Summary of Contents for KOCOM KHN-T100M9
- Page 1 [For Administrator] WALL-PAD Use & Installation Manual KHN-T100M9 This manual may be changed without prior notice for quality enhancement purposes.
-
Page 2: Table Of Contents
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] WALL-PAD Use Manual Contents Caution for Safety Product Component Product Specifications Installation Location Installation Method Product Sockets... -
Page 3: Caution For Safety
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Cautions for safety ※ For safe use, please stick to the following cautions. Warning and directions for safety ※ The meaning of the drawing signs. Mishandling the device with ignoring Warning Caution... - Page 4 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Cautions for safety ※ For safe use, please stick to the following cautions. Warnings and Precautions for Safety HOME NETWORK TOUCH WALL PAD · Do not insert metal into the cover of the fuse, as such an act may lead to electric shocks.
- Page 5 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Cautions for safety ※ For safe use, please stick to the following cautions. Warnings and Precautions for Safety Warning Warnings for usage · Do not install this unit near the fire, for example, near kitchen sink, heater or the like.
- Page 6 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Cautions for safety ※ For safe use, please stick to the following cautions. Warnings and Precautions for Safety Warning Caution when discarding · Do not discard or leave used batteries where fire caution is present. An explosion can cause fire or burns.
- Page 7 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Cautions for safety ※ For safe use, please stick to the following cautions. Warnings and Precautions for Safety Caution Cautions for set-up · The law limits distributing the power lines to an authorized person from government.
-
Page 8: Product Component
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Product Component Wall-Pad (KHN-T100M9) ■ Monitor ■ Wall hanger frame ■ Connector wiring for power supply ■ 26P IDE cable connection wiring (1ea) (AC 220V) connection (1ea) ■ Terminal board (1ea) ■ Monitor fixing screw ■Wall hanger frame... -
Page 9: Product Specifications
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Specifications Wall-Pad (KHN-T100M9) Model KHN-T100M9 (ITEM : HOME NETWORK TOUCH WALL PAD) 15W (FULL LOAD) 170mA / 6W (ON STAND BY) 110mA Power Comsumption Power Source , 2A 10 inch touch LCD... - Page 10 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Name and functions of each part 모니터 (KHN-T100M9) 전 면 후 면 Power Switch : Turns the power on or 26 PIN IDE Cable Connection Wiring AC Cord : Connects the 12V/2A power off for the product.
-
Page 11: Installation Location
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Installation Location Monitor installation location ·Standard monitor installation height is about 1,500mm where screen center is at eye level. In this case, wall-hanging metal center (center of piping) is 1,450mm above ground level. -
Page 12: Installation Method
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Installation Method Wall-Pad (KHN-T100M9) 1) Separate the rear case at the back of the monitor. 2) Fix the rear case to the stealth box using the screws (4 pieces on each corner). -
Page 13: Product Sockets
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Product Sockets KHN-T100M9 Back Side AC CORD ADAPTER 26 PIN IDE CABLE 통신+ 통신- +12V 현관카메라 VOICE VIDEO Terminal Board KC-T80M9 Back Side GND (Wihte/Orange) VIDEO (Orange) VOICE (White/Green) GND (Green) 485- (White/Blue) - Page 14 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] WALL-PAD Use Manual Contents Main Screen Main screen manual Menu Screen Lookup Quick menu settings Announcements Menu screen settings Visitor check Background screen selection How to selectively delete visitor screen video 33...
-
Page 15: Main Screen
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Main Screen 1. Main Screen Manual User Menu Displays the menu set by the user. Displays the menu set by the user; the home menu is fixed Home Menu onto the screen even when the it is swiped and turned over. -
Page 16: Menu Screen
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Menu Screen 1. Quick Menu Settings Quick Menu When you tap and scroll the settings section at the top right of [Quick Menu], you will go to the corresponding screen. (See page 15) Black Box 1. -
Page 17: Menu Screen Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Menu Screen 2. Menu Screen Settings 1. Tap and below, or from below to above at the main scroll from above to screen to go to the corresponding screen. 2. When you tap the menu icon for 2 or more seconds, the home menu icon will be displayed on the main screen,allowing you to manually designate the location. -
Page 18: Background Screen Selection
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Menu Screen 3. Background Screen Selection - You can change the background by using the icon mode’s [ ] background selection menu. 4. Widget Screen - Swipe from left to right on the main screen to display the widget screen. -
Page 19: Self Emergency
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI SecurityMode 1. Self-Emergency 1. When an emergency occurs within the house, press onto the <Emergency> button on WALL-PAD for 3 or more seconds; the <Emergency Notification> delivered to the guard office and management office devices. -
Page 20: Call
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 1. About Call Menu 1. Tap the Call>, or <Front Door Call>, <Unit Call>, <Guard Office <Management Office Call>icon. About Menus Monitors and makes calls between unit front doors. -
Page 21: Call Menu
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 2. Call Menu 1. All calls maintain a 30-second and a 3-minute <Call On> <Tell On>; if the set time expires, each function is handled as <Call Off>... -
Page 22: Viewing Situation Outside The Door
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 3. Viewing Situation Outside the Door “Outside the door” is limited to the outside of the unit’ s front door. / Door opening is only available during phone calls. -
Page 23: Front Door Call (Upon Visit)
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 4. Front Door Call (Upon Visit) 1. When the visitor presses the front door camera's button at the unit's front <Call> door, you will hear the comment, <A call sound has been detected at... -
Page 24: Opening Lobby
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 5. Opening Lobby 1. When a call signal is detected at the lobby,you will hear the comment, <A call sound has been detected at the lobby>. 2. The video of the visitor will be played through the unit device (WALL-PAD) screen inside the unit. -
Page 25: Connecting To Management Office From Unit
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 6. Connecting to Guard·Management Office from Unit [Guard Office] The phone call automatically ends if it lasts for 3 minutes or longer. 1. The default functions of the guard office phone call is entering the menu <Call>;... -
Page 26: When Unit Receives Call From
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 7. When Unit Receives Call From Management Office 1. The voice line, <A call arrived from the guard office or management appears, and moves to the office>... -
Page 27: When Visitor Arrives At The Front
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 8. When Visitor Arrives at the Front Door During Call 1. Phone Call Between Guard Office and Unit 2. When Visitor Arrives 전화가 울릴때 방문객이 왔을 때... -
Page 28: Unit Call
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call 9. Unit Call - The basic functions of generation calls are voice calls and video calls (video blocking/permission) functions. 1. Click the icon <Unit Call> 2. Type of the generation you want to call on on your keyboard. -
Page 29: Switching Calls Available
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call ( Front Door Call Occurrence During 10. Switching Calls Available Call With Guard Office ) 1. The incoming call information is displayed. 2. The user receives the display for the another incoming call during an incoming or outgoing call. -
Page 30: Switching Calls Available
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Call ( Answering Front Door Call 11. Switching Calls Available With Smartphone ) 1. When receiving a front door call with a smartphone, you cannot receive the same call with WALL-PAD. -
Page 31: Lookup
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Lookup 1. Announcements 1. Tap the icon to go to the announcements screen. <Announcement> 2. You can check recent announcements. You can check up to <8> announcements, and you can display up to <254 characters>for its content. -
Page 32: Visitor Check
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Lookup 2. Visitor Check 1. Tap the icon to go to the Visitor Information screen. <Visitor Lookup> 2. For "Call On" of the front door and lobby, their videos are saved after 3 seconds;... -
Page 33: How To Selectively Delete Visitor Screen Video
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Lookup 3. How to Selectively Delete Visitor Screen Video 1. Select the photo to delete from the list on the left and tap the icon. <Delete> Only the current video list will be deleted. -
Page 34: Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 1. About Settings Menu - This menu allows you to easily configure the environment of the device. 1. Tap the icon on the menu screen. <Settings>... -
Page 35: Sound Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 2. Sound Settings 1. Tap the section. <Sound> 2. The sound settings screen is displayed. Use it to control the volume of phone calls and voice comments. -
Page 36: Password Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 3. Password Settings 1. Tap the icon. <Password> 2. The password setting screen is displayed. Enter the password on the entry bar and tap <Save>. (The default 4-digit password is '9999'.) ※... -
Page 37: Smartphone Connection
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 4. Smartphone Connection 1. Tap the section. <Smartphone connection> Tap the button to enter the number appearing on the popup to the Smart Home app. -
Page 38: Language Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 5. Language Settings 1. Tap the section. <Language> 2. The section displays the list of languages supported by WALL-PAD; tap the language you wish to apply. Please Note! ※... -
Page 39: Help
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Settings 6. Help 1. Tap the section. <Help> 2. Scan the QR code to check the WALL-PAD manual through a mobile device. 3. The QR code image is stored in the apartment complex server. -
Page 40: Administrator Mode Scenario
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Administrator 1. Administrator Mode Scenario - This mode is where you can configure basic settings for WALL-PAD operations. ※ You can enter this mode by going to Home ▶Settings ▶Administrator Settings (Management) ▶<Run Admin Settings>,... -
Page 41: Ip Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] How to Use GUI Administrator 3. IP Settings 1. The items that can be configured on the IP address settings are <IP Address, methods. Subnet Mask, Default Gateway, KHNS, and SIP Server IP>... -
Page 42: Settings
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Smart Phone APP Settings 1. Installation Method ① App Activation 1) Install the Home>app and run the app. <KOCOMSmart 2) Execute the intro and request for permissions if they have not been configured. - Page 43 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Smart Phone APP Settings 1. Installation Method ② Smartphone Registration 1) If your phone number is unregistered, go to this menu. 2) Enter your phone number and tap <OK>. 3) Register the new device at the menu.
-
Page 44: App Main Screen
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Smart Phone APP Settings 2. Main Screen Settings Edit Registered Device New Device Registration Edit Settings... -
Page 45: Incoming Call From Lobby/Guard Phone
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Other Matters 1. Incoming Call From Lobby/Guard Office Phone Incoming Lobby Call Signal to the Unit >> Unit Enter unit’s Call call room number Tap the unit number The visitor’ s appearance is (room number) the visitor displayed at the unit;... -
Page 46: How To Use Lobby Phone
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Other Matters 2. How to Use Lobby Phone How to Open/Close Lobby With Password >> (e.g : Unit No. 101) - Tap the <Open door with unit password>. - Enter the unit number and tap <Next>. -
Page 47: Before You Request Repairs
KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] Settings Other Matters 3. Before You Request Repairs Please check the following items before requesting a repair; please inquire the nearest KOCOMservice center after con- firming thatissues persist despite checking the items. - Page 48 KHN-T100M9 WALL-PAD Use & Installation Manual [For Administrator] www.kocom.com ■ This manual's version is based on the date on the right; this manual may be changed without prior notice for quality enhancement purposes. KHN-T100M9 X1207...
