Summary of Contents for Tapco Indoor BlinkerStop
- Page 1 Indoor BlinkerStop® Installation Guide For Fastening Sign To: ƒWalls ƒTelespars ƒWarehouse Racking Systems ƒOther Structures IG0035...
-
Page 2: Table Of Contents
Indoor BlinkerStop® Installation Guide Table Of Contents Exploded View -- Single Bracket ........3 Exploded View -- Two-Brackets ........4 Tools and Hardware ............5 Mount The Sign With A Single Bracket For Vertical Tilting ..................6 Mount the Sign With Two Brackets For Horizontal Panning ..................8... -
Page 3: Exploded View - Single Bracket
Indoor BlinkerStop® Installation Guide Exploded View - Single Bracket... -
Page 4: Exploded View - Two-Brackets
Indoor BlinkerStop® Installation Guide Exploded View - Two-Brackets... -
Page 5: Tools And Hardware
20 ft from the sign. direction and location. See 24 in. Figure 1. WARNING ƒ The Indoor BlinkerStop® is only rated for 120VAC. ƒ Exceeding this voltage can result in death, serious injury, or equipment failure. ƒ Do not apply higher voltages. -
Page 6: Mount The Sign With A Single Bracket For Vertical Tilting
Indoor BlinkerStop® Installation Guide For sign mounting, see Section A or B below according to assembly type. A. MOUNT THE SIGN WITH A SINGLE BRACKET FOR VERTICAL TILTING Skip to the next section if installing a two-bracket assembly for horizontal panning Installer should use his or her own discretion on drilling bolt holes. - Page 7 Indoor BlinkerStop® Installation Guide A.2 Use the hardware from Bag 2 to fasten the male bracket to the bottom of the sign as shown in Figure 3. Tighten with a socket wrench and 1/2 in. socket. Sign Bottom Figure 3 A.3 Insert the nylon spacers from Bag 1 into the male bracket as shown in...
-
Page 8: Mount The Sign With Two Brackets For Horizontal Panning
Indoor BlinkerStop® Installation Guide A.5 Use the hardware from Bag 1 to loosely fasten the male and female brackets together as shown in the top view in Figure 5. Top View Partially tighten with a socket wrench and 7/16 in. socket Figure 5 A.6 Tilt the sign up or down to the desired warning position. - Page 9 Indoor BlinkerStop® Installation Guide B.2 Use the hardware from Bag 3 to loosely fasten the top female bracket to the structure as shown in Figure 7. Amount of bolts used per bracket will vary depending on application. Partially tighten with a 1/2 in.
- Page 10 Indoor BlinkerStop® Installation Guide B.4 Use the same hardware from Bag 3 to fasten the bottom female bracket to the structure, so the top bolt is positioned at the 18 in. mark. B.5 Partially tighten the nuts with a ½ in. wrench.
-
Page 11: Plug In The Sign
B.17 Fully tighten the hardware. C. PLUG IN THE SIGN. Note: ƒ TAPCO recommends using the provided mounting points on the power supply to fasten to a wall or flat surface where it would not obstruct traffic or activity. NOTICE ƒ... -
Page 12: Adjust Brightness (Optional)
Loose or Disconnected Cord Check the connection on the power cord. Low Brightness Adjust the brightness dimmer (see Figure 12). For technical support, call TAPCO® at 800-236-0112 or email customerservice@TAPCOnet.com. 8 am–5 pm (CST) Monday through Friday (800) 236-0112 (800) 236-0112 TAPCOnet.com...
