Summary of Contents for Teradek AMIMON Falco SL11
- Page 1 SL11 U ANUAL...
- Page 2 Amimon. Amimon is part of the Creative Solutions Division, which is part of Videndum PLC. Amimon's products are sold under the TERADEK professional video product line. Contact us International 26 Zarhin St., Raanana, 4366250, Israel...
-
Page 3: Table Of Contents
Table of Contents 1. Before You Start 1.1 Glossary of Symbols ............5 1.2 S/N Label ................6 1.3 Warning ................7 2. Introduction 2.1 System Description ............8 3. Safety 3.1 Introduction ..............10 3.2 Operator ................11 3.3 Regulatory Warnings and Information ......12 3.4 Electrical and Mechanical Safety, and Fire Hazards .. - Page 4 6. Maintenance 6.1 Maintenance ..............26 6.2 Waste Electrical and Electronic Equipment (WEEE) ..26 7. Troubleshooting 7.1 Troubleshooting ............... 27 8. Technical Specifications 8.1 Technical Specifications ..........29...
-
Page 5: Glossary Of Symbols
1.1 Glossary of Symbols The following are symbols that you will find throughout this operating manual and their meanings SL11 User Manual Page 5... -
Page 6: S/N Label
1.2 S/N Label SL11 Camera unit label on the device SL11 User Manual Page 6... -
Page 7: Warning
SL11 Camera unit label on individual device package 1.3 Warning The SL11 system is designed for professional use only. The manufacturer cannot be held responsible for damage or injury caused by improper use or for uses other than those for which this machine is intended. Read the User Manual instructions carefully before using the system to become familiar with all safety requirements and operating procedures thereby preventing accidents and injury while reducing the risk of damaging the machine. -
Page 8: System Description
2.1 System Description Models Camera unit: SL11TX01 Receiver: MD11RX01 Sterilizable cover: AMN_ASM_1030 Description Falco SL11 is a wireless camera designed for medical applications, providing ultra-low latency video up to 4K30 FPS. It can capture detailed procedures and deliver sharp, clear images from surgical lights, treatment room lights, suspended arms, and various setups. - Page 9 Limitations of Use The SL11 is a non-sterile, reusable device and is not intended for use within a sterile field without the sterilizable cover. The sterilizable cover shall be sterilized before each procedure, according to the requirements specified in the sterilizable cover user manual. System Dimensions Camera Unit SL11 User Manual...
-
Page 10: Introduction
Sterilizable Cover 3.1 Introduction This chapter describes safety issues regarding the use and maintenance of the System, with special emphasis on electrical safety. Please carefully read this chapter and be familiar with all of its safety requirements and operating procedures before operating the System. -
Page 11: Operator
WARNING: Use of accessories, transducers, and cables other than those specified or provided by the manufacturer of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper operation. WARNING: The video transmitter system, model SL11 needs special ... -
Page 12: Regulatory Warnings And Information
3.3 Regulatory Warnings and Information Modifications Any changes or modifications could void the user’s authority to operate the equipment and invalidate the regulatory approval. Antenna Requirements The product is provided with approved antennas. Use only antennas supplied by Amimon. Any changes or modifications to the antenna may void the regulatory approvals obtained for the product. - Page 13 Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
- Page 14 minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IC RADIATION EXPOSURE STATEMENT Important Note: Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for uncontrolled environments.
- Page 15 • In the 5.925-6.425 GHz band, devices containing AMN42012 (which is a client device) must operate under the control of a device containing the AMNPTTX01 which is an indoor access point. In all cases, an exception exists for transmitting brief messages to an access point when attempting to join its network after detecting a signal that confirms that an access point is operating on a particular channel.
- Page 16 Caution: 1. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems. 2. Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
-
Page 17: Electrical And Mechanical Safety, And Fire Hazards
Directives 2014/53/EC, 2011/65/ EU and (EU) 2015/863. The full text of the EU DoC is located at: https://www.medical.teradek.com/falco-sl11. 3.4 Electrical and Mechanical Safety, and Fire Hazards Damage due to inappropriate handling is not covered by the warranty. -
Page 18: Installation
Electrical Requirements The SL11 is powered by the Theater light. • Power input - 12V – 24V DC • Typical Power Consumption - 10W Environmental Requirements • Corrosive materials can damage electronic parts. Ensure that the environment is free from corrosive material. - Page 19 • The MD11 Receiver is not intended for use near patients, or medical staff (minimum distance 20cm between the radiator and your body). • Do not install near sources of intense heat, such as boilers or radiators. • Install this system in an environment that complies with all applicable IEC, CEC, and NEC requirements for safety of electrical devices.
- Page 20 D = Distance • The distance between neighboring Falco transmitters shall be no less than 1m • The distance between any transmitter and any receiver (not part of the link) shall be no less than 2m. SL11 User Manual Page 20...
- Page 21 • The distance between receivers (linked to different transmitters) shall be no less than 80 cm. • The maximum number of Falco devices to be operated in a single room is six transmitters and six receivers. • The room may also contain other RF-emitting devices, such as 2.4GHz or 5GHz Wi-Fi and 2.4GHz Bluetooth.
-
Page 22: View Of The System
4.2 View of the System SL11 Camera Unit A: Pairing button E: Host connector B: Network LED (Blue) F: Sterilizable cover release button C: Video LED (Green) G: Sterilizable cover D: Reset button SL11 User Manual Page 22... -
Page 23: Power And Connectivity
MD11 Receiver A. HDMI output D. 12V DC power input G. On/Off switch B. USB-C port E. OLED display C. RS-232 F. Navigation button 5.1 Power and Connectivity 1. Connect power to the receiver using the included AC adapter. 2. Connect the receiver's HDMI output (A) to the video input on your monitor. 3. -
Page 24: Pairing
4. To turn off the device, slide the power switch (G) to the OFF position and ensure the blue light turns off. 5. USB-C (B) available for future software updates. 5.2 Pairing To associate the SL11 transmitter with the MD11 receiver, the devices need to be paired using the dedicated buttons. - Page 25 SL11 LEDs The SL11 LEDs indicate the status of the Network (Blue) and Video (Green) states. Each LED can be Off, On (solid light), or in a blink state. There are three blink speeds used to differentiate between states – Fast, Medium, and Slow.
-
Page 26: Maintenance
Camera Control The control on the SL11 Camera Unit is controlled by VISCA protocol, over RS232. 6.1 Maintenance No maintenance is required. Cleaning and Maintenance Warning: • Unplug the SL11 from the power source before cleaning, to avoid electric shock and potentially fatal injury. -
Page 27: Troubleshooting
7.1 Troubleshooting The MD11 Receiver unit does not power on. a. Verify the power adaptor is connected and the power switch is in ‘On’ position. b. Power cycle the unit, by switching the power button to ‘Off’ and then back to ‘On’ position. - Page 28 d. Verify that there is no other wireless unit located near the SL11 Receiver unit. e. Verify that the sterilizable cover is clean and unscratched. The Video LED indicator of the SL11 Camera unit is blinking. There is a problem with the camera. Power cycle the SL11 Camera unit by pressing the Reset button, or by disconnecting and connecting the host connector.
-
Page 29: Technical Specifications
8.1 Technical Specifications FALCO SL11 CAMERA UNIT FALCO MD11 RECEIVER VIDEO Video Outputs 1x HDMI 1.4 Type-A output Color Sampling 10-bit/HDMI: RGB 4:4:4 8-bit Delay (TX to <0.001sec <0.001sec 4Kp23.98/29.97 4Kp23.98/24/25/29.97/30 1080p23.98/25/29.97/30/50/ 1080p23.98/24/25/29.97/30/50/ Supported 59.94 59.94/60 Resolutions 1080i50/59.94/60 720p50/59.94/60 Camera: Sony FCB-ER8530 Video Camera Zoom: 20x Optical, 12x Digital Camera Control: VISCA... - Page 30 A proprietary connector for Host Connector power and VISCA control for the camera. OLED Status and Configuration Display Wireless, Video BLE and NFC Control and configuration Switches On/Off Switch USB Interface Update via USB-C Device Control VISCA using host connector RS-232 (for future use) WIRELESS VIDEO NETWORK DFS Frequencies:...
- Page 31 AES-256, RSA-1024 key Encryption AES-256, RSA-1024 key exchange exchange Range Up to 100 ft (30m) Up to 100 ft (30m) Transmitter can stream Receiver can switch between 4 Multicast simultaneously to up to 4 transmitters receivers Can coexist with WiFi and other devices working on the 5GHz Can coexist with WiFi and other Noise Rejection...
- Page 32 CFR 21 Parts 801, 807, 820, 880 UK MDR 2002 IEC 60601-1:2005 + A1:2012 + A2:2020, EN 60601-1:2006 + A1:2013 + A2:2021, ANSI/AAMI ES60601-1:2005+ A1:2012 + A2:2021, CAN/CSA- C22.2 No. 60601-1:14 + A2:2022 IEC 60601-1-6:2010+A1:2013+A2:2020 for use in conjunction with IEC Medical 62366-1:2015+A1:2020 and IEC 60601-1:2005+A1: 2012+A2: 2020 Electrical...
- Page 33 that HF surgical interference is observed, adjust the separation distance of the equipment. Guidance and Manufacturer's Declaration - ELECTROMAGNETIC IMMUNITY The SL11 Wireless Camera and MD11 Receiver are intended for use in the electromagnetic environment specified below. The customer or the user of the SL11 Wireless Camera and MD11 Receiver should ensure that they are used in such an environment.
- Page 34 SL11 User Manual Page 34...
- Page 35 SL11 User Manual Page 35...
- Page 36 SL11 User Manual Page 36...
