ASSEMBLY INSTRUCTIONS
Fletcher Titan Squaring Arm
Shown Assembled on Titan Machine
The Fletcher-Terry Company
65 Spring Lane • Farmington, CT USA 06032-3311
Tel 860.677.7331 or 800.843.3826 • Fax 860.676.8858 •
www.fletcher-terry.com
customerservice@fletcher-terry.com
FORM #060909
Leha ® -Technik GmbH & Co.Kg | Tel.: 02191 - 36270 | E-Mail: info@leha.de | Web: www.leha.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Titan Squaring Arm and is the answer not in the manual?

Questions and answers

Summary of Contents for Fletcher-Terry Titan Squaring Arm

  • Page 1 ASSEMBLY INSTRUCTIONS Fletcher Titan Squaring Arm Shown Assembled on Titan Machine The Fletcher-Terry Company 65 Spring Lane • Farmington, CT USA 06032-3311 Tel 860.677.7331 or 800.843.3826 • Fax 860.676.8858 • www.fletcher-terry.com customerservice@fletcher-terry.com FORM #060909 Leha ® -Technik GmbH & Co.Kg | Tel.: 02191 - 36270 | E-Mail: info@leha.de | Web: www.leha.de...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TITLE PAGE Product Warranty ....................2 Parts Identification ....................2 Base Mounting Holes: Step 1: ..........3 Drill base mounting holes - if necessary Assembly: Step 2: ............4 Remove your machine’s End Cap Step 3: ..............4 Attach Right Side Extrusion Step 4: ..............

  • Page 3: Product Warranty

    The Fletcher-Terry Company warrants the product purchased to be free from defects in parts and workmanship for (1) one year from the date of purchase. The Fletcher-Terry Company warrants that it will repair or replace any such defective parts, providing the product has been under normal use and service and the defective part is returned to The Fletcher-Terry Company at the purchaser’s expense.

  • Page 4: Step 1: Drill Base Mounting Holes - If Necessary

    Drilling Base Holes Note: If your unit has the four holes pre-drilled then jump to Step #2. Step #1a: Remove the End Cap from your machine. Step #1b. 1) Tape the Drill Template, found on last page, onto your Base with the Fold line along the Base edge and the bold double line positioned over the knife (blade) slot.

  • Page 5: Assembly

    Assembly Step #2: Remove the End Cap from your machine for easier installation of the Threaded Base Nuts. Step #3: Loosely attach the Right Side Extrusion Assembly to your Base with Flat Head Screws (x2) and Threaded Base Nuts (x2). Note: The machine Rail Extrusion and Pivot System not pictured for clarity.

  • Page 6: Step 5: Square The Right Side Extrusion

    Squaring & Setting the Scale Step #5: 1) Reattach your machine’s End Cap. 2) Using a carpenter’s square as shown, the longer leg along the Right Side Extrusion edge and the shorter leg along the back side of the Rail Extrusion, square the Right Extrusion Assembly and tighten the two flat head screws.
  • Page 7 Setting the Measuring Stop The Measuring Stop has been designed so you can use the Scale for both the Cutting and Trimming positions of your machine. The material always locates on the left side of the Stop. Set the position of the Stop as follows: - For the Cutting Position: Set the left side of the Stop to the desired location on the Scale.
