Honda HRX217HZU Owner's Manual

Honda HRX217HZU Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HRX217HZUA
HRX217HZUA
QUICK FIND
Add Fuel. . . . . . . . . . . . . . . . . . . . . . .
Air Filter . . . . . . . . . . . . . . . . . . . . . .
Blade Inspection. . . . . . . . . . . . . . . .
Charging the Battery . . . . . . . . . . . .
CONTENTS
FOR YOUR SAFETY . . . . . . . . . . . . .
PARTS AND CONTROLS . . . . . . . . .
INITIAL MOWER SETUP. . . . . . . . . .
List of Parts . . . . . . . . . . . . . . . . .
Adjust the Handlebar . . . . . . . . . .
Add Engine Oil . . . . . . . . . . . . . . .
Check Your Mower. . . . . . . . . . . .
Clip Director® . . . . . . . . . . . . . . .
Check the Oil Level . . . . . . . . . . .
Add Fuel. . . . . . . . . . . . . . . . . . . .
OPERATION . . . . . . . . . . . . . . . . . . .
Safe Mowing Practices . . . . . . . .
Operating the Controls. . . . . . . . .
Starting the Engine. . . . . . . . . . . .
Stopping the Engine. . . . . . . . . . .
Illustrations in this manual are for instructional purposes only and may not be exact representations. All information contained in this
manual is based on the latest product information available at the time of publication. Honda Australia Motorcycle and Power
Equipment Pty. Ltd. reserves the right to make changes at any time without notice. No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying, recording or otherwise,
without the prior written permission of Honda Australia Motorcycle and Power Equipment Pty. Ltd. This includes text, figures and
00X32VH7 W030
OWNER'S MANUAL
7
Check the Oil Level . . . . . . . . . . . . . . .
12
Cleaning . . . . . . . . . . . . . . . . . . . . . .
11
Dealer Locator Information . . . . . . . .
14
How to Contact Honda . . . . . . . . . . .
2
SERVICING YOUR MOWER . . . . . . .
3
Maintenance Safety . . . . . . . . . . .
3
Maintenance Schedule . . . . . . . .
3
Blade Inspection . . . . . . . . . . . . .
3
4
Blade Replacement . . . . . . . . . . .
4
Oil Change . . . . . . . . . . . . . . . . .
4
Air Filter . . . . . . . . . . . . . . . . . . . .
4
Spark Plug . . . . . . . . . . . . . . . . . .
4
5
Charging the Battery . . . . . . . . . .
6
6
Replacing the Battery . . . . . . . . .
7
TRANSPORTING . . . . . . . . . . . . . . .
7
STORAGE . . . . . . . . . . . . . . . . . . . . .
7
Fuel . . . . . . . . . . . . . . . . . . . . . . .
8
Oil . . . . . . . . . . . . . . . . . . . . . . . .
9
Cleaning . . . . . . . . . . . . . . . . . . .
9
Storage Location . . . . . . . . . . . . .
Handlebar . . . . . . . . . . . . . . . . . .
tables.
Honda Australia Motorcycle and Power Equipment Pty. Ltd.
ABN 96 006 662 862 (trading as Honda MPE).
© 2018 American Honda Motor Co., Inc.-All Rights Reserved
HRX217HZU
LAWN MOWER
Before operating the mower for the first time, please read this
Owner's Manual. Even if you have operated other mowers,
take time to become familiar with how this mower works and
practice in a safe area until you build up your skills.
6
Maintenance Schedule . . . . . . . . . . . . . . .
15
Oil Change. . . . . . . . . . . . . . . . . . . . . . . . .
20
Operating the Controls . . . . . . . . . . . . . . . .
20
Spark Plug . . . . . . . . . . . . . . . . . . . . . . . . .
9
TROUBLESHOOTING . . . . . . . . . . . . . . .
9
Engine Will Not Start . . . . . . . . . . . . . .
10
Loss of Power . . . . . . . . . . . . . . . . . . .
11
Vibration . . . . . . . . . . . . . . . . . . . . . . .
11
11
TECHNICAL INFORMATION . . . . . . . . . .
12
Serial Number Locations. . . . . . . . . . .
12
High Altitude Operation . . . . . . . . . . . .
13
Specifications . . . . . . . . . . . . . . . . . . .
13
14
CUSTOMER INFORMATION . . . . . . . . . .
14
14
Dealer Locator Information . . . . . . . . .
14
How to Contact Honda . . . . . . . . . . . .
15
Honda Publications . . . . . . . . . . . . . . .
15
Service Record . . . . . . . . . . . . . . . . . . . . .
15
LIMITED WARRANTY. . . . . . . . . . . . . . . .
15
15
15
10
12
8
13
16
16
16
16
16
17
17
17
18
19
20
20
20
20
20
21
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRX217HZU and is the answer not in the manual?

Questions and answers

Related Manuals for Honda HRX217HZU

Summary of Contents for Honda HRX217HZU

  • Page 1: Table Of Contents

    Illustrations in this manual are for instructional purposes only and may not be exact representations. All information contained in this manual is based on the latest product information available at the time of publication. Honda Australia Motorcycle and Power Equipment Pty. Ltd. reserves the right to make changes at any time without notice. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Honda Australia Motorcycle and Power Equipment Pty.

  • Page 2: For Your Safety

    Important Message to Parents WELCOME The safety of children and adolescents is important to Honda. Lawn mowers are powerful tools, not toys. As with any equipment, bad judgements can result in serious injuries. Please ensure before any Congratulations on your selection of a Honda lawn mower! We are...

  • Page 3: Parts And Controls

    THROTTLE LEVER (P. 8) following list. Contact the authorised Honda dealer from whom you REAR purchased the mower if any of the loose parts shown are not included DISCHARGE with your mower.

  • Page 4: Add Engine Oil

    Read and understand this manual. Know what the controls do and oil filler opening. how to operate them. All Honda engines are run at the Familiarize yourself with the lawn mower and its operation before you factory prior to packaging. Most begin using it.

  • Page 5: Clip Director

    KNOB Remove the grass bag and raise the discharge guard to check the rear shield for cracks or tears. If the rear shield is excessively worn, have it replaced by your authorised Honda servicing dealer. DISCHARGE GUARD SLIDING DOOR (50% open)

  • Page 6: Cutting Height Adjustment

    Grass Bag To adjust cutting height, pull ADJUSTMENT LEVERS each adjustment lever toward A lawn mower works like a vacuum cleaner; it blows air through the the wheel, and move it into bag fabric, which traps the grass clippings. Always empty the grass another notch.

  • Page 7: Add Fuel

    Add Fuel OPERATION This engine is certified to operate on regular petrol with a pump octane rating of 86 or higher. For your safety, avoid starting or operating the engine in an enclosed Never use stale or contaminated petrol or an oil/petrol mixture. Avoid area, such as a garage.

  • Page 8: Operating The Controls

    Refuel With Care Operating the Controls Petrol is extremely flammable and petrol vapor can explode. Refuel Throttle Lever only outdoors, in a well-ventilated area, with the engine OFF. Never For best cut quality, always smoke near petrol, and keep other flames and sparks away. Always mow with the throttle lever in store petrol in an approved container.

  • Page 9: Starting The Engine

    Remember that an authorised Honda servicing dealer knows your mower best and is fully equipped to maintain and repair it. To ensure The starter should not be the best quality and reliability, use only new, Honda Genuine parts or cranked for more than 5 SWITCH seconds at a time.

  • Page 10: Maintenance Schedule

    (2) Change engine oil every 25 hours when used under heavy load or in high outside air temperatures. (3) These items should be serviced by an authorised Honda servicing dealer unless you have the proper tools and are mechanically proficient.

  • Page 11: Blade Inspection

    4. Tighten the blade bolts with a torque wrench to the specified torque. Use a wooden block to prevent the blades from turning If a blade is bent, take the lawn mower to an authorised Honda when tightening the bolts, as shown on page 12.

  • Page 12: Air Filter

    LIMITED WARRANTY (page 23). 2. Wipe the oil filler area clean, and then remove the oil filler We recommend the use of a Honda Genuine air filter to ensure it cap/dipstick. seals and performs as designed. Using a non-Honda air filter can 3.

  • Page 13: Spark Plug

    4. If the blades do not start or stop as they should with the correct 2. Remove the spark plug cable adjustment, take the mower to an authorised Honda with a 21 mm spark plug servicing dealer for repair.

  • Page 14: Charging The Battery

    3. Remove and inspect the fuses. If they are burned out, replace with 3. Insert the connector on the Honda battery charger into the other a serviceable fuse. end of the adapter harness.

  • Page 15: Storage

    Drying STORAGE After washing the lawn mower, wipe dry all accessible surfaces. Place the mower with its wheels on a level surface. Start the engine Proper storage preparation is essential for keeping your lawn mower outdoors and let it run until it reaches normal operating temperature to trouble free and looking good.

  • Page 16: Troubleshooting

    Blades bent, damaged, or Take the mower to an Starter turns slowly or not at all • Use the recoil starter for at unbalanced by improper authorised Honda servicing least one mowing session to sharpening dealer for repair. allow the battery to charge •...

  • Page 17: Technical Information

    TECHNICAL INFORMATION High Altitude Operation At high altitudes, the standard carburetor air-fuel mixture will be too Serial Number Locations rich. Performance will decrease, and fuel consumption will increase. A very rich mixture will also foul the spark plug and cause hard starting. Operation at an altitude that differs from that at which this engine was certified, for extended periods of time, may increase emissions.

  • Page 18: Specifications

    Unleaded petrol with a pump page 7 octane rating of 86 or higher containing HRX217K6HZU Honda rotary mower, 530 mm mower deck, no more than 10% ethanol by volume self-charging electric start, Clip Director, Capacity: 0.91 litres hydrostatic transmission, blade brake clutch, See “AVOIDING FUEL-RELATED...

  • Page 19: Avoiding Fuel-Related Problems

    AVOIDING FUEL-RELATED PROBLEMS When properly maintained, your Honda lawn mower should provide years of trouble-free operation. This includes the fuel system. However, petrol can quickly deteriorate (in as little as 30 days) causing starting or running problems and, in some cases, damage to the fuel system. Most fuel-related problems can be avoided by following the precautions listed below.

  • Page 20: Customer Information

    The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Inc. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatever.
  • Page 21 Service Record Here is an easy way to keep track of the hours your Honda lawn mower has done. Record how many hours you get from a tank of fuel, and then simply page 10 record the number of tanks used. TANK x HOURS per TANK = TOTAL HOURS USE. (Refer to the Maintenance Schedule on...

  • Page 22: Service Record

    Service Record Here is an easy way to keep track of the hours your Honda lawn mower has done. Record how many hours you get from a tank of fuel, and then simply record the number of tanks used. TANK x HOURS per TANK = TOTAL HOURS USE. (Refer to the Maintenance Schedule on...

  • Page 23: Limited Warranty

    Honda will repair or replace, at its option, any part that is proven to be defective in material or workmanship under normal use during the applicable warranty time period.
  • Page 24 www.hondampe.com.au HPE.2018.09 Printed in U.S.A.
