AsBridge
ASA-112M
Data Register for AsReaderGun Series
User's Manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader ® is registered trademarks of Asterisk Inc.
Other company and product names are generally trademarks or registered trademarks of their respective companies.
The contents of this manual are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AsReaderGun Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Asterisk AsReaderGun Series

  • Page 1 User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader ® is registered trademarks of Asterisk Inc. Other company and product names are generally trademarks or registered trademarks of their respective companies. The contents of this manual are subject to change without notice.

  • Page 2: Table Of Contents

    AsBridge ASA-112M User’s Manual Contents Preface ............................2 Safety Instructions ........................3 How to Care for the Device .....................4 1 Assembly of Products and Accessories ................1 Inside the Box ........................1 2 Name of Each Part and Operations ..................2 3 Basic Operations ........................

  • Page 3: Preface

    AsBridge ASA-112M User’s Manual Preface Thank you for purchasing the AsBridge. AsBridge is a data register that can be used with AsReaderGun series ASR-R202G, ASR-L251G devices. The barcode /tag information read by AsReader can be cached in the memory of the AsBridge device.

  • Page 4: Safety Instructions

    AsBridge ASA-112M User’s Manual Safety Instructions Please read the following instructions carefully to prevent injury, malfunction, fire, etc. Warning Do not attempt to disassemble, modify or repair the device yourself, otherwise it may cause malfunction, fire or electric shock. We are not responsible for any malfunction of the device, the smart device or the PC. If you notice any abnormalities such as smoke, abnormal odor, or strange noise coming from the device during use, stop using it immediately.

  • Page 5: How To Care For The Device

    AsBridge ASA-112M User’s Manual How to Care for the Device Please use this device in a clean environment. Adhesive chemicals or oils may cause the resin shell to break.  chemicals include cosmetics, detergents, pesticides, thinners, gasoline, etc.  oils include tallow and other animal oils, hand creams, etc. Please keep the device clean.

  • Page 6: Assembly Of Products And Accessories

    AsBridge ASA-112M User’s Manual Assembly of Products and Accessories Inside the Box The following items are contained in the box. Please first make sure you have all of these items. In case that any items are missing, please contact the company from whom you purchased the device.

  • Page 7: Name Of Each Part And Operations

    AsBridge ASA-112M User’s Manual 2 Name of Each Part and Operations ⑤ FW Update Indicator (Green) Action Indicator ⑥Battery Indicator (White) ④ (Blue) ①Power Button ②Reset Button ③ Charging Indicator (Red/Green) FIG. 2-1 Appearance Indication (Front)
  • Page 8 AsBridge ASA-112M User’s Manual ⑦AsLock Interface ⑧Micro USB Type-B ⑨DIP Switch FIG. 2-2 Appearance Indication (Back) (1) Power Button ・Power on/ off Press and hold the power button over 2 seconds, the blue and green LED blinks and the device starts. When the device is on, press and hold the power button over 2 seconds to shut down.
  • Page 9 AsBridge ASA-112M User’s Manual (3) Charging Indicator ・It indicates the charging status of the device. Running status LED status Connected with a USB charging cable Charging Red on (Regardless of power on/off) Fully charged Green on (4) Action Indicator ・It indicates the data transfer status and the connection status with AsReaders. Running status LED status Power on (AsReader device disconnected)

  • Page 10: Basic Operations

    AsBridge ASA-112M User’s Manual Basic Operations Power on/off  Long press the power button of the device for 2 seconds to switch it on and off. This product has no buzzer and vibrator, so the product does not have any buzzer or vibration indication.
  • Page 11 AsBridge ASA-112M User’s Manual Reset  Press the Reset button on the AsBridge device (see FIG. 2-1 Appearance Indication (Front)-②) to reset the device. This operation is only equivalent to re-plugging the battery then restarting the device. It will not affect the setting of any product parameters. Nor will it delete any barcode and RFID tag data stored in the device.

  • Page 12: Working Modes And Supporting Asreaders

    AsBridge ASA-112M User’s Manual Working Modes and Supporting AsReaders 4.1 Working Modes The product has two working modes, some need to be switched by setting the DIP switch, as shown in FIG. 2-2 Appearance Indication (Back)-⑨DIP Switch. The device must be restarted to take effect after the DIP switch is toggled.

  • Page 13: Use With Asr-L251G

    AsBridge ASA-112M User’s Manual Use with ASR-L251G FIG. 5-1 Combination with ASR-L251G (old design) For ASR-L251G V2, To work with a 251V2 device, push the protective cover of the AsBridge a little before installing. See below.
  • Page 14 AsBridge ASA-112M User’s Manual Operation steps: Put the AsReader configuration file into the AsBridge internal memory via U-disk mode (For details, see 7 U-disk Mode). About the configuration file format for ASR-L251G, see Appendix1-Configuration File Format for ASR-L251G. You can set parameters of the ASR-L251G running in Buffer mode through the configuration file.

  • Page 15: Use With Asr-R202G

    AsBridge ASA-112M User’s Manual Use with ASR-R202G FIG. 6-1 Combination with ASR-R202G (old design) Operation steps: Put the AsReader configuration file into the AsBridge internal memory via U-disk mode. About the configuration file format for ASR-R202G, see Appendix 2-Configuration File Format for ASR-R202G.

  • Page 16: Disk Mode

    AsBridge ASA-112M User’s Manual U-Disk Mode What's the use of U-disk mode? In U-disk mode, the configuration files of the AsReader device can be placed in the  memory of the AsBridge device. In this way, when using buffer mode, the AsBridge device will automatically configure some parameters of the AsReader devices, such as the on/off state of the buzzer or vibrator.

  • Page 17: How To Update Firmware Via Configuration File

    AsBridge ASA-112M User’s Manual How to Update Firmware via Configuration File How to put the configuration file into AsBridge:  Put the configuration file into the AsBridge internal memory via U-disk mode. About the configuration file format, see Appendix 3-Configuration File Format for AsBridge.

  • Page 18: How To Set Asbridge Via Configuration File

    AsBridge ASA-112M User’s Manual How to Set AsBridge via Configuration File Configuration file name and format  Local_Parameter.txt (see Appendix 3-Configuration File Format for AsBridge) Configuration file content and format  SleepTime(0~1800)s:300 AutoOffTime(0~300)s:300 How to Set  The default value for both the parameters is 300 seconds. To modify them, simply change the value after the colon of the parameters.

  • Page 19: How To Set The Asbridge Local Time Via Configuration File

    AsBridge ASA-112M User’s Manual How to set the AsBridge Local Time via Configuration File Configuration file name and format  Local_Parameter.txt (see Appendix 3 Configuration File Format for AsBridge) Configuration file content and format  LocalTimeIndicate:0(2022/10/18-14:23:00) How to Set the Local Time: ...

  • Page 20: Troubleshooting

    AsBridge ASA-112M User’s Manual Troubleshooting Power indicator does not indicate power.   Check the DIP switch to make sure it is in the ON state. The green light is on.   Check the DIP switch to make sure it is in the ON state. The ASR-R202G device cannot be connected.

  • Page 21: Appendix 1- Configuration File Format For Asr-L251G

    AsBridge ASA-112M User’s Manual Appendix 1- Configuration File Format for ASR-L251G The following figure is a configuration file. You can refer to it. Configuration file name and format: ASR-L251G_Parameter.txt  File content format:  For example: Power=30dBm, and Buzzer=On, Vibrator=On, and Link Profile=3.
  • Page 22 AsBridge ASA-112M User’s Manual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uzzer and Vibrator Buzzer and Vibrator State Hex data Buzzer on & Vibrator on BB00AB0003FFFF007E4A55 Buzzer on & Vibrator off BB00AB0003FF00007E8536 Buzzer off &...
  • Page 23 AsBridge ASA-112M User’s Manual Session and Session Flag Session Session Flag Hex data Only A BB0077000801000009000000007ED224 Only A BB0077000801000009200000007EDA90 Only A BB0077000801000009400000007EC34C Only A BB0077000801000009600000007ECBF8 Only B B0077000801000009100000007ED67E Only B BB0077000801000009300000007EDECA Only B BB0077000801000009500000007EC716 Only B BB0077000801000009700000007ECFA2 Any one A or B BB0077000801000509030000007E4551 Link Profile Link Profile...
  • Page 24 AsBridge ASA-112M User’s Manual BB00770008010007032C0100007EB849 BB0077000801000703900100007E1D5C Sleep Time Sleep Time (sec) Hex data BB00E90002003C7E00DD BB00E90002012C7E349E 1800 BB00E9000207087E4C1C Auto Off Time Auto Off Time (sec) Hex data BB00E70002003C7E807E BB00E70002012C7EB43D 1800 BB00E7000207087ECCBF Threshold Threshold (0.1dBm) Hex data BB0077000801002C0B320000007E2D94 BB0077000801002C0B3C0000007EE23C BB0077000801002C0B460000007EB914...

  • Page 25: Appendix 2- Configuration File Format For Asr-R202G

    AsBridge ASA-112M User’s Manual Appendix 2- Configuration File Format for ASR-R202G The following figure is a configuration file. You can refer to it. Configuration file name and format: ASR-R202G_Parameter.txt  File content format:  For example: Buzzer=On, and Vibrator=On. File content: Buzzer_High>F1FF0101CC00067E7762320D0A7F925D>Vibrator_On>F1FF0101C C00067E7771310D0A7FE309<...

  • Page 26: Appendix 3-Configuration File Format For Asbridge

    AsBridge ASA-112M User’s Manual Appendix 3- Configuration File Format for AsBridge The following figure is a configuration file. You can refer to it. Configuration file name and format: Local_Parameter.txt  File content format:  For example: Check the firmware update file and perform the firmware update. Sets the Sleep time of the AsBridge device to 300 seconds;...
  • Page 27 AsBridge ASA-112M User’s Manual LocalTimeIndicate LocalTimeIndicate Value To change local time Do not change local time...

  • Page 28: Appendix 4- Specifications

    AsBridge ASA-112M User’s Manual Appendix 4- Specifications Model ASA-112M Battery capacity Built-in rechargeable lithium-ion battery 250mAh Built-in Button battery 11mAh Continuous operation > 5 hours time Battery Power source USB cable, Gender ASA-017C Power input 5V/1A Charging time About 2.5 hours (Built-in battery) Power button, Reset button Key input DIP switch (On: Buffer mode;...
  • Page 29 AsBridge ASA-112M User’s Manual AsBridge ASA-112M User Manual 2024/1/8 1.0 Asterisk Inc. Osaka Office Tel: +81 (0) 50 5536 1185 Shin-Osaka Dainichi Bldg. 201, 5-6-16 Nishinakajima, Yodogawa-ku, Osaka-city, Osaka, 532-0011 JAPAN...
