- Page 1 Air Lift Performance 3H /3P ® ® INSTALLATION GUIDE For maximum effectiveness and safety, please read these instructions completely before proceeding with installation. Failure to read these instructions can result in an incorrect installation.
- Page 2 Download the App for the Best #lifeonair The Air Lift Performance 3 mobile app allows for full integration of your new 3H/3P control system on compatible mobile devices. Download the FREE app to take full control of your system and always have the latest system firmware with updates directly from the app.
-
Page 3: Table Of Contents
Notation Explanation ........... . . 3 Installing Air Lift Performance 3H/3P Kit ....4 Layout Overview . -
Page 4: Component List
Item Part # Description ....Qty 16444 or 16444B Compressor (chrome or black) ..1 Varies Tank ........1 HEIGHT CONTENT (OPTIONAL INCLUDED IN 3H SYSTEMS ONLY) Item Part # Description ......Qty Item Part # Description ......Qty 34977 HPACK- Height sensor linkage ...4... -
Page 5: Introduction
Installation Guide Introduction The purpose of this publication is to assist with the installation, maintenance and troubleshooting of Air Lift Performance 3H/3P. ® Read and understand the entire installation guide before beginning installation or performing any maintenance, service or repair. The information includes step-by-step installation information, installation templates and a troubleshooting guide. -
Page 6: Installing Air Lift Performance 3H/3P Kit
Installation Guide Installing Air Lift Performance 3H/3P Kit LAYOUT OVERVIEW For a complete installation diagram, see pages 16-17. See page 2 for a complete parts list. NOTE Layout 1. Plan component location first. Ideally, the manifold should be located at a level above the compressor and tank to avoid compressor ingested water from gathering in the manifold (fig. -
Page 7: Tank (Optional)
Installation Guide TANK (OPTIONAL) Tank pre-assembly 1. Determine tank location and orientation prior to installing fittings. 2. Before installing fittings, apply thread sealant around the male threads, leaving the first two threads uncovered. NEVER BACK OFF AN INSTALLED PIPE FITTING TO ACHIEVE PROPER ALIGNMENT. CAUTION LOOSENING INSTALLED PIPE FITTINGS WILL CORRUPT THE SEAL AND CONTRIBUTE TO LEAKAGE AND FAILURE. -
Page 8: Filter
CAUTION SOURCE, AND WILL DEPOSIT THAT MOISTURE IN THE AIR TANK. THE AIR LIFT PERFORMANCE 3H/3P SYSTEM INCLUDES A FILTER THAT WILL GREATLY REDUCE THE POTENTIAL FOR MOISTURE TO ENTER THE MANIFOLD. HOWEVER, TANKS MUST BE REGULARLY PURGED TO ELIMINATE THE POSSIBILITY OF WATER ENTERING THE MANIFOLD. -
Page 9: Installing Harness
Installation Guide INSTALLING HARNESS The harness can be routed inside or underneath the vehicle. In either case, ensure all parts of the harness are protected from abrasive edges and heat sources. DISCONNECT THE BATTERY GROUND BEFORE INSTALLING THE SYSTEM. CAUTION REMOVE ALL FUSES WHEN JUMP-STARTING OR WELDING ON THE VEHICLE. - Page 10 See Table 2 below for information pertaining to kits that require manifold fitting installation. G THREAD VERSION HAS A RECESSED FRONT Kit Numbers: 3H KITS 3P KITS 27690, 27790 (1/4"NPT - 1/4" AIR LINE) 27680 (1/4"NPT - 1/4" AIR LINE) 27795 (G THREAD)
-
Page 11: Installing Air Lines
Installation Guide INSTALLING AIR LINES 1. Route and attach the air lines from the manifold to the air springs, from the manifold to the filter, and from the filter to the tank, if not mounting filter directly to tank. • Route air lines free from abrasive edges and heat sources. -
Page 12: Manifold
Installation Guide MANIFOLD BEST PRACTICE IS TO LOCATE THE MANIFOLD UNIT INSIDE THE VEHICLE. IF CAUTION EXTERNAL MOUNTING IS DESIRED, THE MANIFOLD SHOULD BE LOCATED IN AN AREA SHIELDED FROM DIRECT WATER SPRAY FROM TIRES OR CAR WASHES. 1. Position the manifold in desired location. Make sure the manifold mounting surface is flat. -
Page 13: Compressor (Optional)
Installation Guide COMPRESSOR (OPTIONAL) 1. Prepare the compressor intake. If it is mounted inside the vehicle, attach the filter to port on end of compressor (fig. 14). If the compressor is located outside the vehicle, snorkel the inlet filter to dry location inside vehicle using components supplied with compressor (fig. -
Page 14: Height Sensors
Installation Guide IF THE PRESSURE-BASED SYSTEM IS ALREADY INSTALLED BEFORE HEIGHT WARNING SENSOR INSTALLATION, MAKE SURE TO TURN OFF RISE ON START TO AVOID UNINTENDED AIRING UP. (SEE USER GUIDE.) HEIGHT SENSORS Installation of height sensors is a trial-and-error process and requires patience. The goal is to use as much of the sensor range as possible, which will maximize height adjustment accuracy. - Page 15 Installation Guide wear and may damage these components. 6. Understand whether the suspension or wheel assembly is the limiting factor when the vehicle is aired out. This will ensure proper accommodation of sensor arm travel. 7. If using self-tapping screws into the frame, make sure there are no wires or brake/ FLOOR JACKS CAN BE DANGEROUS.
- Page 16 Installation Guide SELECTING SENSOR ARM HOLE Max angle of travel for this sensor is 120 degrees, which can be correlated to the necessary suspension travel as seen in the table below (Table 3). Any significant over-extension or over-compression may damage and possibly destroy the sensor or sensor linkage (fig.
- Page 17 Installation Guide LINKAGE ASSEMBLY/MODIFICATION 1. Locate the linkage and ensure the rod is threaded all the way on (fig. 22). Thread both ends all the way down fig. 22 2. Next, put the suspension in the mid-position with respect to full suspension travel (fig. 23). Mid-position Min.
-
Page 18: Installation Diagram
Installation Guide MN-946... - Page 19 Installation Guide Heat-shrinkable butt splice MN-946...
- Page 20 Installation Guide 6. Remove the rod linkage from the sensor arm and measure 1/2" back from the mark. This will show where to cut the rod (fig. 27). Mark Rod cover fig. 27 Cut here 1/2" 7. Before cutting the rod, thread the jam nut back on the rod. Use the nut to deburr the rod end (fig.
- Page 21 Installation Guide VERIFYING SUSPENSION RANGE Use the paper height sensor tool on page 25 or electronic sensor tool in the display to make sure the range is sufficient to provide accurate measurements (fig. 31). (See User’s Guide) Next, manually air the vehicle up and down to see if there is any issue with the travel of the sensor using the height sensor install tool.
-
Page 22: Troubleshooting Guide
Installation Guide Troubleshooting Guide For technical assistance, please contact our customer service department by calling (800) 248-0892, Monday through Friday. For calls from outside the USA or Canada, dial (517) 322-2144 or email techsupport@airliftcompany.com. PROBLEM CAUSE SOLUTION Compressor doesn’t run. Check for a blown fuse, bad relay, poor ground, Replace the 30A or 3A fuse if blown. -
Page 23: Leak Testing And Detection
Installation Guide Leak Testing and Detection 1. A leak can be defined as a loss of pressure of more than 5 PSI over an 8-hour period. Be aware that ambient temperature change affects pressure that may seem like a leak. For example: a change of 10 degrees F up or down from your baseline will have an approximate gain or loss of indicated pressure of 2 PSI. -
Page 24: Permissible Modifications
Air-Zenith Harness ground 3. The keypad on the 3H/3P display can be rotated for horizontal applications, but it must not be rotated so that the keypad is above the screen (fig. 34). It will not power up in this position. -
Page 25: Display Mounting Template
Installation Guide 5. Optional Accessory Stance Guard: When installed in line with the 3P/3H display, the buzzer dongle (Fig. 36) will generate an audible beep when the air spring pressure is too low or too high. fig. 36 Display Mounting Template IMPORTANT: PRINT THIS MANUAL AT 100% SCALE. -
Page 27: Height Sensor Install Tool
Installation Guide Height Sensor Install Tool 120˚ 120˚ 100˚ 100˚ 80˚ 80˚ 60˚ 60˚ 120˚ 120˚ 100˚ 100˚ 80˚ 80˚ 60˚ 60˚ Cut out the height sensor tools and position each one as shown at right depending on the height sensor orientation. -
Page 29: Manifold Mounting Template
Installation Guide Manifold Mounting Template 3 13 16 " 5/16-18 UNC Thread (1/4-14 Self Tapping 1 7 8 " Screw included in kit) 6 3 8 " " MN-946... -
Page 31: 16444 Compressor Mounting Template
Installation Guide HOLE PATTERN FOR 16444 COMPRESSOR 8 1/2” 3 5/16” MN-946... - Page 33 Installation Guide Notes MN-946...
-
Page 34: Limited Warranty And Return Policy
Limited Warranty and Return Policy Air Lift Company provides a 1-year limited warranty* to the original purchaser of Air Lift Performance products from the date of original purchase, that the products will be free from defects in workmanship and materials when used on cars and trucks as specified by Air Lift Company and under normal operating conditions, subject to the requirements and exclusions set forth in the full Limited Warranty and Return Policy. - Page 36 (800) 248-0892, Monday through Friday. For calls from outside the USA or Canada, dial +1 (517) 322-2144. Thank you for purchasing Air Lift Performance products! Air Lift Company • 2727 Snow Road • Lansing, MI 48917 or P.O. Box 80167 • Lansing, MI 48908-0167 Toll Free (800) 248-0892 •...
