Sunbeam 30310906 Manual

IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Thank you for purchasing this Sunbeam
Power Failure Night Light. Please read all instructions before using your new
Power Failure Night Light.
IMPORTANT: FOR INDOOR AND DRY LOCATION USE ONLY.
SPECIFICATIONS
Charging time: Minimum 10 hours
Battery type: Built-in rechargeable 3.6V 500mAh Ni-MH battery
Runtime for power failure light: 16 hours
Rating: 120VAC, 60Hz, max. 1.5W
PARTS AND FUNCTIONS
Motion Sensor Night Light
Color changing LED automatically turns on
when the sensors detect motion and there is
a lack of ambient light; automatically turns
off when motion stops or there is sufficient
ambient light.
Power Failure Light
White light will automatically turn on during
a power outage. After 60 seconds, white
light will turn off until motion is detected in
low ambient light, or if the ON / OFF switch
is pressed.
Color Changing and Color Adjustable
Automatic Night Light with Photo Sensor
Color changing LED turns on with lack of
ambient light. Automatically turns off when
there is sufficient ambient light.
Auto Dimming
Under night light mode, unit auto adjusts to a
lower brightness if no motion is detected by
motion sensor for 25 seconds.
Rechargeable LED Flashlight
SAVE THESE INSTRUCTIONS
MOTION SENSOR SWITCH SETTINGS:
Motion Sensor
ON Mode
Night light will turn on for 25 seconds.
If no motion is detected, unit will turn off.
Motion Sensor
OFF Mode
Night light will turn on for 25 seconds. If no
motion is detected, unit will automatically dim.
If motion is detected, unit will return to full
brightness. Night light will remain lit until
ambient light is detected.
ON / OFF and Color
Function Button
When the unit is first plugged in, it will begin to
automatically cycle through the colors by default.
For white color, click the ON / OFF button.
Flashlight: When the unit is unplugged from
the wall, press the ON / OFF button to turn the
flashlight on. Press the ON / OFF button again to
turn the flashlight off. Press the ON / OFF button
once again to illuminate the white LED on the
front panel.
NOTE: The unit automatically returns to the
continuous color changing default setting
once power has returned or when the unit is
unplugged and then plugged back into the
wall outlet.
MODEL# 30310906
5-IN-1 InstaBeam LED Color Changing
®
15 m
70
49 ft
OPERATION
Two Night Light Modes
Continuous Color Changing Night Light
This is the default setting. The unit will
continue to cycle through the colors unless
the ON / OFF button is pressed to display a
single color. To return to the default setting,
press and hold the ON / OFF button until the
continuous color changing mode restarts.
Single Color Night Light
To select a single color, simply press the
ON / OFF button to stop the color cycling on
the desired color. To change the single color,
continue to press the ON / OFF button to cycle
through the 13 color selections. To return to
the default setting, press and hold the
ON / OFF button.
ITEM# 11690
Plug the LED power failure light into a wall
socket (upright [FIG. 1] or downfacing [FIG. 2]).
Charge for 24 hours before first use.
Complete charging time is 10 hours thereafter.
CAUTION:
5h
is not a toy and is not intended for use by children. For adult
use only. Do not plug in extension cords. Indoor use only. For
safe use, plug only into exposed wall outlets where device is
ventilated and cannot contact bed coverings or other material
1 white LED
for flashlight
that may present a fire hazard.
Photo sensor
Motion sensor
Color changing
This device complies with Part 15 of the FCC
night light /
Rules and Industry Canada ICES-005 standard.
White power
failure light
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
ON / OFF and color
function button for compliance could void the user's authority to
operate the equipment. NOTE: This equipment
Motion sensor
has been tested and found to comply with the
switch
limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
Foldable plug
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from the to which the receiver
is connected.
- Consult the dealer or an experienced radio / TV
technician for help.
LIMITED WARRANTY This product has a limited warranty of 1 year from the original date of purchase against
workmanship and defects in material. If under normal use, your product fails to operate, please contact our
customer service department at info@stareliteinc.com. A refund or replacement will be provided to you with
proof of purchase. Star Elite Inc. may deny claims of damage caused by misuse or modifications of this product.
If you have any problems, please do not
contact the store. Contact our customer
service at 1-877-383-6399
(8:30 am - 5:00 pm E.S.T.) Monday - Friday (EN / FR).
or contact us at info@stareliteinc.com.
Our customer service will be happy to assist you.
© 2022 Sunbeam Products, Inc. All rights reserved.
SUNBEAM logo is a registered trademark of
®
Sunbeam Products, Inc. used under license. Distributed
by Star Elite Inc., Montreal, Canada H3B 3X9.
SE025-030922
SAVE THESE INSTRUCTIONS
HOW TO CHARGE
FIG. 1 FIG. 1
Risk of electric shock and fire hazard. This product
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using this product, basic
precautions should always be followed,
including the following:
a) Read all the instructions before using the
product.
b)
To reduce the risk of injury, close
supervision is necessary when the product
is used near children.
c) Do not put fingers or hands into the product.
d) Use of a power supply or charger not
recommended or sold by power pack
manufacturer may result in a risk of fire or
injury to persons.
e) Do not expose a power pack to fire or
excessive temperature. Exposure to fire or
temperature above 100 °C / 212 °F may
cause explosion.
Have servicing performed by a qualified
f)
repair person using only identical
replacement parts. This will ensure that the
safety of the product is maintained.
FIG. 2 FIG. 2
CAN ICES-005(B) /
NMB-005(B)
MADE IN CHINA
