Logic Plus-42
and
Logic Plus-128
Two Wire Irrigation Controllers
P.O. Box 929, 556 S. Mirage Avenue
Lindsay, CA 93247
For Technical Assistance: 800-468-0071 ext. 115
MADE IN THE USA
December 20, 2020
Specifications and Installation Instructions Read Entire Booklet Before Installing

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Logic Plus-42 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hit Products Logic Plus-42

  • Page 1 Logic Plus-42 Logic Plus-128 Two Wire Irrigation Controllers P.O. Box 929, 556 S. Mirage Avenue Lindsay, CA 93247 For Technical Assistance: 800-468-0071 ext. 115 MADE IN THE USA December 20, 2020 Specifications and Installation Instructions Read Entire Booklet Before Installing...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Specifications……………………………………………… 1-4 -Grounding………………………………………………... -Field Surge Protection L-SPD-F........ -Pump Start Relay............3 -Rain OFF………………………………………………….. 4 -Multiple Controller Installation……………………….. 4 -Controller Reset............4 -Setting the Calendar........... 12 Installation Do’s & Don’ts………………………………... 6 Installing the Logic Plus..........7 Programming the Logic Plus......... 8 - 15 Receiver Programming..........

  • Page 3: Specifications

    SPECIFICATIONS FEATURES LOGIC Plus 42 LOGIC Plus 128 Stations Available 1-42 1-128 Programs Available Run Time Per Station 0-10 hours, 59 min. Max. 0-10 hours, 59 min. Max. 0-27 hours-use 250% 0-27 hours-use 250% budget budget Programs 5 & 6 0-59 min., 59 sec.

  • Page 4: Grounding

    Field Wire Outputs 4 Minimum Wire Size 14 gauge 14 gauge Maximum Wire Run 12,000 Feet 12,000 Feet Maximum Number of Receivers Receivers Programmable and Re-Programmable On Board Receiver Programming Capability Remote Receiver Programming use LP-HHRP Enclosure: Box - Stainless steel, locking, wall or pedestal mount. Pedestal –...

  • Page 5: Field Surge Protection L-Spd-F

    .35 amps and holding .25 amps. The relay will act as a slave to the magnetic relay to control the pump motor. You can use up to a 5hp Hit Products pump start relay attached directly to the relay terminal.

  • Page 6: Rain Off

    Fertigation The controller is fitted with a separate relay to operate a 24VAC system with a maximum inrush of .35 amps and holding .25 amps at 24VAC, for application of fertilizer or other material injection systems. A slave relay should be used to operate any auxiliary pumps or injection systems exceeding the above power requirements.
  • Page 7 Receivers away from the controller See diagram page D15. LogicPLUS Warranty Procedure: Receivers – Any Receiver returned for warranty must have the DBC-BR connection attached. If the DBC-BR connection is not attached, warranty is void. Controllers – Any Controller requiring service or warranty, ONLY the control panel and the SPD (Surge Protection / Connection Terminal Panel) board to be returned to factory for repair or replacement.

  • Page 18: Receiver Programming

    Logic Plus Receiver Programming Instructions When programming a receiver with a controller that is installed with the field wires connected: 1. Set the controller in the OFF position. Turn the rotary switch to position 11 (Rain Off/Auto On/Off) use the top right arrow key to turn the setting from ON to OFF.
