Operating and Maintenance Instructions
Window shutters
Wing shutters | Sliding shutters | Folding sliding shutters | Folding scissor shutters
GENERAL INFORMATION
Window roller shutters provide solar shading and are not security equipment.
They can be used either open, closed or at an intermediate position for control-
ling incoming solar radiation.
The end user must read and observe these Operating and Maintenance Instruc-
tions before using the shutters for the first time.
OPERATION
Motorized operation
Shutters are operated using central or local wall-mounted or hand-held controls
with an Open / Close / Stop button. The operating functions of the controls are
described in the operating instructions for the controls.
Manual operation
The curtain is moved in the desired direction by hand. Impact buffers are in-
stalled as a rule at the beginning and end of the system. The curtain can be
locked in these impact buffers.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Griesser 4001
Summary of Contents for Griesser 4001
- Page 1 Operating and Maintenance Instructions Window shutters Wing shutters | Sliding shutters | Folding sliding shutters | Folding scissor shutters GENERAL INFORMATION Window roller shutters provide solar shading and are not security equipment. They can be used either open, closed or at an intermediate position for control- ling incoming solar radiation.
-
Page 2: Electrical Installations
Use only original Griesser replacement parts No assurance is provided that the product will function with accessories, parts or operating equipment made by other manufacturers. Modifications to the product that are not expressly approved by Griesser render warranty or product liability claims null and void. -
Page 3: Maintenance / Inspection
The window shutters meet the requirements of the wind classes indicated in the declaration of conformity and may re- main extended only up to the specified wind class. Window roller shutters provide solar shading and may not be used as security equipment. The system is not to be used unless it is in a technically flawless condition. - Page 4 PERFORMANCE DECLARATION WING SHUTTERS DoP- Nr. 4013 / 09.2013 1. Product Type: Griesser Wing shutters 2. Product Name: Wing shutter 4001 with fixed slats, simple construction Models: A, R, T, EZ 2.2 4002 with movable slats, simple construction Models: B, E 2.3 4003...
- Page 5 PERFORMANCE DECLARATION SLIDING BI-FOLD SHUTTERS DoP- Nr. 4013 / 09.2013 1. Product Type: Griesser Sliding bi-fold shutters with filling and / or lining 2. Product Name: Sliding bi-fold shutter with filling and / or lining 4005 Models: S, SL 2.2 4006...
- Page 6 DECLARATION OF CONFORMITY WINDOW SHUTTERS GRIESSER AST GmbH Gewerbestrasse 17 A – 6710 Nenzing Austria declares that the products listed below «window shutters» for exterior use Wing shutters Sliding shutters Wing shutter with window frame Sliding shutter Wing shutter with installation frame...
- Page 7 Sliding bi-fold shutters must be protected against overwinding. The values in the table apply with the following reservations: Product dimensions and use comply with the Griesser technical data sheet. Installation, fastening and operation are carried out in accordance with installation and operating instructions.
- Page 8 www.griessergroup.com...
