Large Solar Kit
Installation Instructions
1.
Unpack the solar kit from it's packaging. Look
inside the packaging for a set of U-Bolts.
3.
Mark the mounting pole.
This is where the top
U-bolt will be.
2.
4.
Slide the U-bolts over the
pole and tighten when
the top bolt aligns with
previous marking.
The JVA Logo is a Trademark of JVA Technologies Pty Ltd
© JVA Technologies
Remove the U-Bolts from the zip lock bag and
mount it to the top and bottom panel of the
bracket.
(A) U-Bolt x2
(B) Top or Bottom Panel
(C) Washers x4
(D) Spring Washers x4
(E) Hex Nut x4
5.
Loosen the 6 bolts on the
inside of the frame. Do NOT
completely remove the bolts.
