ASROCK N68PV-GS Brochure

N68PV-GS
NVIDIA ® GeForce 7050 / nForce 630A MCP Chipset
Product Brief
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD
playback
- NVIDIA PureVideo
®
- Gigabit LAN
- Supports Smart BIOS, ASRock OC Tuner
(Up to 130% CPU frequency increase & 210%
FSB Speed increase)
- Supports Extra ESD Protection, Intelligent
Energy Saver (Up to 15% CPU Power Saving)
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Ready
TM
www.as rock.com

Detail Specification

Platform - Micro ATX Form Factor: 9.6-in x 7.2-in, 24.4 cm x 18.3 cm
CPU
- Support for Socket AM2+ / AM2 processors: AMD
Phenom FX / Phenom / Athlon 64 FX / Athlon 64 X2
TM
Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron
processor
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset
- NVIDIA ® GeForce 7050 / nForce 630A MCP
- Dual Channel DDR2 memory technology
Memory
- 2 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 4GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
- Integrated NVIDIA
Graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Dual VGA Output: support DVI-D and D-Sub ports by
independent display controllers
- Supports HDCP function with DVI-D port
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
- NVIDIA PureVideo
®
Audio - 5.1 CH Windows
(ALC662 Audio Codec)
- Chipset embedded HDMI Audio
LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Realtek RTL8211CL
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector
- 4 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ, AHCI and
"Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x COM port header
- 1 x Print port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology
to boost memory performance up to 12.5%
Hardware Monitor - CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS
- Microsoft ® Windows
Vista TM 64-bit compliant
Certifications
- FCC, CE
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 cables (optional)
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
® GeForce7 Series (NV44)
Ready
TM
® Vista™ Premium Level HD Audio
® 2000 / XP / XP 64-bit / Vista TM /
