- Page 1 Baicells EG7035E-M11 User Manual V100R001C00 All rights reserved © Baicells Technologies Co., Ltd.
- Page 2 About This Document This document introduces the specifications of Baicells EG7035E-M11 CPE and guides users to install and configure it. Copyright Notice Baicells copyrights this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of Baicells.
-
Page 3: Table Of Contents
Contents Product Overview ....................... 1 Introduction ......................1 Features ........................ 1 Appearance ......................1 Technical Specifications ....................5 Basic Specification ....................5 RF Specification ..................... 5 SW Specification ....................5 Device Management ....................6 Environment Specification ..................6 Installation Guide......................8 Support Materials .................... - Page 4 Appendix B Shipping List ..................... 19...
- Page 5 Figure 4-5 Lock Frequency ..................16 Figure 4-6 Lock Frequency ..................17 Tables Table 1-1 Description of EG7035E-M11 Interface and Button ........2 Table 1-2 LED Indicator Description ................3 Table 2-1 Basic Specification ..................5 Table 2-2 RF Specification ................... 5 Table 2-3 SW Specification ..................
-
Page 6: Product Overview
WBB services. Features The EG7035E-M11 is designed according to the simplicity principle, which can evolve in a short period and realize fast customization, delivery and deployment as well. The main features of the EG7035E-M11 is as follows: Support TD-LTE network according to the operator’s choice. -
Page 7: Figure 1-1 Eg7035E-M11 Appearance
Figure 1-1 EG7035E-M11 Appearance The EG7035E-M11 interfaces and buttons are shown in Figure 1-2. Figure 1-2 Interface and Button of EG7035E-M11 The EG7035E-M11 interface and button description is given in Table 1-1. Table 1-1 Description of EG7035E-M11 Interface and Button Interface & Button... -
Page 8: Figure 1-3 Led Indicators Of Eg7035E-M11
LTE signal strength Indicator& status indicator Connected to Earth by conductor The LED indicators are shown in Figure 1-3. Figure 1-3 LED Indicators of EG7035E-M11 The description of LED indicators are given in Table 1-2. Table 1-2 LED Indicator Description... - Page 9 Identity Description Color Status Description LTE Signal 5 LTEs, Indicate Green All OFF Signal is too weak to attach. connection state Steady On According to signal strength in and signal turn light up strength Blanking Scanning the LTE network The CPE is authenticating.
-
Page 10: Technical Specifications
2. Technical Specifications Basic Specification Table 2-1 Basic Specification Item Description LTE Standard 3GPP Release 9 Ethernet LAN Port One RJ-45 port 10/100 auto-sensing, auto-MDX, LED Indicators Power/LET Signal/LAN Indicator USIM Support 1.8V/3V 2FF Restore Button Tact Button Long press over 10s to restore the factory settings Power Supply Input: Universal range 100V~240V AC Dimension... -
Page 11: Device Management
Item Description PIN Management SIM Lock Network Connection setup Create, delete, and edit APNs Set up dial-up connection automatically Set up dial-up connection manual LTE Scan Mode Full Band Cell Lock Band / Frequency Preferred ... -
Page 12: Table 2-5 Environment Specification
Table 2-5 Environment Specification Item Description Operating Temperature -40℃ ~ 55℃ Storage Temperature -40℃ ~ 70℃ Operating Humidity 5% ~ 95%... -
Page 13: Installation Guide
3. Installation Guide Support Materials Before installation, prepare the following support materials accordingly, as given in Table 3-1. Table 3-1 Support Materials for Installing Item Description Ethernet cable Outdoor Shield CAT5E Shorter than 330 feet Ground wire 16mm² yellow-green wire Install USIM Card and Ethernet Cable Screw the two screws on the waterproof cover. -
Page 14: Install On Pole
Figure 3-2 Connection Diagram Power on, the LED indicator will light up. Install on Pole Tighten the screws at the bottom of the bracket，as shown in Figure 3-3. Figure 3-3 Install the Bracket Install the bracket on pole as shown as Figure 3-4. -
Page 15: Install On Wall
Figure 3-4 Install on Pole Install on Wall Install bracket on wall as show as Figure 3-5. Figure 3-5 Install on Wall Grounding The EG7035E-M11 must be grounding, please contact professional person to operation. -
Page 16: Regulatory Compliance
Using grounding cable, connect the grounding screw to the ground row, as shown in Figure 3-6. Figure 3-6 Grounding Regulatory Compliance FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 17 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Warning: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
-
Page 18: Configuration Guide
4. Configuration Guide Log in The EG7035E-M11 manages, configures, and maintains the device by web management page. The steps to log in are as follows: In the address column of browser, type in http://192.168.150.1, then press “Enter”, login in page is shown in Figure 4-1. -
Page 19: Basic Configuration
Figure 4-2 View Status Basic Configuration 4.3.1 LTE Setting To set the LTE Network, perform the following steps: 1. Choose LTE. 2. In the LTE Setting area, configure the LTE network. 4.3.2 Set Connection Method To set the LTE network connection method, perform the following steps: 1. -
Page 20: Set Scan Mode
2. In the connection Method area, set the connection method 3. There are two methods to connect the LTE network, it is needed to choose a method between Auto and Manual, if you want to auto connect to the LET network you should choose the Auto, otherwise you should choose Manual. -
Page 21: Lock Pci
Figure 4-5 Lock Frequency Click “SAVE & APPLY”. 4.3.5 Lock PCI To lock the PCI, perform the following steps: Choose “LTE>Scan Method”. In the LTE Scan Method area, click PCI Lock to lock the PCI. Click ADD LIST you can choose a band, frequency and PCI, then click Add to add the frequency and PCI to the list, as shown in Figure 4-6. -
Page 22: Figure 4-6 Lock Frequency
Figure 4-6 Lock Frequency Click “SAVE & APPLY”. 4.3.6 SAS Settings... -
Page 23: Appendix Afaqs
Appendix A FAQs The POWER indicator does not turn on. Make sure that the power cable is connected properly and the CPE is powered on. Make sure that the power adapter is compatible with the CPE. Fails to Login to the web management page. ... - Page 24 Appendix B Shipping List The product outward appearance, the color take the material object as, the picture only supply reference. Index Content Picture Amount EG7035E-M11 CPE Power cord PoE adapter Mounting bracket User Manual...
- Page 25 Caution: This device complies with Part 15 of the FCC rules and Industry Canada license‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications ...
