IS LEVEL AND STABLE Most ground terrain is uneven. The stove should be level and STEP 3: STANDING DEPLOYMENT stable prior to operation. If the stove is not level, or does not a) Place appliance on a level, stable, non-combustible surface.
  • Page 6 Extend hose to full length and ensure that the propane tank is Leak Test all connections. See section labeled “Leak Test”. as far as safely possible from the appliance and place the tank in the included stabilizer ring. En-5 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...
  • Page 7 SECTION 2: IGNITION (continued) STEP 6 Fully open the air-fuel adjustment levers. Light each burner individually. Using a lighter or match, ignite lighter and hold flame slightly above the burner, then open the valve on the appliance slowly by turning (counterclockwise) until the unit ignites. Both the inner ring and outer ring of the burner should ignite.

  • Page 8: Extinguishing The Appliance

    (a straw, or a can of compressed air may be helpful). 6. Confirm all burner jet obstructions are clear. 7. Close grill. 8. Reignite stove normally En-7 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...
  • Page 9 SECTION 5: IGNITION TROUBLESHOOTING (continued) DANGER: WHAT IS AN EXCESS FLOW VALVE? (EFV) The EFV is a safety mechanism contained within every Keep hair tied back and keep head and face away from the propane gas regulator. The purpose of the EFV is to restrict appliance during ignition! the gas supply if too much gas is flowing too quickly through the gas hose.

  • Page 10: Appliance Dimensions

    LP Cylinder not included GRILL AREA LENGTH APPLIANCE DIMENSIONS 341 mm [13.4"] (COMPACT TRANSPORT/STORAGE) 420 mm [16.5"] LENGTH TABLE TOP DEPLOYMENT TABLE TOP DEPLOYMENT Front LP Cylinder not included En-9 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...

  • Page 11: Operational Safety

    SECTION 7: OPERATIONAL SAFETY DANGER: Keep the appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Never leave the appliance unattended while in use. The user Keep the fuel supply hose away from any heated surface(s). must have a clear line of sight to the appliance at all times.
  • Page 12 LP cylinder must be arranged for vapour withdrawal and include a collar to protect the LP cylinder valve. Always keep LP cylinders in upright position during use, transit or storage. En-11 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...

  • Page 13: Lp Cylinder Removal, Transport And Storage

    LP tank inside a vehicle which may become overheated operation. by the sun. Do not store an LP tank in an area where children Only use a replacement hose by OUTLAND Living. play. En-12 1-888-514-1663 |...
  • Page 14 3. Prepare a leak testing solution of half liquid detergent and LEAK TEST: Apply the solution half water. to the LP gas delivery system at points: Appliance Valve Coupling 2. Gas Regulator 3. LP Cylinder Coupling En-13 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...

  • Page 15: Appliance Maintenance

    SECTION 7: OPERATIONAL SAFETY (continued) d) If no adverse reaction is observed and the connections all THE APPLIANCE IS NOT TO BE USED UNTIL ANY LEAK IS CORRECTED. seem fine then move to the ignition sequence. A gas appliance repairman or LP gas dealer should be called if 6.
  • Page 16 Never perform inspections, cleaning or maintenance when the appliance is hot! The stove must be cool and the LP cylinder disconnected BEFORE any cleaning or inspection and maintenance is performed. En-15 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...
  • Page 17 SECTION 8: APPLIANCE MAINTENANCE (continued) BURNER VENTURI INSPECTION Inspect and clean the cast aluminum burner venturi tubes often ATTENTION: and especially if the stove has been sitting unused for a period of time. Keep debris and bug nests out of the burner tube. Fully close 1.

  • Page 18: Warning Notes

    • Always inspect and clear all valve and gas orifices of any foreign debris including spider webs prior to lighting. • Fully close the air-fuel adjustment levers when appliance is not in use. En-17 OUTLAND LIVING - PRINCETON 1-BURNER STOVE OWNER & SAFETY MANUAL D.215.000.V1...
  • Page 19 NOTES En-18 1-888-514-1663 | WWW.OUTLANDLIVING.COM...
  • Page 20 At FMI Brands’ sole discretion, products under warranty will be repaired and/or replaced at no charge to the customer. Any returns sent back to FMI Brands must be sent via prepaid freight and in the original retail packaging. Please register your OUTLAND Living product for proof of purchase and warranty at https://outlandliving.com/register-products/ For more warranty information and details please contact FMI Brands Inc.
