Accuride 9301-E Installation Manual

9301-E/9308-E4
Installation Guide
Einbauanleitung
Guide d'installation
Guida all'installazione
Guía de instalación
Instrukcja montażu
9301-E
SL TR
DZ9301-0010U-E 254.0 254. 0
DZ9301-0012U-E 304.8 304.8
DZ9301-0014U-E 355.6 355.6
406.4 406.4
DZ9301-0016U-E
DZ9301-0018U-E 457.2 457.2
DZ9301-0020U-E 508.0 508.0
558.8 558.8
DZ9301-0022U-E
DZ9301-0024U-E 609.6 609.6
DZ9301-0026U-E 660.4 660.4
DZ9301-0028U-E 711.2 711.2
762.0 762.0
DZ9301-0030U-E
DZ9301-0032U-E 812.8 812.8
DZ9301-0034U-E 863.6 863.6
914.4 914.4
DZ9301-0036U-E
1016.0 1016.0
DZ9301-0040U-E
DZ9301-0042U-E 1066.8 1066.8
DZ9301-0044U-E 1117.6 1117.6
1219.2 1219.2
DZ9301-0048U-E
DZ9301-0054U-E 1371.6 1371.6
DZ9301-0060U-E 1524.0 1524.0
INS-9301-E/9308-E4-000 Revision M 05/20
A B C D
- - - -
- - - -
- - - -
127.0 - -
-
127.0 - - -
127.0 190.5 - -
127.0 190.5 - -
127.0 190.5 - -
127.0 190.5 - -
127.0 190.5 - -
127.0 190.5 368.3
-
127.0 190.5 368.3 -
127.0 190.5 368.3 469.9
127.0 190.5 368.3 520.7
127.0 190.5 368.3
520.7
127.0 190.5 368.3 520.7
127.0 190.5 368.3 520.7
127.0 190.5 368.3
520.7
127.0 190.5 368.3 520.7
127.0 190.5 368.3 520.7
272/68 kg
9301-E
mm mm
E F G H
- 103.1 128.5 147.6
- 153.9 179.3 198.4
- 204.7 230.1 249.2
- 255.5 280.9 299.9
246.1 306.3 331.7 350.8
296.9 357.1 382.5 401.6
347.7 407.9 433.3 452.4
398.5 458.7 484.1 503.2
449.3 509.5 534.9 553.9
500.1 560.3 585.7 604.8
550.9 611.1 636.5 655.6
601.7 661.9 687.3 706.4
652.5 712.7 738.1 757.2
703.3 763.5 788.9 807.9
804.9 865.1 890.5 909.6
855.7 915.9 941.3 960.4
906.5 966.7 992.1 1011.2
1008.1 1068.3 1093.7 1112.8
1160.5 1220.8 1246.2 1265.2
1312.9 1373.1 1398.5 1417.6
J K M N
166.6 - - -
217.4 - - -
268.2 - - -
319.0 - - -
369.8 - - -
420.6 - - -
471.4 - - -
522.2 - - -
573.0 - - -
623.8 - - -
674.6 234.9 - 501.6
725.4 234.9 393.7 552.5
776.2 234.9 419.1 603.3
827.0 234.9 444.5 654.1
928.6 235.0 546.1 755.7
979.4 235.0 546.1 806.5
1030.2 235.0 546.1 857.3
1131.8 234.9 596.9 958.9
1284.2 235.0 596.6 958.9
1436.6 234.9 596.9 958.9
P Q R
152.4 209.6 228.6
203.2 260.4 279.4
254.0 311.2 330.2
304.8 361.9 381.0
355.6 412.8 431.8
406.4 463.6 482.6
457.2 514.4 533.4
508.0 565.2 584.2
558.8 615.9 635.0
609.6 666.8 685.8
660.4 717.6 736.6
711.2 768.4 787.4
762.0 819.2 838.2
812.8 870.0 889.0
914.4 971.6 990.6
965.2 1022.4 1041.4
1016.0 1073.2 1092.2
1117.6 1174.8 1193.8
1270.0 1327.2 1346.2
1422.4 1479.6 1498.6
1
