BENDIX Fusion FLR-25 Service Data

Bendix Fusion
® ™
Vehicle Equipped with the
Bendix Fusion System
® ™
NOT TO SCALE
Figure 1 – Bendix Fusion
®
IMPORTANT
Bendix -brand Electronic Control Units (ECUs) are
®
not designed to store data for purposes of accident
reconstruction, and Bendix
Software is not intended to retrieve data for purposes
of accident reconstruction. Bendix makes no
representations as to the accuracy of data or video
retrieved and interpreted from ECUs for purposes
of accident reconstruction. Bendix does not offer
accident reconstruction services or interpretation of
stored data. Bendix ECUs are not protected from fire,
loss of power, impact damage, or other conditions that
may be sustained in a crash situation and may cause
data to be unavailable or irretrievable.
FLR-25 Radar Sensor
™
Windshield-mounted
Camera
The DARK GRAY area approximates
the zone where the Fusion system is
ready to alert – and intervene with the
vehicle's brakes – as long as the vehicle
is traveling above 15 mph (24 kph).
System
™
ACom PRO Diagnostic
® ® ™
Front Bumper-
mounted Radar
The Bendix Fusion system will not operate and will
set a Diagnostic Trouble Code (DTC) if any of the
following vehicle systems also show a relevant DTC:
engine, engine cruise, instrument cluster, Bendix
Bendix ATC, Bendix
®
components must be repaired and cleared of DTCs
before troubleshooting the Fusion system. (NOTE:
Clearing the vehicle DTCs may be the only step needed
to reestablish full Fusion system functionality. Refer to
Section 2.6: Clearing Diagnostic Trouble Codes (DTCs).
Radar Beam
Detected Forward
Vehicle
The STRIPED area approximates the
zone where the Active Cruise with
Braking (ACB) feature is ready to
alert – and intervene with the vehicle's
brakes – when the cruise control is set.
IMPORTANT
ESP , or transmission. These
® ®
ABS,
®
1
