- Page 1 R E C TA N G L E SMART LOCK E N T R Y PREMIUM CONVENIENT KEYLESS ENTRY FINGERPRINT PIN CODE WI-FI MESSAGE KEY FOB 6-PIN C4 KEYWAY OVERRIDE...
- Page 2 S M A R T L O C K M A N U A L INDEX...
-
Page 3: Table Of Contents
FEATURES LOCK SETUP INSTALLATION FUNCTIONS Video guide LOCK MAIN MENU Door direction Change handle direction QUICK START Installing the Smart Lock LOCK SETTINGS MENU REPLACING BATTERIES Admin settings User settings RESTORE TO FACTORY SETTINGS Other settings EMERGENCY POWER SUPPLY Data and records Other functions MOBILE AND WI-FI SETUP Pairing with the mobile app... - Page 4 COMPONENT Front plate Back plate M5 x M6 x 30 screw bolt M4 x 25 countersunk head screw Spindle Strike plate Strike plate box M5 x 45 screw M3 x 6 screw Battery cover Screw cap High security dead latch Fobs Keys...
-
Page 5: Features
F E A T U R E S MESSAGE WI-FI PIN CODE 6-PIN C4 KEYWAY FINGERPRINT BACK PANEL FRONT PANEL KEY OVERRIDE KEY FOB... -
Page 6: Installation Video Guide
I N S T A L L A T I O N STEP BY STEP VIDEO INSTALLATION INSTALLATION VIDEO GUIDE S C A N H E R E... -
Page 7: Door Direction
DOOR DIRECTION LEFT IN RIGHT IN LEFT OUT RIGHT OUT STEP 1 Identify the direction in which the door opens. -
Page 8: Change Handle Direction
CHANGE HANDLE DIRECTION OF THE FRONT PANEL 180° RIGHT HANDED LEFT HANDED STEP 1 FOR RIGHT HANDED FRONT PANEL FOR LEFT HANDED FRONT PANEL Remove the screw from ‘L’ side, rotate handle to Remove the screw from ‘R’ side, rotate handle to the right side and re-fix screw in the ‘R’... - Page 9 CHANGE HANDLE DIRECTION OF THE BACK PANEL RIGHT HANDED LEFT HANDED 180° 180° STEP 1 FOR RIGHT HANDED BACK PANEL FOR LEFT HANDED BACK PANEL Remove the screw below the spindle, rotate Remove the screw below the spindle, rotate reversing device to ‘R’ direction and re-fix screw. reversing device to ‘L’...
-
Page 10: Installing The Smart Lock
INSTALLING THE SMART LOCK STEP 1 STEP 2 STEP 3 Position the drilling template on Insert the high security dead Push the spring in and fix the the door, and create holes. latch, and fasten screws tight. spindle to the clutch on the front plate. - Page 11 STEP 4 STEP 5 Feed the cable, spindle and screw bolts through Connect the back plate cable to the front panel the door holes from outside to inside. cable. Align the back handle to the spindle. Fix with screws.
- Page 12 STEP 6 STEP 7 Install the batteries and battery cover. Insert the strike plate box and strike plate. Fasten with screw. Fasten with screws.
-
Page 13: Replacing Batteries
R E P L A C I N G B A T T E R I E S STEP 1 Remove battery cover. STEP 2 Replace all four batteries with AA Alkaline batteries for optimum usage. -
Page 14: Restore To Factory Settings
R E S T O R E T O F A C T O R Y S E T T I N G S STEP 1 Remove battery cover. STEP 2 Hold the SET button for 5 seconds to reset lock to the default factory settings. -
Page 15: Emergency Power Supply
E M E R G E N C Y P O W E R S U P P L Y USB-C PORT KEYWAY STEP 1 In case the battery fails and the lock cannot be Alternatively, proceed to unlock the door using opened from the outside, a 5V power bank can the overriding keys provided. -
Page 16: Mobile And Wi-Fi Setup
M O B I L E A N D W I - F I S E T U P FOR A COMPLETE SMART HOME SYSTEM DOWNLOAD THE GRID CONNECT APP AVAILABLE TO DOWNLOAD FROM DOWNLOAD PAIR... - Page 17 STEP 1 Download the Grid Connect SCHEDULED ACCESS App from the App Store or the Google Play Store, or Generate a temporary code for scheduled alternatively scan the QR code. access by name, date, time and expiry. STEP 2 NEW USERS If you are a first time user, ‘Create new account’...
-
Page 18: Pairing With The Mobile App
PAIRING WITH THE MOBILE APP STEP 1 STEP 2 STEP 3 Once logged into your Grid At the add device menu, Enter your Wi-Fi details and Connect account, tap “add choose the category “Others”. network password. Network device” or “+” icon. must support 2.4GHz. - Page 19 PAIRING WITH THE LOCK 1. Access the lock settings by pressing * then # into the keypad. 2. Press 000000 into the keypad to input admin information. 3. Select Wi-Fi settings by pressing 1. 4. Select Enable pairing by pressing 1. 5.
- Page 20 STEP 6 STEP 7 While the lock is searching for a device, reopen Once connected, return back to the Grid Connect the mobile app and select “go connect”. App. The app will now attempt to pair with the This will take you to the Wi-Fi settings in lock.
- Page 21 STEP 8 STEP 9 An added successfully screen will show once The app will then open the device home page. completed. Press “Done”. Manage all mobile based features of the lock from this screen. A lock icon will also now be accessible from the Grid Connect dashboard.
-
Page 22: Setting Scheduled Access
SETTING SCHEDULED ACCESS STEP 1 STEP 2 Tap the “scheduled access” icon and select the At the Code Setting page, follow the prompts desired code type. For the initial use, press “Add” to input or generate a code. to open the scheduled access settings page. - Page 23 STEP 3 STEP 4 Complete the required details such as Name (e.g. AT THE LOCK Plumber), start time and end time then press Before the scheduled access can be used, the “Done”. The scheduled access page will show all lock must be synced by pressing “9” then “#” current passwords and their status.
-
Page 24: Adding Users To The App
ADDING USERS TO THE APP Once Admins and Users have been added to the lock (see pg 34–35), new users can be added to use the app. Primary user A primary user is only added to record their details with a door event. -
Page 25: History
HISTORY STEP 1 STEP 2 Tap the “History” icon at the bottom right of the Review all lock entries and events. Once Users device page. have been setup and accounts are linked to user IDs on the lock, their details will appear here. -
Page 26: App Device Settings
APP DEVICE SETTINGS STEP 1 STEP 2 The top right icon “3 vertical dots” will open Access information including device name, additional settings and information. device information, automation options, FAQs and remove device. -
Page 28: Lock Setup
L O C K S E T U P FIVE CONVENIENT WAYS TO UNLOCK YOUR DOOR... -
Page 30: Functions
F U N C T I O N S Activate the lock by touching keypad with the back of your hand Go back or cancel Confirm Default admin password 000000... -
Page 31: Lock Main Menu
L O C K M A I N M E N U Enter setup menu (requires authentication) Enable pairing Default admin password 000000 Delete device Wi-Fi settings Lock settings Admin settings User settings Other settings Data and records... -
Page 32: Quick Start
Q U I C K S T A R T IMPORTANT For the first administrator, a pin code is highly recommended. Avoid common pin codes, or Default admin password 000000 codes that contain repeated numbers or birthdays. Change default Make sure to Lock settings password to remember this pin... -
Page 33: Lock Settings Menu
L O C K S E T T I N G S M E N U Enter setup menu (requires authentication) Lock settings Admin settings Add admin Edit admin Delete admin User settings Add user Edit user Delete user Other settings Passage mode Double unlock Voice setting... -
Page 34: Admin Settings
Press * then # to enter the setup menu. ADMIN SETTINGS Enter the administrator pin code, followed by #. Press 2 for Lock settings. Press 1 for Admin settings. Pin code ADD ADMIN Press 1 to add an admin. Lock settings Enter a pin code (must be 6 or more digits), scan fingerprint or scan key fob, press #. -
Page 35: User Settings
Press * then # to enter the setup menu. USER SETTINGS Enter the administrator pin code, followed by #. Press 2 for Lock settings. Press 2 for User settings. Pin code ADD USER Press 1 to add a user. Lock settings Enter a pin code (must be 6 or more digits), scan fingerprint or scan key fob, press #. -
Page 36: Other Settings
Press * then # to enter the setup menu. OTHER SETTINGS Enter the administrator pin code, followed by #. Press 2 for Lock settings. Press 3 for Other settings. Pin code PASSAGE MODE Press 1 for Passage mode settings. Lock settings Select 1 to enable or 2 to disable. -
Page 37: Data And Records
Press * then # to enter the setup menu. DATA & RECORDS Enter the administrator pin code, followed by #. Press 2 for Lock settings. Press 4 for Data records. Pin code RECORDS QUERY Press 1 to record query. Lock settings STORAGE QUERY Data and records Press 2 for storage query details. -
Page 38: Other Functions
OTHER FUNCTIONS KEYPAD LOCK SCRAMBLE FUNCTION SLEEP The touch panel will be Add random numbers before The display will turnoff locked and inactive for 90 and/or after a valid pin code and enter sleep mode after seconds if the pin code is and press “#”... -
Page 39: Specifications
OPERATING TEMP -10°C – -60°C RELATIVE HUMIDITY 20% – 85% This product comes with a 10 year mechanical guarantee against defects in materials YEAR or workmanship and 5 year electrical guarantee. For full details refer to our website at lemaar.com.au GUARANTEE... -
Page 40: Troubleshooting
T R O U B L E S H O O T I N G PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY Minor scratches or abrasions Protective film not yet removed. Carefully remove protective film. on panels. 1. Check and ensure connector between front and rear door handle is properly plugged in and connected. - Page 41 PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY The door is not automatically Ensure passage mode is disabled. locking after 5 seconds from Lock is in Passage Mode. Lock settings > Other settings > Passage mode > Disable correct pin code? 1. Check that the key is being fully inserted prior to turning. The override key is not turning The key override does not work.
- Page 42 2. Ensure notifications alerts from the app on your phone/device settings. is enabled. Images are used for reference purposes only. The actual product might vary in terms of colour and composition. Lemaar Pty Ltd reserves the right to change existing services without prior notice, at its sole discretion.
-
Page 43: Customer Support
C U S T O M E R S U P P O R T FURTHER QUESTIONS? For further questions or customer support scan the QR code or email customerservice@lemaar.com.au... - Page 44 24–26 Endeavour Way, Braeside Victoria 3195 PHONE +61 3 9580 1630 FAX +61 3 9580 6273 customerservice@lemaar.com.au lemaar.com.au...
