1/8
NR100-103/119
IMPORTANT - READ CAREFULLY - KEEP FOR FUTURE REFERENCE
a) WARNING Raised beds and the upper bed in a bunk bed assembly are not good for
children under 6 years old because of the risk of injury from falling from such beds,
b) WARNING If the raised and bunk beds are not used correctly, they can present a serious
risk of injury from strangulation. Never attach or suspend things from the upper bunk bed
that are not going to be used with that bed.
Such things include - but are not limited to - cords, string, sashes, hooks, belts and bags.
c) WARNING Children can find themselves trapped between the bed and wall, or inclined
roof wall, ceiling, adjacent pieces of furniture (such as cupboards) or other items.
To avoid any risk of serious injury, the distance between the upper safety barrier and
surrounding items should not exceed 75 mm - or the distance should be greater than 230 mm.
d) WARNING Do not use the upper bunk bed or a raised bed if a part of the structure
is missing or broken. Spare parts should be requested from the manufacturer or shop.
e) It is essential that the manufacturer's instructions on assembly and use are followed.
f) The recommended size of the mattress to be used with the bed is 1900mm x 900mm,
Maximum mattress thickness: 158mm,
g) Mattresses must be aired to maintain a low humidity and to stop moisture
building up in the bed and its surroundings.
k) The fastenings put in place on assembly should all be properly tightened and
regularly checked. Retighten the fastenings as necessary.
l) This complies with the requirements of the European Safety Standard NF EN 747+A1: 2015.
m) The presence of a night light could give more safety for a child sleeping in an upper bed.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Estella Highsleeper Gaming and is the answer not in the manual?

Questions and answers

Summary of Contents for Kids Avenue Estella Highsleeper Gaming

  • Page 1 NR100-103/119 IMPORTANT - READ CAREFULLY - KEEP FOR FUTURE REFERENCE a) WARNING Raised beds and the upper bed in a bunk bed assembly are not good for children under 6 years old because of the risk of injury from falling from such beds, b) WARNING If the raised and bunk beds are not used correctly, they can present a serious risk of injury from strangulation.
  • Page 2: Table Of Contents

    NR100-103/119 Max. mattress height 60 min Tools needed (not supplied) Ladder can be fitted right or left side. 8x40 3,5x40 D35x12 7x34 15x12 D4x13 7x60 D8x13 7x50 D15x18 M6x75 71x30x3 20x42x70 M6x55 4x30 M6x15x15 D6x10x13 6,3x70 GLUE 55/12,5x5...
  • Page 3 8x40 7x60 7x34...
  • Page 4: C 15X12 X4 P D20 X4

    to attach desk place this hole upwards D35x12 15x12 Always placed inside the ladder 7x50 D4x13 x20...
  • Page 5: T D15X18 X18

    to attach desk place these holes upwards M6x75 M6x10x13 x8 6,3x70 D15x18 x10...
  • Page 6: K 55/12,5X5 X2

    Max. Decide which side to attach ladder. mattress height ASSEMBLING LADDER LEFT SIDE M6x75 M6x15x15 M6x55 55/12,5x5 M6x10x13 x4 D15x18...
  • Page 7 60-75mm 3,5x40 71x30x3...
  • Page 8 Important! To secure the bed it is necessary to fix the bed to the wall by mounting the 2 brackets L as shown on the illustration. D8x13 20x42x70 4x30...
  • Page 15 Email: service@kids avenue.co.uk By Post: Kids Avenue, The Old Mill House, Dockfield Rd, Shipley, BD17 7AD (Our office is open during normal working hours Mon Fri 9.ooam – 5.00pm) Please ensure that you provide all product information to avoid delays in processing. We...
