- Page 1 Operators & Parts Manual SC18 Battery Powered Automatic Scrubber Revolutionizing Floor Scrubbing Simple Clean www.simplecleanscrubbers.com 8050901 866-959-2787 REV.01 (01-2016)
- Page 2 Please dispose of packaging materials,old machine components such as batteries, hazardous fluids, including antifreeze and oil, in an envi- ronmentally safe way according to local waste disposal regulations. Always remember to recycle. Specifications and parts are subject to change without notice. SC18...
-
Page 3: Table Of Contents
OPERATOR MANUAL TABLE OF CONTENTS SAFETY PRECAUTIONS......................4 MACHINE COMPONENTS....................5 MACHINE SETUP & INSTALLATION..................6 MACHINE OPERATION....................7 TANK DRAINING........................8 BATTERY CHARGING......................8 PREVENTATIVE MAINTENANCE..................9 BASIC TROUBLESHOOTING....................10 TECHNICAL SPECIFICATIONS..................11 PARTS LIST........................12-26 WEARABLE PARTS....................27 WIRING DIAGRAM.....................28 SC 18... -
Page 4: Safety Precautions
- Secure machine with wheel blocks prior to jacking the machine up. - Use approved jack or hoist to safely elevate the machine. - Disconnect batteries prior to working on machine. - Wear gloves when handling batteries or battery cables. SC18... -
Page 5: Machine Components
OPERATOR MANUAL macHIne componentS 1. Solution tank 2. Recovery tank 3. Clear cover, Recovery tank 4. Control handle bar 5. Battery meter 6. Vacuum motor switch 7. Brush motor switch 8. Circuit breaker 9. Clear cover, Battery charger 10. Drain hose 11. -
Page 6: Machine Setup & Installation
3. Connect the vacuum hose to the squeegee assembly. Loop the hose by using the hose clip provided. 4. Check the squeegee blades for proper adjustment. SC18... -
Page 7: Machine Operation
4. Pour a recommended defoamer into the an explosion or a fire. Only use recommended recovery tank if excessive foam appears. cleaning chemicals. contact your Simple clean Scrubbers dealer for recommendations on WaRnInG: do not allow foam to enter proper chemicals. -
Page 8: Tank Draining
4. After rinsing out the tank, securely reconnect the tank level hose to the hose fitting, replace the filter assembly cover and be sure the filter screen and the "O" ring is in the correct posi- tion. SC18... -
Page 9: Preventative Maintenance
6. If storing in an area which may reach freezing temperatures, be sure to drain all fluids from the motoR maIntenance machine prior to storage. Any damage caused 1. Contact your Simple Clean Scrubbers dealer for by freezing temperatures will not be covered by any motor maintenance. the warranty. -
Page 10: Basic Troubleshooting
Brush motor will not operate Bad brush motor solenoid Replace brush motor solenoid Faulty brush motor or wiring Contact Simple Clean Scrubbers Dealer Worn motor carbon brushes Contact Simple Clean Scrubbers Dealer Bad vacuum motor switch Replace vacuum motor switch... -
Page 11: Technical Specifications
OPERATOR MANUAL tecHnIcal SpecIfIcatIonS model Sc18 Voltage 24VDC Recovery tank capacity 13 gal / 50 L Solution tank capacity 10 gal / 40 L Cleaning path width 18 in / 450 mm Squeegee width 30 in / 762 mm Drive system... -
Page 12: Parts List
PARTS LIST RECOVERY TANK GROUP SC18... - Page 13 1123608 LOCK NUT, M6 8011007 MUFFLER 8112006 STUD, M6 ×92 1121605 NUT, M6 8112005 GASKET, VACUUM MOTOR 8050106 LOGO, SIMPLE CLEAN 8111008 BRACKET 1421824 FLAT WASHER M8×∮24×2.0 8111007 RECOVERY TANK SUPPORT 8115404 SLEEVE, P/M 1021830 HEX HEAD BOLT M8×30 8111015...
- Page 14 PARTS LIST SOLUTION TANK GROUP SC18...
- Page 15 HEX BOLT, M12 X 30 1021616 HEX BOLT, M6 X 16 1422616 LOCK WASHER, M6 8037020 BRACKET, SQUEEGEE MNTG 8119007 ELBOW, G1/2 8119005 BALL VALVE, G1/2 1021830 HEX BOLT, M8 X30 8013016 2 INCH CASTER 8034012 BRACKET, CASTER 1962025 CLAMP, 16-25MM SC18...
- Page 16 BATTERY, DISCOVER EV24A-A OR TROJAN 24TMX 8114751 JACKET, BATTERY TERMINAL, BLACK 8050476 BATTERY CONNECT CABLE, RED 8050475 BATTERY CONNECT CABLE, BLACK 1321310 SCREW, SELF-TAPPING, ST4.8 X 9.5 8050153 CHAIN 8050151 LID, SOLUTION TANK FILL PORT 8050150 LID, KIT 8050152 SEAL 6210107 FILTER 8013002 BRACKET SC18...
- Page 17 PARTS LIST CONTROL CONSOLE GROUP SC18...
- Page 18 BAFFLE 1123608 LOCK NUT M6 8134501 BRACKET 1021512 HEX HEAD BOLT M5×12,SS 1421515 FLAT WASHER M5×∮15×1.0 1421132 FLAT WASHER M12×∮32×1.5 1121605 HEX NUT M6 8134081 SLEEVE 8134080 SQUEEGEE LIFTING HANDLE 8113104 BALL KNOB M8 1021840 HEX HEAD BOLT M8×40,SS SC18...
- Page 19 BRACKET, MICRO SWITCH 1123305 LOCK NUT M3 8014062 BRACKET, REAR PANEL 8114707 RELAY 8014035 SPRING 8014034 BRACKET, SPRING 8210421 RELAY 1534608 SET SCREW M6 ×8 8014022 TRIGGER 8014031 BUSHING, HEX 8014032 SPRING ROD 8014033 PLATE 1422411 LOCK WASHER, M4 8114101 SHAFT SC18...
- Page 20 PARTS LIST SCRUB HEAD GROUP SC18...
- Page 21 PAN HEAD SCREW M5 X 10 1221512 PAN HEAD SCREW M5 X 12 1421510 FLAT WASHER M5×∮10× 1.0 8116002 PLATE, BRUSH CLAMP 8116003 SPRING CLIP FLAT WASHER ∮ 8.5× ∮ 25.4× 4.5 8116008 HUB, DRIVE, 3-LUG 8116010 1422821 LOCK WASHER, M8 SC18...
- Page 22 LOCK NUT, M8 1439005 8015105 HOUSING, BEARING 8015104 JOINT BEARING 1111008 HEX NUT, M10 8015106 DECAL 8015020 HANDLE, ADJUSTING NYLON WASHER, ∮ 10.5× ∮ 30× 2.5 1511065 SOCKET BOLT M10 X 65 8015115 8015002 BRACKET 8015121 SPACER 1113012 LOCK NUT M10 SC18...
- Page 23 PARTS LIST SQUEEGEE GROUP SC18...
- Page 24 SHORT CLAMP ASSEBLY 1221575 SCREW M5×75 8118200 LEFT BRACKET 1121008 HEX NUT M10 8118600A CLAMP ASSEMBLY 8118624 SPACER 8118623 SHAFT 1123507 LOCK NUT M5 8118109 HOLDER VACUUM HOSE 8118006 VACUUM HOSE 8118000 SQUEEGEE ASSEMBLY, LINATEX 8118000-PU SQUEEGEE ASSEMBLY, PU SC18...
- Page 25 PARTS LIST SOLUTION FLOW GROUP SC18...
- Page 26 FILTER ASSEMBLY, 70 MESH 8119101 BASE, FILTER ASSEMBLY 1622760 O RING 8119103 SCREEN, FILTER, 70 MESH 8119102 CAP, FILTER ASSEMBLY 1421409 FLAT WASHER M4×∮9×0.8 1221412 PAN HEAD SCREW M4X12 8050903 TUBING ID=12MM L=120MM 8018007 SOLENOID VALVE,24VDC 8018004 TUBING 8015060 INLET, TUBING SC18...
-
Page 27: Wearable Parts
BUMPER, ROLLER 8118400 CASTER, 2 INCH 8118001 FRONT SQUEEGEE BLADE, PU 8118021 FRONT SQUEEGEE BLADE, LINATEX 8118002 REAR SQUEEGEE BLADE, PU 8118022 REAR SQUEEGEE BLADE, LINATEX 9040017 PAD HOLDER, 17 INCH 9050018 BRUSH, 18 INCH 8015090 SPLASH GUARD, SCRUB HEAD SC18... -
Page 28: Wiring Diagram
WIRING DIAGRAM WIRING DIAGRAM SC18...
