Caldera SSK Series Installation Manual

Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

SSK Series Installation Manual
WHAT'S IN THE BOX
·
SSK-365 Series, 36" -5 burner Model # SSK365LP-US or SSK365NG-US
·
SSK-305 Series, 30" -5 burner Model # SSK305LP-US or SSK305NG-US
·
2
Side Grates, 1 Center grate
·
Accessory Sleeve Containing the following:
Five Brass Flame Rings
Five Cast Iron Burner Cap
Five Knobs
Flat Steel Burner Ring Wrench PLEASE SAVE THIS TOOL!
Store it with the Use and Care Manual for future use.
Regulator
·
A Plastic bag containing the following:
Use and Care
Installation Manual
Warranty information
Before you begin: Read the instructions carefully!
FOR YOUR SAFETY
WARNING: If the information in this
manual is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a
neighbor's home.
Follow your gas supplier's instructions.
If you cannot reach your gas supplier call
.
the fire department
INSTALLATION AND SERVICE MUST
BE PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR
THE GAS SUPPLIER.
C
A
L
D
E
R
Electrical Requirements
Your gastop must be connected to a properly
grounded 115 volt AC 60 Hz, 15 amp electrical
service. It is the personal responsibility and
obligation of the customer to contact a qualified
electrician/installer and have the unit installed by
a qualified installer and connected to a properly
grounded circuit in accordance with local codes
of your area or, if no codes apply, the National
Electric Code, ANSI/NFPA 70- Latest Edition
must be followed. Copies are available by writing:
National Fire Protection Association
Battery March Park
Quincy MA 02269
In Canada follow CAN/CSA-C.22.1,
Canadian Electrical Code, Part 1.
Copies are available by writing:
178 Rexdale Boulevard
CANADA, M9W 1R3
1
A
or
CSA
Toronto, Ontario,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSK Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Caldera SSK Series

  • Page 1 SSK Series Installation Manual WHAT'S IN THE BOX · SSK-365 Series, 36” -5 burner Model # SSK365LP-US or SSK365NG-US · SSK-305 Series, 30” -5 burner Model # SSK305LP-US or SSK305NG-US · Side Grates, 1 Center grate · Accessory Sleeve Containing the following:...

  • Page 2: For Your Safety

    ™ Caldera Gastop Installation Before installing the Caldera™ gastop, visually inspect the cooking surface, burners, and control areas for evidence of damage, which may have occurred during shipping or delivery. MINIMUM CLEARANCES Location Prior to installing your gastop it is important to select an appropriate location.
  • Page 3 Dimension and Clearance clearance between the centers of the side burner Cabinets If you choose to have a cabinet above the and the sidewall. The back wall must be a gastop the maximum depth is 13 inches (330 minimum of 8-1/2 inches from the center of the mm).

  • Page 4: Provide Adequate Gas Supply

    GAS SUPPLY CONNECTIONS Recommended Gas Supply Location From Back Wall From center line of cooktop 1" Min. 15 ˝" from back wall 12" Min. Regulator 10" Min. 24" Max. (shipped with unit) Shut Off Valve (to be provided by installer) View facing wall A manual valve must be installed in an accessible location in the gas line external to the appliance for the purpose of turning on or shutting off gas to the appliance.

  • Page 5: Countertop Cutout Dimensions

    COUNTERTOP CUTOUT DIMENSIONS The SSK365 is 36" x 21”. The cutout is 34-1/2” wide 34-1/2” for the SSK365 and 19-1/2” deep 28-1/2” for the SSK305 The SSK305 is 30” x 21” The cutout is 28-1/2”wide and 19-1/2” deep Cooktop be centered in cutout MUST Chassis is 4-1/8”...
  • Page 6 Connecting the Gas Supply Line The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 - Latest Edition and CAN/CSA-B149.1 Natural Gas and Propane Installation Code. Some local codes do not allow the use of copper gas piping flexible connectors. Where allowed, use only a new gas certified flexible connector to form the gas line.

  • Page 7: Specifications

    Specifications SSK365LP-US SSK305LP-US SSK365NG-US SSK305NG-US Minimum Inlet Pressure LP...11”w.c. NG...6”w.c. Max. Inlet Pressure LP...14”wc. NG... 14"w.c. Manifold Pressure LP 10”w.c. NG...5”w.c. Total Input 54,000 Maximum Input left front burner(BTUH) 6,000 Minimum Input left front burner (BTUH) Maximum Input left rear burner (BTUH) 9,000 Minimum Input left rear burner (BTUH) 1,100...

  • Page 8: Do Not Use An Extension Cord

    CAUTION: DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE THE THIRD (GROUND) PRONG FROM THE POWER CORD. Replacement parts may be obtained by calling Caldera at 1-800-725-7711 or 1-802-244-3000 or contact: customerservice@calderacorp.com Improper installation, alteration, service or maintenance can cause injury or property damage. For assistance or...
