ASROCK N68-GS Brochure

N68-GS
NVIDIA GeForce 7025 / nForce 630a Chipset
®
Product Brief
- Hyper Transport 2000 MT/s
- Supports Dual Channel DDR2 1066
- Integrated NVIDIA
®
DX9.0 VGA, Pixel Shader 3.0, Max. shared
memory 256MB
- Gigabit LAN 10/100/1000 Mb/s
- Supports Smart BIOS, ASRock OC Tuner,
Intelligent Energy Saver, Instant Boot
- Supports ASRock Instant Boot, OC Tuner
(Up to 132% CPU frequency increase & 215%
FSB speed increase)
- Supports Smart BIOS, Intelligent Energy Saver
(Up to 15% CPU Power Saving)
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
GeForce 7025 graphics,
www.as rock.com
Detail Specification
Platform - Micro ATX Form Factor: 9.6-in x 7.0-in, 24.4 cm x 17.8 cm
CPU
- Support for Socket AM2+ / AM2 processors: AMD
Phenom FX / Phenom / Athlon 64 FX / Athlon 64 X2
TM
Dual-Core / Athlon X2 Dual-Core / Athlon 64 /
Sempron processor
- Support for AM3 processors: AMD Phenom
and Athlon II X4 / X3 / X2 processors
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset
- NVIDIA GeForce 7025 / nForce 630a
®
- Dual Channel DDR2 memory technology
Memory
- 2 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI Express x1 slot
- 2 x PCI slots
Graphics - Integrated NVIDIA
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Supports D-Sub with max. resolution up to 1920x1440
@ 60Hz
Audio
- 5.1 CH HD Audio (VIA
LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY RTL8211CL
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector
- 4 x Serial ATAII 3.0 Gb/s connectors, support RAID
(RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ
and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x Print port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
Unique Feature - ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology
to boost memory performance up to 12.5%
Hardware Monitor
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
OS
- Microsoft ® Windows
Vista TM 64-bit compliant
Certifications
- FCC, CE
Accessories - Quick Installation Guide, Support CD, I/O Shield
- ATA 133 cable (optional)
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
II X4 / X3
TM
GeForce7025 graphics
®
VT1705 Audio Codec)
®
® 2000 / XP / XP 64-bit / Vista TM /
