LindabRoofSafetySystem

Installation instructions

Table of Contents

Need help?

Do you have a question about the RoofSafetySystem and is the answer not in the manual?

Questions and answers

Summary of Contents for Lindab RoofSafetySystem

Page 1 l i n d a b w e s i m p l i f y c o n s t r u c t i o n LindabRoofSafetySystem Installation instructions...
Page 2: Table Of Contents
Tile roofing on batten underlay Standing seam long strip roofing Tile roofing on light underlay Fibre cement roof Trapezoidal profile 115 Lindab tile (LPA, LPE) Trapezoidal profiled steel sheet Steel sheet LPP 20 Pivot bolt Felt roofing on batten underlay...
Page 3 Assembly of protective device Installation requirements For fastening to your rooftype see chapter ”fastening for roofs”, then Façade ladder go forward to your product ”assem- bly of protective device” to complete your montage. Slide protection Chimney ladder Ridge rail Snow guard Guard rail Roof walkway Roof ladder...
Page 4 1 July 2008. All products are weather. tested according to the applicable test Lindab has developed a full range of standards and fulfil the requirements for roof safety products for all professional the relevant functional standard.
Page 5 BBR 5:374 2002. roof safety. A risk analysis gives consid- Lindab's roof safety product range fulfils eration to special risks on specific build- ings and the type of work. In this case, applicable requirements for escape routes.
Page 6 Besiktning utförs årligen (vid besiktning följ skötselinstruktionen via QR-koden ovan) Datum Namn/Företag Certifikatsnr 10 18 01 Control and warranty Inspection of lindab’s roof safety shall take place annually. for more information visit: Control and maintenance instruction (in Swedish) Warranty (in Swedish)
Page 7: Concrete Tile With Batten Underlay
KOBETL can be used for installation of protective equipment except ladder: roof all protective equipment except for roof walkway, guard, and ROR snow guard. walkways and ladder: e.g. guards and ROR snow guard. For information about control and warranty visit: www.lindab.se...
Page 8: Concrete Tile With Light Underlay
KOBETL can be used for installation of protective equipment except roof ladder: all protective equipment except for roof roof walkway, guard, and ROR snow walkways or ladder: e.g. guards and guard. ROR snow guard For information about control and warranty visit: www.lindab.se...
Page 9: Standing Seam Long Strip Roofing
36. panel. Tighten the bolts to 20 Nm. When mounting on copper roofs, insula- tion profile FFIP is used to prevent corro- sion between FF and the copper roof. For information about control and warranty visit: www.lindab.se...
Page 10: Fibre Cement Roof
Mark 120 mm higher up for the other hole. For mounting of roof ladder use TSKFF. For mounting of snow fence SNO use Mounting of console UNIK. HSN. For information about control and warranty visit: www.lindab.se...
Page 11: Lindab Tile (Lpa, Lpe)
200 mm from the edge of HSN with 1 screw and nut from bolt set the plate. Fasten TSKIF with the eight accompanying point screws from bolt set 2. For information about control and warranty visit: www.lindab.se...
Page 12 Mount UNIK in the bolts. Mount TSK in the bolt. Mount HSN in the bolt. Position IFLPP on LPP20 and fasten in the plate with eight point screws from bolt set 23. For information about control and warranty visit: www.lindab.se...
Page 13: Felt Roofing On Batten Underlay
26. A disc must also be arranged above the bolt set 26. rubber disc for LLF150. Use bolt set 27. For information about control and warranty visit: www.lindab.se...
Page 14 GRB under and the accompanying nuts. fastener and the accompanying nut from LLF150 and the accompanying nuts. bolt set 26. There should also be a disc above the rubber disc. For information about control and warranty visit: www.lindab.se...
Page 15 GRB under and the accompanying nuts. fastener and the accompanying nut from LLF150 and the accompanying nuts. bolt set 26. There should also be a disc above the rubber disc. For information about control and warranty visit: www.lindab.se...
Page 16: Felt/Membrane Fastening On The
TSK and the accompanying nuts der LLF150 and the accompanying nuts bolt set 26. from bolt set 3. from bolt set 30. There should also be a disc above the rubber disc. For information about control and warranty visit: www.lindab.se...
Page 17 3. fastener and the accompanying nut from LLF150 and the accompanying nut from bolt set 26. bolt set 3. There should also be a disc above the rubber disc. For information about control and warranty visit: www.lindab.se...
Page 18: Sandwich Panels
11. Use the outer holes on positioned on the upper side. Mount SAWPLF. SAWPLF on the sandwich panel with 8 screws from bolt set 11. For information about control and warranty visit: www.lindab.se...
Page 19: Sinusoidal Profiled Steel Sheet
HSN on IFSIN 26. Mount with 2 screws and nuts from bolt set 29, nuts po- sitioned on the upper side. Place IFSIN 26 on the roof, fixate with 10 screws from bolt set 29. For information about control and warranty visit: www.lindab.se...
Page 20: Steel Sheet Lpp
If the HSN is used (snow guard), fit it on the IFSRP first, as illustrated. Mount HSN against IFSRP with one screw and nut from bolt set 4, nut on the upper side. For information about control and warranty visit: www.lindab.se...
Page 21 4, IFSRPN, as illustrated. IFSRPN, as illustrated. nut on the upper side. For information about control and warranty visit: www.lindab.se...
Page 22: Tile Roofing On Batten Underlay
KOTEGL can be used for installation of protective equipment except for ladders: all protective equipment except for roof e.g. roof walkway, guard, ROR snow walkways or ladders: e.g. guards, ROR guard. snow guard. For information about control and warranty visit: www.lindab.se...
Page 23: Tile Roofing On Light Underlay
KOTEGL can be used for installation of protective equipment except for ladders: all protective equipment except for roof e.g. roof walkway, guard, ROR snow walkways or ladders: e.g. guards, ROR guard. snow guard. For information about control and warranty visit: www.lindab.se...
Page 24: Trapezoidal Profile 11
200 mm TSKIF. trated, with one screw and nut from bolt from the edge of the plate. Fasten TSKIF set 36. with eight screws from bolt set 2. For information about control and warranty visit: www.lindab.se...
Page 25: Trapezoidal Profiled Steel Sheet
TSKIF first, as illustrated. profile top on the plate at least 200 mm TSKIF. from the edge of the plate. Fasten TSKIF with eight drill bit screws from bolt set For information about control and warranty visit: www.lindab.se...
Page 26: Pivot Bolt
VIPPBULT is positioned immediately beneath the boards. Fasten TSK to the VIPP-bolt. Maximum distance betewwn consoles 1,5 m. At least three consoles per ladder. For information about control and warranty visit: www.lindab.se...
Page 27: Façade Ladder
1 screw per VSK, all VSK must be used. Brackets max 600 mm C-C between fastening hole and wall bracket VSK is 435 mm on all dimen- sions. For information about control and warranty visit: www.lindab.se...
Page 28 2 screws and nut 45mm through and 2 screws and nut 25mm to fix the glove around the ladder. Diagonal restraint VSKSL and VSKSF are mounted crosswise with 4 screws and nut from bolt set 39. For information about control and warranty visit: www.lindab.se...
Page 29 Also mount coupling HALKSBR between handrail and ladder. Fasten coupling HALKSBR against walkway with 2 screws and nut and and against handrail with 2 screws and nut. For information about control and warranty visit: www.lindab.se...
Page 30 40. VSST is from bolt set 40. to be mounted on VSBYH with 5 screws The protective cage may end 2.5 metres and nut from bolt set 41. above the ground. For information about control and warranty visit: www.lindab.se...
Page 31: Slide Protection
Loosen the nuts and position the slide protection over the seam. Ensure that the low- er part comes down far enough for the ground ladder's connection. Tighten the three nuts with a 16 mm socket wrench. Ensure that they are tightened correctly (approx. 45-55 Nm). For information about control and warranty visit: www.lindab.se...
Page 32 Loosen the nuts and position the slide protection over the seam. Ensure that the lower part comes down far enough for the ground ladder's connection. Tighten the three nuts with a 16 mm socket wrench. Ensure that they are tightened correctly (approx. 45-55 Nm). For information about control and warranty visit: www.lindab.se...
Page 33 Mount the angle VIPAPP to the plate. Mount VINGEH and VINGEV with the use the accompanied rubber washer 3 accompanied screws and nuts. GRB from bolt set 26 below the angle and nut from bolt set 26. . For information about control and warranty visit: www.lindab.se...
Page 34: Chimney Ladder
TVS with 2 accompanied screws and nuts. walkway with a guard STANDN. Fasten the walkway with 2 screws and nuts per SKKO from bolt set 5. Fasten VSSP with 4 included drill bit screws. For information about control and warranty visit: www.lindab.se...
Page 35: Ridge Rail
Ridge rail - ROR Installation of ROR as ridge rail on KOBET/L, KOTEG/L and UNIK Installation requirements • Bottom brackets are fastened on the underlay according to instruc- tions • The distance L is max. 1200 mm, but varies for different snow zones. Visit www.roofsafetysystems.se to determine the correct distance for brackets.
Page 36: Snow Guard
ISSTOPP can also be installed on the supplied drill bit screw. middle tube if necessary. Fix ISSTOPP with 1 included drill bit screw. For information about control and warranty visit: www.lindab.se...
Page 37 Use the 4 accompanying drill bit screws and overlap SAWSG. top hole). Use AND tube end in each tube end. Fasten AND as close to SAWK as possible. Fix AND with 1 accompa- nied drill bit screw. For information about control and warranty visit: www.lindab.se...
Page 38 KOTEG/L by twisting the lock washer around with pliers. The distance between the roof (profile top on tile and profiled sheet) and the snow guard's lower edge must not exceed 30 mm. For information about control and warranty visit: www.lindab.se...
Page 39 With use of consol UNIK: fasten in the plate IF115 with one accompanied ISKRATTA with the 6 accompanied drill ISKRATTA with the 6 accompanied drill drill bit screw. bit screws. bit screws. For information about control and warranty visit: www.lindab.se...
Page 40: Guard Rail
• Bottom brackets are fastened on the underlay according to instruc- tions • A maximum pole spacing of <1200 mm is used for long guard rails. Various versions can be used with guard rail. For information about control and warranty visit: www.lindab.se...
Page 41 Use the two accompanying drill bit screws. If necessary, ROR can be joined by threading the crimped end over the non-crimped one and fastened with the supplied drill bit screw. For information about control and warranty visit: www.lindab.se...
Page 42: Roof Walkway
It is possible to adjust the length of the walkway after your need, cut using a hacksaw and then repaint the surface. When working attached to the bridge, hold 4 meters distance between each person. For information about control and warranty visit: www.lindab.se...
Page 43 Roof walkway with brackets Assembly with console UNIK Roof slope 5° 10° 15° 20° 25° 5+1/3+3 30° 6+2/4+4 35° 40° 45° Adjust the angle according to chart. 50° Attach UNIK in UNIKBR. For information about control and warranty visit: www.lindab.se...
Page 44 Roof walkway with brackets Assembly with KOBET/KOTEG Roof slope 5° 10° 15° 20° 25° 30° 35° 40° 45° Adjust angle according to chart Attach KOBR in KOBET/KOTEG with 2 50° screws and nuts from bolt set 10. 60° The T-bracket must be bent away when setting the maximum roof slope of 60°.
Page 45 200mm. The joint is locked in place with two screws and nuts from bolt set SKARVBR. When joining several bridges each bridge must always rest on at least 2 brackets. min 200 mm For information about control and warranty visit: www.lindab.se...
Page 46 Roof walkway BRSTAG BSTAG walkway stiffener must be used. Mount with one screw and nut from bolt set 4, loosen screw and nut from the console to fix BSTAG against the console. Support points max 300 mm max 1200 mm max 500 mm max 500 mm At least three brackets must be used per length.
Page 47 BRSTON. Fasten with a drill bit screw at each joint with ROR. Fasten STANDN och BRSTON with 2 drill bit screws from bolt set 8, one on the upperside and one in the middle. For information about control and warranty visit: www.lindab.se...
Page 48: Roof Ladder
1,5 nuts. m. At least three pairs of brackets must be used for each ladder length. Fasten the ladder on TSK with 2 includ- ed drill bit screws. For information about control and warranty visit: www.lindab.se...
Page 49 3 wood screws from bolt set 37. The maximum distance between brackets is 2 m. At least three pairs of brackets must be used for each ladder length. Fasten the ladder on TSK with drill bit screws. For information about control and warranty visit: www.lindab.se...
Page 50 Fasten the ladder on TSK with 2 drill bit imum distance between brackets is 1,5 screws from bolt set 36.. m. At least three pairs of brackets must be used for each ladder length. For information about control and warranty visit: www.lindab.se...
Page 51 Fasten the TVS ladder on the TSK/TSKFF ladder bracket with 2 drill bit screws from bolt set 36. The maximum distance between brackets is 1,5 m. At least three pairs of brackets must be used for each ladder length. For information about control and warranty visit: www.lindab.se...
Page 52 Roof ladder Joining of ladders The ladder is joined by guiding the The TSSV joining kit is used for dis- crimped end into the upper ladder. Fas- continuous roofs. Mount TSSV with 8 ten them together with 2 accompanied accompanied drill bit screws. drill bit screw.
Page 53 16° 23° 30° 37° 44° Measure the roof pitch and determine Hook TSST around the rung and fasten which hole is suitable for the roof pitch. with 2 accompanied drill bit screws. For information about control and warranty visit: www.lindab.se...
Page 54: Wire System
M12 double nut, premounted on the bly. wire. Thread the wire end through WFANDL end fastener and fix with disc and M12 double nut. The wire should only be tightened til it is streched. For information about control and warranty visit: www.lindab.se...
Page 55 Guide wire end through WFANDL end fastener and fix with disc and M12 double nut, premounted on the wire. The wire should only be tightened til it is streched. For information about control and warranty visit: www.lindab.se...
Page 56 Wire system Installation requirements • Approved for installion on maximum - walkway vertically towards 15° roof pitch. • The support fasteners are installed the ridge at a maximum distance of 2,5m • Allways install a support fastener 1m from eaves. Mount the WFANDL start and end Install WSLOPS wire support for runners Mount the WFSTL support fasteners in the...
Page 57 Wiresystem Installation requirements • Roof pitch 0-15° - two end faste- - roof ladder ners on each wire, wire support with 2500mm gap and wire support at 1000mm distance from eaves. • Roof pitch 16-45° - two end faste- ners on each wire, wire support with 1500mm gap and wire support at 1000mm distance from eaves.
Page 58 Tie the tension rope to the small carabi- Fasten the the wire pulley’s carabiner ner hook on the wire pulley. hook to the upper fastener VSWFO and tie the tensin rope the lower fastener VSWFU. For information about control and warranty visit: www.lindab.se...
Page 59: Anchorage Poin
If steel sheet with maximum 0,9mm thickness is used, mount with 8 point screws from from bolt set 31. bolt set 31. Steel sheet 1,0mm or more use 8 drill bit screws from bolt set 31. For information about control and warranty visit: www.lindab.se...
Page 60 Anchorage point Installation requirements • Anchorage point may only be used by one person at a time. • Anchorage point may only be used as single attachment point for roofs Installation on trapezoidal profile roofing with roof pitch <6°. If LLF is to be used (anchorage point) , Position IF20, IF35, IF45 on a profile top first mount it on IF20, IF35,IF45 accor- on the plate at least 200 mm from the...
