STYLE NO:
5455-15842 | 16-Section Organizer
A
B
4 ea
4 ea
Vertical Poles
Small Horizontal
Tubes
- Feet & caps
may be preassembled
©2023 Whitmor, Inc.
C
D
4 ea
1 ea
Horizontal Tubes
Cubbies
Part
Reference
A
F12760
B
F12761
C
F12762
D
F12763
E
F12764
F
F12765
G
F12766
H
F12767
No additional tools required.
E
16 ea
Hex Screws
F
4 ea
Caps
G
4 ea
Feet
H
1 ea
Hex Wrench
Page 1
Advertisement
Related Manuals for Whitmor 5455-15842
Summary of Contents for Whitmor 5455-15842
- Page 1 STYLE NO: 5455-15842 | 16-Section Organizer Part Reference F12760 F12761 F12762 F12763 F12764 F12765 F12766 F12767 No additional tools required. 16 ea Hex Screws 4 ea Caps 4 ea Feet 4 ea 4 ea 4 ea 1 ea Vertical Poles...
- Page 2 STYLE NO: 5455-15842 | 16-Section Organizer STEP 1: Side Frame Assembly Insert two caps (F) into the top of the two vertical poles (A). Insert the feet (G) into the bottom of the two vertical poles (A). Attach the small horizontal tubes (B) onto the two vertical poles (A) using four hex screws (E).
- Page 3 STYLE NO: 5455-15842 | 16-Section Organizer STEP 2: Attach the four horizontal tubes (C) to the side frames and secure them using four hex screws (E). Use a hex wrench (H) to tighten. STEP 3: Place the cubbies (D) onto the four horizontal tubes (C).
- Page 4 8680 Swinnea Road • Suite 103 • Southaven, MS • 38671 NEED HELP? For help with assembly, or if you are missing a part, please call Whitmor’s Consumer Care Team, 1-888-944-8667 between 8 a.m. and 4:30 p.m. (Central Standard Time) Monday through Friday, or email: help@whitmor.com. Visit us online at www.whitmor.com Rev#0 | 06.28.23...
