DKP39905BK

EN User Manual

Oven

Table of Contents

Need help?

Do you have a question about the DKP39905BK and is the answer not in the manual?

Questions and answers

Summary of Contents for Dieter Knoll DKP39905BK

Page 1 DKP39905BK EN User Manual Oven...
Page 2: Table Of Contents
CONTENTS 1. SAFETY INFORMATION...................2 2. SAFETY INSTRUCTIONS.................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................9 5. CONTROL PANEL.................... 9 6. BEFORE FIRST USE..................11 7. DAILY USE...................... 12 8. CLOCK FUNCTIONS..................13 9. AUTOMATIC PROGRAMMES................ 15 10. USING THE ACCESSORIES................ 16 11.
Page 3 Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be •...
Page 4: Safety Instructions
Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal scrapers • to clean the glass door since they can scratch the surface, which may result in shattering of the glass. Before pyrolytic cleaning, remove all accessories and •...
Page 5 2.3 Use must be carried out by our Authorised Service Centre. • Do not let mains cables touch or come WARNING! near the appliance door or the niche below Risk of injury, burns and electric shock or the appliance, especially when it operates explosion.
Page 6 • Always cook with the appliance door • Keep children away from the appliance closed. while the pyrolytic cleaning operates. The • If the appliance is installed behind a appliance becomes very hot and hot air is furniture panel (e.g. a door) make sure the released from the front cooling vents.
Page 7: Installation
2.7 Service • Contact your municipal authority for information on how to dispose of the • To repair the appliance contact the appliance. Authorised Service Centre. • Disconnect the appliance from the mains • Use original spare parts only. supply. •...
Page 8 (*mm) min. 550 min. 560 3.2 Securing the oven to the cabinet ENGLISH...
Page 9: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Control panel Electronic programmer Heating element Lamp Cavity embossment - Aqua cleaning container Shelf support, removable Shelf positions 4.2 Accessories • Telescopic runners With the telescopic runners you can put in • Wire shelf and remove the shelves more easily.
Page 10 Sensor Function Description Field Oven Light To turn the oven lamp on and off. Temperature / Fast To set or check the temperature. Heat Up Press and hold it for three seconds to turn on and off the function: Fast Heat Up. My Favourite Pro‐...
Page 11: Before First Use
Symbol Name Description h / min A clock function works. Heat-up / residual heat indica‐ Shows the temperature level of the oven. Temperature / fast heat up The function works. Temperature You can examine or change the temperature. Door lock The door lock function works.
Page 12: Daily Use
The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated. 7. DAILY USE WARNING! Oven func‐ Application tion Refer to Safety chapters. This function is designed to 7.1 Heating Functions save energy during cooking. When you use this function, Oven func‐...
Page 13: Clock Functions
7.5 How to check: Temperature The oven door should be closed during cooking so that the function is not interrupted You can check the current temperature in the and the oven operates with the highest oven when the function or programme works. energy efficiency possible.
Page 14 Clock function Application Minute Minder To set a countdown time. This function has no effect on the opera‐ tion of the oven. You can set the Minute Minder at any time and also when the oven is off. 00:00 Count Up Timer To set the count up, which shows how long the oven works.
Page 15: Automatic Programmes
4. Press or the Minute Minder starts When the Time Delay function is automatically after 5 seconds. turned on, the display shows a symbol of When the set time ends, the signal sounds for the heating function, with a dot and 2 minutes and the display shows flashing .
Page 16: Using The Accessories
6. When the set time ends, an acoustic The display shows: the cooking time, the signal sounds for two minutes. duration symbol , a default weight, a unit flashes. of measurement (kg, g). 7. Touch a sensor field or open the oven door to stop the acoustic signal.
Page 17: Additional Functions
11. ADDITIONAL FUNCTIONS 11.1 Using My Favourite Programme The signal sounds. function The display shows SAFE. The door is locked. Use this function to save your favourite To turn off the Child Lock function repeat step temperature and time settings for an oven function or programme.
Page 18: Hints And Tips
Description Value to set SERVICE MENU RESTORE SETTINGS YES / NO It is not possible to deactivate the tone of the ON / OFF sensor field. • Night brightness - when the appliance is 1. Press and hold for 3 seconds. deactivated, the brightness of the display The display shows SET1 and "1"...
Page 19 Baking cakes To prevent too much smoke in the oven during roasting, add some water into the Do not open the oven door before 3/4 of the deep pan. To prevent the smoke set cooking time is up. condensation, add water each time after it If you use two baking trays at the same time, dries up.
Page 20 (°C) (min) Soufflè, 6 pieces ceramic ramekins on wire 25 - 30 shelf Sponge flan base flan base tin on wire shelf 15 - 25 Victoria sandwich baking dish on wire shelf 40 - 50 Poached fish, 0.3 baking tray or dripping pan 20 - 25 Whole fish, 0.2 kg baking tray or dripping pan...
Page 21 ( °C) (min) Small Conven‐ Baking 20 - 35 cakes, tional Cook‐ tray 20 per tray Small True Fan Baking 150 - 20 - 35 cakes, Cooking tray 20 per tray Small True Fan Baking 2 and 4 150 - 20 - 35 cakes, Cooking...
Page 22: Care And Cleaning
( °C) (min) Short True Fan Baking 2 and 4 140 - 25 - 45 bread Cooking tray Short Conven‐ Baking 140 - 25 - 45 bread tional Cook‐ tray Toast, 4 Grill Wire shelf max. 1 - 5 Preheat the oven for 10 min.
Page 23 Clean all accessories after each use and let them dry. Use only a microfibre cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects. Accesso‐...
Page 24 Option Cleaning mode Duration Light cleaning Normal cleaning 1 h 30 min Thorough cleaning 2 h 30 min When the cleaning starts, the oven door is locked and the lamp is off. To stop the cleaning before it is completed, turn off the oven. The oven stays locked until it is cold.
Page 25 Step 1 Open the door fully and hold both hinges. Step 2 Lift and pull the latches until they click. Step 3 Close the oven door halfway to the first opening position. Then lift and pull to re‐ move the door from its seat. Step 4 Put the door on a soft cloth on a stable surface.
Page 26 Step 9 After cleaning, install the glass panels and the oven door. If the door is installed correctly, you will hear a click when closing the latches. Make sure that you put the glass panels (A and B) back in the correct sequence. Check for the sym‐ bol / printing on the side of the glass panel, each of the glass panels looks different to make the disas‐...
Page 27: Troubleshooting
14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 What to do if... Problem Possible cause Remedy You cannot activate or operate The oven is not connected to an Check if the oven is correctly the oven. electrical supply or it is connected connected to the electrical supply incorrectly.
Page 28: Energy Efficiency
......... Serial number (S.N.) ......... 15. ENERGY EFFICIENCY 15.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Dieter Knoll Collection Model identification DKP39905BK 949498285 Energy Efficiency Index 81.2 Energy efficiency class ENGLISH...
Page 29 Energy consumption with a standard load, conventional mode 0.93 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle Number of cavities Heat source Electricity Volume 72 l Type of oven Built-In Oven Mass 30.7 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.
Page 30: Environmental Concerns
16. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
Page 32 867377356-A-312023...
