Summary of Contents for Anywhere AX50 Series
- Page 1 AX50 Series QUICK START GUIDE Applicable for Models AX51, AX52 and AX52e PUBLISHED SEP 1, 2023 REV 1.3 ANYWHERE NETWORKS Copyright © 2023 Anywhere Networks by P2 Mobile Technologies Limited. All Rights Reserved.
-
Page 2: Safety Instructions
1. S AFETY NSTRUCTIONS Compliance is required with respect to voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment, or pose a fire hazard if the limitations are not followed. Read the instructions before you connect the system to its power source. - Page 3 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or modifications not expressly approved by AX52/AX52e Anywhere Network Node for compliance could void the user's authority to operate this equipment. RF Exposure This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
- Page 4 CMIIT ID 本产品上如有无线电发射设备型号核准代码表示产品符合《中华人民共和国无线电管理 条例》，并获国家无线电管理委员会核发“无线电发射设备型号核准证”。 OFCA This product in compliance the HKCA 1039 (Issue 6) standards issued by the Hong Kong Communications Authority. Warning: The 5.15 to 5.35 GHz band is restricted for indoor use in Hong Kong. RCM marking on this product represents the product in compliance with AS/NZS 4268 as regulated by Australian Communications and Media Authority (ACMA).
-
Page 5: Start Guide
AX51, AX52 or AX52e Anywhere Network Node x 1 Mounting kit x 1 Cable gland x 2 Quick start guide x 1 IMPORTANT: Anywhere Node Manager (A-NM) v2.0.x or newer is required for the setup process. It is available at the Anywhere Networks partner portal. - 4 -... - Page 6 ETUP ROCEDURES 3.2.1 EQUIRED QUIPMENT Computer with below system requirements: • Windows 10/11 64-bit • A-NM v2.0.x or newer • NOTE: For the installation of A-NM, please refer to the A-NM User Computer Cat 5e Ethernet cable Manual. Two Cat 5e Ethernet Cables. 802.3at PoE switch or PoE injector (sold separately).
- Page 7 3.2.3 A-NM UICK TAGING Sign up and run the A-NM software in “Quick Staging” mode. Carefully read the Quick Instructions before use, click “NEXT” to go through all of them. Then click “COMPLETE” to start. 3.2.4 DD THE DEVICE INTO THE MANAGED DEVICE LIST As the managed device list is empty, the dialog box “Unmanaged host node”...
-
Page 8: Hardware Installation
- The connection quality of the AX51/ AX52/ AX52e may vary between different environments. - Only use the mounting kits compatible with the AX51/ AX52/ AX52e For best practice, please consult Anywhere Networks authorized installers. 5. H ARDWARE INSTALLATION... - Page 9 Attach Inner Mounting Bracket (item 2) to the AX51/ AX52/ AX52e (item 1) using the 4 sets M8-12L Integrated Screw (item 4). Insert the Hose Clamps (item 8) through the three slots of the Outer Mounting Bracket (item 3). Install the Hose Clamps onto the pole (ø25 to ø75 mm) and tighten the screws on the Hose Clamp until the Outer Mounting Bracket is securely mounted on the pole as shown.
- Page 10 Warning: Weatherproofing the antenna and cable connections is essential and this can avoid cable connections become loose over time due to vibration and prevents water from entering the device. Anywhere Networks recommended that you use butyl rubber and electrical tape to weatherproof all the outdoor connections. For more information of the weatherproofing procedure, please refer to User Manual.
- Page 11 Unit D5, 19/F, TML Tower, 3 Hoi Shing Road, Tsuen Wan, New Territories, Hong Kong Anywhere Networks reserves the rights to change, modify, transfer or otherwise revise the publication and the product specification without notice. All scaling metrics outlined in this document are maximum supported values.
