GlobalVision I-Count Assembly Guide

Rev 002

I-COUNT ASSEMBLY GUIDE

25 November 2020

Need help?

Do you have a question about the I-Count and is the answer not in the manual?

Questions and answers

Summary of Contents for GlobalVision I-Count

Page 1 GlobalVision I-Count Assembly Guide Rev 002 I-COUNT ASSEMBLY GUIDE 25 November 2020...
Page 2 GlobalVision I-Count Assembly Guide Rev 002 The GlobalVision I-Count System with Monitor Arm Figure 1: GlobalVision I-Count system with Monitor Arm Note: Do not fully tighten any bolts until every part is assembled. 1 of 25 25 November 2020...
Page 3 GlobalVision I-Count Assembly Guide Rev 002 The following instructions are to assemble the I-Count System: Figure 2: GlobalVision I-Count System without Monitor Arm 2 of 25 25 November 2020...
Page 4 GlobalVision I-Count Assembly Guide Rev 002 Figure 3: GlobalVision I-Count system assembly parts Parts List Part Name Quantity Right Leg Left Leg Horizontal Support Bar Tabletop Computer Tray Diagonal Column Right Side Mounting Bracket for Diagonal Column Left Side Mounting Bracket for Diagonal Column...
Page 5 GlobalVision I-Count Assembly Guide Rev 002 Step 1: Slide the Left Leg (Ref Table 1: Part 2) in the Horizontal Support Bar (Ref Table 1: Part 3), so that the (two) bolt entry points align with one another. Place and fasten the two bolts.
Page 6 GlobalVision I-Count Assembly Guide Rev 002 Step 2: Slide the Right Leg (Part 1) in the Horizontal Support Bar (Part 3), so that the (two) bolt entry points align with one another. Place and fasten the two bolts. Figure 5: Attaching right leg with horizontal support bar...
Page 7 GlobalVision I-Count Assembly Guide Rev 002 Step 3: Place the Tabletop (Part 4) on top of the two legs (Parts 1 and 2) by aligning it with the (four) bolt entry points on each side. Place and fasten the four bolts on each side.
Page 8 GlobalVision I-Count Assembly Guide Rev 002 Step 4: Connect the Computer Tray (Part 5) on the inside of the Right Leg (Part 2) so that its flat surface rests on the Horizontal Support Bar (Part 3) and the (two) bolt entry points align with the other set. Place and fasten the two bolts.
Page 9 GlobalVision I-Count Assembly Guide Rev 002 Step 5: Attach the Right and Left Side Mounting Brackets (Parts 7 and 8) for the Diagonal Column using two bolts per bracket. Ensure that the hook is facing upwards on both brackets. Note: Do not fully tighten any bolts until every part is assembled.
Page 10 GlobalVision I-Count Assembly Guide Rev 002 Step 6: Attach the Diagonal Column (Part 6) to the Right and Left Side Mounting Brackets (Parts 7 and 8) using four bolts (two bolts each side). Figure 9: Attaching the diagonal column to the right and left mounting brackets...
Page 11 GlobalVision I-Count Assembly Guide Rev 002 Step 7: Attach the Main Column (Part 9) on top of the Diagonal Column (Part 6) using four bolts (two bolts on each side). Also attach the column to the table using two bolts from the rear cut out on the column.
Page 12 GlobalVision I-Count Assembly Guide Rev 002 Figure 11: Attaching the main column(Part 2) 11 of 25 25 November 2020...
Page 13 GlobalVision I-Count Assembly Guide Rev 002 Figure 12: Attaching the main column(Part 3) 12 of 25 25 November 2020...
Page 14 GlobalVision I-Count Assembly Guide Rev 002 Figure 13: Attaching the main column(Part 4) 13 of 25 25 November 2020...
Page 15 GlobalVision I-Count Assembly Guide Rev 002 Step 8: Separate the Column Head (Part10) as per the diagram below, by loosening the three bolts. Figure 14: Separating the column head(Part 1) 14 of 25 25 November 2020...
Page 16 GlobalVision I-Count Assembly Guide Rev 002 Figure 15: Separating the column head(Part 2) 15 of 25 25 November 2020...
Page 17 GlobalVision I-Count Assembly Guide Rev 002 Step 9: Slide the right side of the Column Head (Part 10) into the Main Column (Part 9). Figure 16: Sliding column head into main column 16 of 25 25 November 2020...
Page 18 GlobalVision I-Count Assembly Guide Rev 002 Step 10: Next, re-attach the left side of the Column Head to the right side of the Column Head using three bolts. The Column head will be held in position by an aluminum knob positioned on the rear. This knob will anchor into the holes, on the rear of the Main Column (Part 9).
Page 19 GlobalVision I-Count Assembly Guide Rev 002 Figure 18: Re-attaching the column head(Part 2) 18 of 25 25 November 2020...
Page 20 GlobalVision I-Count Assembly Guide Rev 002 Step 11: Attach the Light/Camera Fixture (Part 11) to the Column Head (Part 9) by sliding the tabs from the Column Head into the Light/Camera Fixture. Now tighten the bolts on the Column Head. This will lock the Light/Camera Fixture to the Column Head as one piece.
Page 21 GlobalVision I-Count Assembly Guide Rev 002 Figure 20: Attaching the light/camera fixture(Part 2) 20 of 25 25 November 2020...
Page 22 GlobalVision I-Count Assembly Guide Rev 002 Step 12: Place the Tray Support (Part 12) on top of the table. This piece is not bolted to the table. It is used as a guide for the trays to be counted. The user needs to position this manually for different types of trays.
Page 23 GlobalVision I-Count Assembly Guide Rev 002 Figure 22: : Placing the support tray(Part 2) 22 of 25 25 November 2020...
Page 24 GlobalVision I-Count Assembly Guide Rev 002 Figure 23: : Placing the support tray(Part 3) 23 of 25 25 November 2020...
Page 25 GlobalVision I-Count Assembly Guide Rev 002 Step 13: Connect the Monitor Arm to the right side of the Right Leg (Part 1). Note: Follow instructions with Monitor Arm assembly guide. Figure 24: Connecting the monitor arm with the right leg(Part 1)
Page 26 GlobalVision I-Count Assembly Guide Rev 002 Figure 25: Connecting the monitor arm with the right leg(Part 2) Step 14: Tighten all the bolts to ensure the Flatbed Scanner Table is safe and ready to use. 25 of 25 25 November 2020...
