- Page 1 INSTRUCTION MANUAL Installation, Operation and Maintenance of EN Dishwasher Voila Freestanding FS-DWVOV13PS-INX Dishwasher...
- Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
1. Safety Instructions 1.1. General Safety Warnings 1.2. Installation Warnings 1.3. During Use 2. Installation 2.1. Machine Positioning 2.2. Water Connection 2.3. Water Inlet Hose 2.4 Drain Hose 2.5. Electrical Connection 3. Technical Specications 3.1. General Appearance 3.2. Technical Specications 4. - Page 4 4.5. Water Hardness Table 4.6. Water Softener System 4.7. Settings 4.8. Detergent Use 4.9. Filling The Detergent 4.10. Using Combined Detergents 4.11. Rinse-aid Use 4.12. Filling The Rinse-aid And Setting 16 5. Loading Your Dishwasher 5.1. Recommendations 5.2. Alternative Basket Loads 6.
-
Page 5: Safety Instructions
1. SAFETY INSTRUCTIONS 1. GENERAL SAFETY WARNINGS Read these instructions carefully before using your appliance and keep this ® manual for future reference. Please check the packaging of your machine before installation and the ® outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 6: During Use
All electrical connections must match the values on the plate. ® Ensure the machine does not stand on the electrical supply cable. Never use an extension cord or a multiple socket connection. The plug should be accessible after the machine is installed. After installation, run your machine unloaded for the rst time. - Page 7 The machine door should not be left open. It may cause accidents. ® Place knives and other sharp objects in the cutlery basket in a blade down position. For models with the automatic door-opening system, when the EnergySave option is active, the door will open at the end of a program. To prevent damage to your dishwasher, do not attempt to close the door for one minute after it has opened.
-
Page 8: Installation
CE DECLARATION OF CONFORMITY We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. DISPOSAL OF YOUR OLD MACHINE The symbol on the product or on its packaging indicates that this product may not be treated as household waste. -
Page 9: Water Inlet Hose
2.3. WATER INLET HOSE WARNING: Use the new water inlet hose supplied with your machine, do not use an old machine's hose. WARNING: Run water through the new hose before connecting. WARNING: Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa. -
Page 10: Electrical Connection
2.5. ELECTRICAL CONNECTION WARNING: Your machine is set to operate at 230V AC/50Hz. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the "Technical Specications"... -
Page 11: Technical SpeciCations
Products Product’s Height 850 mm 860 mm 865 mm (±2 mm) If there is no felt on the top of the product; you should take into account this product’s height. B1: If there is felt on the top of the product with 2nd basket; you should take into account this product’s height. -
Page 12: Technical SpeciCations
Lower basket Lower spray arm Filters Rating plate Control panel Detergent and rinse-aid dispenser 10. Cutlery basket 11. Salt dispenser 12. Upper basket track latch 13. Turbo Drying Unit: This system provides better drying performance. 3.2. TECHNICAL SPECIFICATIONS Capacity 13 place settings Dimensions 850(mm) Height... -
Page 13: Salt Usage
4.2 SALT USAGE (IF AVAILABLE) For a good washing function, the dishwasher needs soft, i.e. less calcareous water. Otherwise, White lime residues will remain on the dishes and the interior equipment. This will negatively affect your machine's washing, drying and shining performance. When water ows through the softener system, the ions forming the hardness are removed from the water and the water reaches the softness required to obtain the best washing result. -
Page 14: Test Strip
4.4. TEST STRIP Run water Keep the Set the Shake the Wait through the strip in the hardness level strip. (1min.) tap (1min.) water (1sec) of your machine. NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use lter and renement devices. -
Page 15: Settings
4.7. SETTING • Turn the machine on by pressing the On/Off button. • Press the Program button for at least 3 seconds immediately after the machine is turned on. • Release the Program button when “SL ” is shown. Next, the last setting level is displayed. -
Page 16: Using Combined Detergents
4.10. USING COMBINED DETERGENTS These products should be used according to the manufacturer's instructions. Never put combined detergents into the interior section or the cutlery basket. Combined detergents contain not only the detergent but also rinse-aid, salt replacement substances and additional components depending on the combination. -
Page 17: Loading Your Dishwasher
Brightener Dose Level Indicator Rinse-aid not dispensed r1 is shown on the display. 1 dose is dispensed r2 is shown on the display. 2 doses are dispensed r3 is shown on the display. 3 doses are dispensed r4 is shown on the display. 4 doses are dispensed r5 is shown on the display. - Page 18 Height Adjustable Rack (peg type) The height adjustable racks enable glasses and cups to be placed on or under the racks. The racks can be adjusted to 2 different heights. Cutlery and utensils can also be placed on the racks horizontally. Upper Basket The upper basket includes a mechanism which enables the height of the basket to be adjusted up (1)or down (2) without having to remove the basket.
- Page 19 Upper Cutlery Basket The upper cutlery basket is designed for the placement of large and small cutlery and utensils. WARNING: Knives and other sharp objects must be placed horizontally in the cutlery basket.
-
Page 20: Alternative Basket Loads
5.2. ALTERNATIVE BASKET LOADS Lower basket Top basket... -
Page 21: Programme Table
Incorrect Loads Incorrect loading can cause poor washing and drying performance. Please follow the manufacturer's recommendations for a good performans result. 6. PROGRAMME TABLE Duration Programme Description (min) Fastest program for lightly soiled and recently Mini 14’ used dishes and suitable for 4 place settings. Quick 30’... -
Page 22: The Control Panel
NOTE: PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF DISHES, TAP WATER, AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS. • Only use powder detergent in short programmes. • Short programmes do not include a drying step. • To assist drying, we recommend slightly opening the door after a cycle is complete 7. - Page 23 4. Remaining Time Indicator Programme flow can be monitored via the Wash,Rinse, Dry, End indicators and Remaining Time Indicator. 5. Start/Pause Button Press the Start/Pause button to start the programme. The wash lamp turns on and the Remaining Time Indicator shows the programme duration. It also indicates the remaining time during the programme flow.
-
Page 24: Changing A Programme
13. Extra Drying Indicator If Extra Drying option is selected, extra heating and drying steps will be added into the selected program, so you can ensure that your dishes will be extracted dryer. 14. Extra Fast Indicator Select the Extra Fast function to decrease the duration of a programme, providing more economical water usage. -
Page 25: Cancelling A Programme
7.2. CANCELLING A PROGRAMME If you would like to cancel a programme when it is running. 7.3. SWITCHING THE MACHINE OFF 8:88... - Page 26 NOTE: Do not open the door before a programme is complete. NOTE: At the end of washing programme, you can leave the door of your machine ajar to hasten the drying. NOTE: If the door of machine is opened or power is cut off during washing the programme will continue when the door is closed or the power is restored.
-
Page 27: Cleaning And Maintenance
Crystalight (Model Depending) This technology which have Ion and Light Technology together, provides to extra hygiene. It prevents bad odor during a washing program that includes a drying step. Crystalight function is activated or deactivated by pressing Half Load (4) button for 6 seconds. -
Page 28: Filters
8.1. FILTERS Clean the lters and spray arms at least once a week. If any food waste remains or foreign objects on the coarse and ne lters, remove them and clean them thoroughly with water. a) Micro Filter b) Coarse Filter c) Metal Filter To remove and clean the lter combination, turn it counter clockwise and remove it by lifting it upwards (1).Pull the coarse lter out of the micro lter (2).Then pull and... -
Page 29: Drain Pump
8.3 DRAIN PUMP Large food residues or foreign objects which were not captured by the lters may block the waste water pump. The rinsing water will then be above the lter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on pieces of broken glass or pointed implements. -
Page 30: Troubleshooting
9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not Plug your Dishwasher in. plugged in. Switch your Dishwasher on by Your Dishwasher is not pressing the On/Off button. switched on. Check your indoor fuses. Fuse blown. The programme does not start. Water inlet tap is closed. - Page 31 Use the information in the Wrong wash programme programme table to select selected. the most appropriate programme. Clean the holes in the Spray arms clogged with Partial food wastes spray arms with thin objects. food waste. remain on the dishes. Filters or water drain pump Check the drain hose and clogged or lter misplaced.
- Page 32 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is owing. Separate the inlet hose Water inlet system failure from the tap and clean the lter of the hose.
- Page 33 Customer Service for a period of at least 10 years from the date on which your appliance was placed on the market within the European Economic Area. 11. THE PRODUCT FEATURE Supplier's trade mark Crompton Supplier's model FS-DWVOV13PS-INX Capacity of dishwasher The energy efciency class...
- Page 34 * Energy consumption 234 kwh per year, based on 280 standard cleaning cycles using cold water ll and the consumption of low power modes. Actual energy consumption will depend on how the appliance is used. ** Water consumption 2520 litres per year based on 280 standard cleaning cycles. Actual water consumption will depend on how appliance is used.
- Page 35 WARRANTY REGISTRATION FORM For Installation Crompton / Service / Complaint Kindly call us on 1800 419 0505 (All India toll free number) It is mandatory to install the Dishwasher. by calling our toll-free no. and by our authorised service center only Dealer Name &...
- Page 36 WARRANTY REGISTRATION FORM Name of Customer: Mr/Ms: Address : City : Pin Code: State: Phone No. (Resd./Ofce): Mobile Number: Email :...
