Wyrestorm APO-DG2 Quick Start Manual

Apollo USB-C Wireless
Casting Dongle
APO-DG2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
Panel Description
1
4 2
3
Pair with SW-640L-TX-W
1. Insert the USB-C connector of the dongle into the USB-C pairing port on the front of the
2. A message will appear on the display connected to the Switcher saying "Pairing
Note: Up to two dongles can be paired with a Switcher.
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that WyreStorm APO-DG2 Is connected correctly
• Verify that the device is not in 'pause' mode
• Verify that APO-DG2 is paired to the correct device
Warranty Information
WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal
use for a period of five (5) years from the date of purchase. Refer to the Product Warranty page on
limited product warranty.
Copyright © 2024 WyreStorm ProAV Corporation | Copyright © 2024 WyreStorm ProAV Corporation |
APO-DG2 Quickstart Guide | 240605 APO-DG2 Quickstart Guide | 240605
Number Name
1 USB Type-C Port
2 Present Button
3 Project Button
4 LED Indicators
switcher.
Dongle". Wait for the pairing process to complete before disconnecting the APODG2.
wyrestorm.com wyrestorm.com
In the Box
1x APO-DG2 USB-C Dongle
1x QR Code Card 1x QR Code Card
Description
Connect for pairing or source device for sharing content.
Press the Present button to stop or continue the content shared to the display (source
content not affected).
Short Press: Short press button to share content or disconnect.
Hold the Button for at least 2s: When using Multiview and multiple screens are shown
on the connected display, hold the button for at least 2s, the content shown through the
dongle will be shown in full screen.
Pairing Status
• LED indicator is flashing green - Pairing process
• LED indicator is solid green - Pair ready
Sharing Screen Status:
• LED indicator is flashing - Connecting
• LED indicator is solid green - Ready for sharing
• LED indicator is solid white - Sharing content
Upgrade Status:
• LED indicator is fast blinking white (about 2 times per second) while upgrading. Once
upgrade is completed, it will turn green
• LED indicator is solid red when upgrade fails
No Audio Input or Output
• Verify that the volume on your PC/Mac is not muted
• Verify that the volume on the display is not muted
wyrestorm.com
1 of 2
