Simplecom CHU810 User Manual

CHU810 10-Port USB 3.0 Hub
with 48W Charger
CHU810
Overview
ON/OFF Indicator
ON/OFF Switch
About Product
This 10-Port USB 3.0 data hub and charger allows you to expand your
computer's USB connectivity and charge your mobile devices
simultaneously. Quickly expand an available USB 3.0 port into 10 USB
3.0 ports by plugging this hub into the computer's unused USB port,
you can instantly add up to 10 USB devices easily.
Total 48W power lets you plug more power consuming USB devices, and
charge your phones, tablets or other devices at the same time. Four BC
1.2 fast charging ports that auto optimize current up to 1.5A per port.
It features USB 3.0 SuperSpeed transfer rate and backwards compatible
with USB 2.0 and 1.1. Plus, each port has its own separate power switch
so you can control each port independently without unplugging the
equipment.
Speci cations
• Part Number: CHU810
• EAN: 9350414002918
• Model Number: TDX48-1204000A
• Casing Material: Aluminium
• Input: USB 3.2 Gen 1 Type A (USB 3.0)
• Outputs: USB 3.2 Gen 1 Type A (USB 3.0) x10
• Data Rate: SuperSpeed 5Gbps, backward compatible
• Power Input: 100-240V, 50/60hz
• Total Power Output: 48W (12V4A)
• USB Power Output: up to 0.9A each port (6x Blue USB Port), up to
• 1.5A each port (4x Red USB Ports)
• Fast Charging Protocol: BC 1.2 on 4x Red USB Ports
FAQ
What's the di erence between Blue USB Ports and Red USB Ports?
Both colour USB ports have same data transferring speed up to
5Gbps, however Red USB ports with BC 1.2 support that can supply up
DC IN (12V/4A)
to 1.5A power.
• Blue USB ports are standard USB 3.0 that is capable of delivering up
• to 0.9 of current
Red
• USB ports are USB 3.0 with BC 1.2 that is capable of delivering
• up to 1.5 of current
What is BC 1.2?
BC 1.2 is an abbreviation for Battery Charging revision 1.2. BC 1.2 is an
extension of USB 3.0 to make it capable to charge mobile devices with
more than the standard 0.9A. At BC 1.2 the current is output 1.5A
SuperSpeed USB 5Gbps
instead of the standard 0.9A of USB 3.0 when connected to a PC.
Charging up to 0.9A
Does this hub work on previous versions of USB host port?
Yes, this hub is backwards compatible. Also, USB 3.2 Gen 1 is the
standard previously known as USB 3.0 or USB 3.1 Gen 1.
Can I use it as stand-alone USB charger without connecting to PC?
Yes, you can use it with a computer or as a stand-alone USB charger. It
will enable data transfer function while connected to a PC.
Can I plug it to computer without power adapter connected?
Yes, but the USB host port on PC only can supply up to 900mA power
SuperSpeed USB 5Gbps
to the hub, you can only use lower power or external powered USB
BC 1.2 Charging up to 1.5A
devices, such as keyboard, mouse, pen drive, USB card reader, printer.
Can I use this hub for data transfer and charging at the same time?
Yes, this hub is designed for both data transfer and charging, you can
access data from connected USB devices, while charging your mobile
device at the same time.
Features
• 10-Port USB 3.0 Hub for PC and Laptop with 48W power adapter
• USB 3.2 Gen 1(USB 3.0) SuperSpeed Data Transfer Rate up to 5Gbps
• 48W power lets you charge phones, tablets or other devices simultaneously
• Four BC 1.2 fast charging ports that optimize current up to 1.5A per port
• Equipped with 10 individual on/o switches to control each USB port
• Aluminium shell for sleek looking and optimal heat dissipation
• Individual blue LEDs to display the power status of each USB port
• Plug and play, no additional driver required
• Backward Compatible with USB 2.0 and 1.1
• Support more high power consuming devices at the same time
• Short-circuit, over-current, over-voltage, and over-heating protection
• Supports Windows XP and above (32/64-bit), MacOS 10.2 and above
Safty Information
• Read the operating manual prior to use
• Keep the device away from humidity, liquid, vapour and dust
• Disconnect all immediately if device get wet by the rain or water
• Keep small parts and accessories away from children
• Keep away from external heating up components
• Do not attempt to modify the device
• Make sure there is no residual moisture after cleaning
Package Contents
• 1x CHU810 10 Port USB 3.0 Hub
• 1x 12V4A Power Adapter
Warranty
1 Year limited Warranty. Our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not
amount to a major failure.
For our assistance with regards to warranty please email to
support@simplecom.com.au or create a support ticket at
http://www.simplecom.com.au
© Simplecom Australia All Rights Reserved. Simplecom is a registered
trademark of Simplecom Australia Pty Ltd. All other trademarks are
property of their respective owner. Speci cations and external
appearance are subject to change without notice. Warranty and
technical support covering this product are only valid in the country or
region of purchase.
